Radiocrafts
Embedded Wireless Solutions
RC1180DK-MBUS Quick Start
Quick Start Guide
1. Set up each board as illustrated in the picture
Connect to
power
Connect to
serial port
2. Download the latest version of RCTools-MBUS from
as described in the RCTools Installation Guide.
©2008 Radiocrafts AS
RC1180DK-MBUS
RC1180DK-MBUS Quick Start (rev. 1.1)
Ensure that the
power jumper is
mounted
Connect the
antenna
Ensure that RXD
and TXD jumper
are mounted
www.radiocrafts.com
and install
Page 1 of 2
Advertisement
Related Manuals for Radiocrafts RC1180DK-MBUS
Summary of Contents for Radiocrafts RC1180DK-MBUS
- Page 1 Ensure that RXD serial port and TXD jumper are mounted 2. Download the latest version of RCTools-MBUS from www.radiocrafts.com and install as described in the RCTools Installation Guide. ©2008 Radiocrafts AS RC1180DK-MBUS Quick Start (rev. 1.1) Page 1 of 2...
- Page 2 RC1180-MBUS board will appear in this window. Contact Information Radiocrafts AS www.radiocrafts.com Tel: +47 4000 5195 Sandakerveien 64 radiocrafts@radiocrafts.com Fax: +47 22 71 29 15 NO-0484 OSLO sales@radiocrafts.com NORWAY support@radiocrafts.com ©2008 Radiocrafts AS RC1180DK-MBUS Quick Start (rev. 1.1) Page 2 of 2...
