Proxima Media Express Supplementary Manual

Askproxima media express: supplementary guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARRANTY
Proxima Corporation warrants that all Proxima® products purchased from Proxima are free from defects in materials
and workmanship under normal use during the Warranty Period. The Warranty Period commences on the day of
purchase by the end-user. The Warranty Period is one year.
Each Proxima product is manufactured from new parts, or new and some used parts. In some cases, the product may
have been delivered to another end-user and then returned. In all cases, the product has undergone testing and quality
inspection, meets all of Proxima's requirements for a new product, and our full warranty terms apply. The end-user's
sales receipt or invoice showing the date of purchase of the product and the name of the Reseller is proof of date of
purchase. The Warranty extends only to the original purchaser and is not transferable.
During the Warranty Period, Proxima will, at no additional charge, repair or replace defective parts or at the option of
Proxima, replace the entire unit.
LIMITATION OF WARRANTIES
This Limited Warranty does not extend to any Proxima product that has been damaged or been rendered defective (a)
as a result of accident, misuse, or other abuse; (b) by the use of parts not manufactured or sold by Proxima; or (c) by
modification of the product.
The foregoing warranty is expressly in lieu of any other express or implied warranties, including, without limitation,
warranties of merchantability or fitness for a particular purpose. To the extent not prohibited by law, all statutory
warranties are hereby waived and excluded from this warranty. Proxima expressly disclaims all warranties not stated in
this Limited Warranty.
FCC STATEMENT
Warning: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause interference to radio communications. It has been tested and found
to comply with the limits for a Class A computing device pursuant to Subpart B of Part 15 of the FCC Rules, which are
designed to provide reasonable protection against such interference when operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference in which case the user at his own
expense will be required to take whatever measures may be required to correct the interference.
Warning: This is a Class A product. In a domestic environment this product may cause radio interference, in which case
the user may be required to take adequate measures.
TRADEMARKS AND PATENTS
Proxima and Cyclops are registered trademarks; Desktop Projector, Desktop Projection, and MediaExpress are
trademarks of Proxima Corporation. Other trademarks are the property of their respective owners. This product is
covered by one or more of the following U.S. and foreign patent numbers: 5,062,001, 5,137,484, 5,153,568, 5,177,629,
5,181,015, 5,225,875, 5,264,835, 5,276,436, 5,298,892, 5,299,039, 5,300,944, 5,302,946, 5,321,450, 5,400,095,
5,453,803, 5,459,484, 5,483,382, 5,489,923, 5,499,036, 5,502,459, 5,504,501, 5,510,861, 5,512,967, 5,515,079, and
DES. 360,426.
Adobe, the Adobe logo, Acrobat, the Acrobat logo, Distiller, Exchange, and PostScript are trademarks of Adobe Systems
Incorporated or its subsidiaries and may be registered in certain jurisdictions.
Australia Pat. Nos. 644 852, 668 823
Canada Registered Design No. 74980 D Proxima Corporation 1994
British Registered Design No. 2 038 977
Germany Registered Design No.
M 94 03 987.9 geschutztes Muster, Under
Geschmacksmusterschutz
China Patent for Design No. 94303399.3
Japan Registered Design No. 948294
South Korean Registered Design No. 174628
Other US and foreign patents applied for.
© 1996 Proxima Corporation. All rights reserved. Specifications are subject to change without notice.
