X90 w
Multimedia Projector

Network Functions

This manual is only intended to explain Network Functions.
For safety, operations or any other issues, refer to the all user's manual for this
projector.
WARNING
for this projector carefully to ensure your projector is set up correctly.
• After reading, keep the manuals in a safe place for future reference.
NOTE
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in
this manual.
• The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.
Trademark acknowledgment
• Windows is a registered trademark of Microsoft Corporation.
• Netscape is a registered trademark of Netscape Communications Corporation.
• JavaScript is a registered trademark of Sun Microsystems, Inc.
All other trademarks are the properties of their respective owners.
Contents
Network Functions .................................................................. 2
Settings ................................................................................... 6
Projector Control ................................................................... 22
Failure & Warning Alerts via E-mail ...................................... 26
Projector Management via SNMP .......................................... 28
Controlling the Projector via Scheduling .............................. 29
e-SHOT(Still Image Transfer) Display ................................... 32
Command Control via the Network ....................................... 34
• Before using the network functions, read the all user's manual
© 3M 2007. All Rights Reserved.


Advertisement

Table of Contents
loading

Related Manuals for 3M X90

Summary of Contents for 3M X90

  • Page 1: Table Of Contents

    Failure & Warning Alerts via E-mail ... 26 Projector Management via SNMP ... 28 Controlling the Projector via Scheduling ... 29 e-SHOT(Still Image Transfer) Display ... 32 Command Control via the Network ... 34 © 3M 2007. All Rights Reserved. ...

  • Page 2: Network Functions

    Still Image Transfer The projector can display still images that are transferred via the network. (32) Projector Control via RS-232C via the Network The projector can be controlled using RS-232C commands over a network. (34) © 3M 2007. All Rights Reserved.
  • Page 3 [DEFAULT GATEWAY]: Enter an appropriate Gateway (the router/PC that forwards traffic to a destination outside of the subnet of the transmitting device) address for the projector to connect to your network. © 3M 2007. All Rights Reserved. Network Functions...

  • Page 4: Configuring And Controlling The Projector Via A Web Browser

    Windows XP Service Pack 2 install security update Q832894 (MS04-004) or the web browser interface may not be displayed correctly. And when using an older version of Internet Explorer, during operations the browser will log out after 50 seconds. © 3M 2007. All Rights Reserved.
  • Page 5 Below are the factory default settings for administrator IDs, user IDs and passwords. Item Administrator ID Administrator User ID Description Password <blank> User <blank> © 3M 2007. All Rights Reserved. Network Functions Administrator ID User ID √ √ √ √ √ √ √ √...

  • Page 6: Settings

    Fig.  (Logon with administrator ID) 3) Click the desired operation or configuration item on the main menu located on the left-hand side of the screen (Fig. 2 or Fig. 3). Fig.  Fig. 3 (Logon with user ID) © 3M 2007. All Rights Reserved.

  • Page 7: Network Information

    All screen images displayed in this manual are screens of a logon using an administrator ID. Any administrator only functions will not be displayed when using a user ID. Refer to the descriptions in each table. Description © 3M 2007. All Rights Reserved. Settings...

  • Page 8: Network Settings

    Configures the Subnet Mask when DHCP is disabled. Configures the Default Gateway when DHCP is disabled. Configures the Projector name. Configures the location to be referred to when using SNMP. Configures the contact information to be referred to when using SNMP. © 3M 2007. All Rights Reserved.

  • Page 9: Port Settings

    Configures the SNMP port. Click the [Enable] check box to use SNMP. Configures the destination of the SNMP Trap in IP format. Configures the SMTP port. Click the [Enable] check box to use the e-mail function. © 3M 2007. All Rights Reserved. Settings...

  • Page 10: Mail Settings

    Configures the e-mail address of up to five recipients. You can also specify [TO] or [CC] for each address. The length of the recipient e-mail address can be up to 255 alphanumeric characters. © 3M 2007. All Rights Reserved.

  • Page 11: Alert Settings

    The length of the subject line can be up to 255 alphanumeric characters. Configures the text of the e- mail to be sent. The length of the text can be up to 1024 alphanumeric characters. © 3M 2007. All Rights Reserved. Settings...
  • Page 12 The length of the subject line can be up to 255 alphanumeric characters. Configures the text of the e-mail to be sent. The length of the text can be up to 1024 alphanumeric characters. © 3M 2007. All Rights Reserved.
  • Page 13 The length of the subject line can be up to 255 alphanumeric characters. Configures the text of the e-mail to be sent. The length of the text can be up to 1024 alphanumeric characters. © 3M 2007. All Rights Reserved. Settings...
  • Page 14 The length of the subject line can be up to 255 alphanumeric characters. Configures the text of the e-mail to be sent. The length of the text can be up to 1024 alphanumeric characters. © 3M 2007. All Rights Reserved.
  • Page 15 Configures Cold Start alert settings. Click the [Enable] check box to enable SNMP Trap alerts for this item. Configures Authentication Failure alert settings. Click the [Enable] check box to enable SNMP Trap alerts for this item. © 3M 2007. All Rights Reserved. Settings...

  • Page 16: Schedule Settings

    Configures the Friday schedule. Click the [Enable] check box to enable Friday scheduling. Displays the current Friday schedule. Configures the Saturday schedule. Click the [Enable] check box to enable Saturday scheduling. Displays the current Saturday schedule. © 3M 2007. All Rights Reserved.
  • Page 17 Displays the current specific date (No.4) schedule. Configures the specific date (No.5) schedule. Click the [Enable] check box to enable specific date (No.5) scheduling. Set the Month and date. Displays the current specific date (No.5) schedule. © 3M 2007. All Rights Reserved. Settings...
  • Page 18 Configures the parameters for power control. Configures the parameters for input switching. Configures the parameters for display of transfer image data. Description Configures the current date in Year/Month/Day format. Configures the current time in Hour:Minute:Second format. © 3M 2007. All Rights Reserved.
  • Page 19 Click the [ON] check box to retrieve Date and Time information from the SNTP server and set the following items. Configures the interval at which to retrieve Date and Time information from the SNTP server. (hours:minutes). © 3M 2007. All Rights Reserved. Settings...

  • Page 20: Security Settings

    The length of the text can be up to 32 alphanumeric characters. Configures the User Password. The length of the text can be up to 255 alphanumeric characters. Used to re-enter the above password for verification. © 3M 2007. All Rights Reserved.
  • Page 21 Used to re-enter the above password for verification. Configures the community name if SNMP is used. Configures the community name. The length of the text can be up to 64 alphanumeric characters. © 3M 2007. All Rights Reserved. Settings...

  • Page 22: Projector Control

    Selects the Gamma setting. Selects the Color Temp setting. Adjusts the Color setting. Adjusts the Tint setting. Adjusts the Sharpness setting. Selects the Active Iris setting. Recalls the MyMemory data. Saves the MyMemory data. © 3M 2007. All Rights Reserved.
  • Page 23 Selects the RGB input signal type. Selects the RGB input signal type. Adjusts the Vertical Keystone setting. Adjusts the Horizontal Keystone setting. Selects the Fan speed. (Normal or Whisper) Selects the Mirror status. © 3M 2007. All Rights Reserved. Projector Control...
  • Page 24 Assigns the functions for the MY BUTTON2 buttons on the included remote control. Enables/Disables Auto Adjustment. Enable/Disable Remote Receiv. Front. Enable/Disable Remote Receiv. Rear. Enable/Disable Remote Receiv. Top. Enable/Disable Remote Freq. Normal. Enable/Disable Remote Freq. High. © 3M 2007. All Rights Reserved.

  • Page 25: Projector Status

    Displays the current input signal source. Displays the Blank On/Off status. Displays the current Mute On/Off status. Displays the current Freeze On/Off status. Description Restarts the projector’s network connection in order to activate new configuration settings. © 3M 2007. All Rights Reserved. Projector Control...

  • Page 26: Failure & Warning Alerts Via E-Mail

    The following mail will be delivered to the specified addresses. Subject line : Test Mail Text : Send Test Mail Date Time IP Address MAC Address (10) <Projector name> <Testing date> <Testing time> <Projector IP address> <Projector MAC address> © 3M 2007. All Rights Reserved.
  • Page 27 Failure/Warning e-mails are formatted as follows: Subject line : <Mail title> Text : <Mail text> Date Time IP Address MAC Address Failure & Warning Alerts via E-mail <Projector name> <Failure/Warning date> <Failure/Warning time> <Projector IP address> <Projector MAC address> © 3M 2007. All Rights Reserved.

  • Page 28: Projector Management Via Snmp

    ) Click the [Enable] check box to send out the SNMP trap for Failures/Warnings. Clear the [Enable] check box when SNMP trap transmission is not required. 9) Click the [Apply] button to save the settings. (9) © 3M 2007. All Rights Reserved.

  • Page 29: Controlling The Projector Via Scheduling

    (e.g., ‘Specific day No. 1’ has priority over ‘Specific day No. ’ and so on. • Be sure to set the date and time before enabling scheduled events. © 3M 2007. All Rights Reserved.
  • Page 30 DATE and TIME have been set correctly. Replace the battery by following the instructions on replacing the battery. ( Operator's Guide : Internal clock battery) • The Internal Clock’s time may not remain accurate. Using SNTP is recommended to maintain accurate time. (18) © 3M 2007. All Rights Reserved.
  • Page 31 [¡] or the breaker in a room is tripped. The power indicator will lights orange or green when the projector gets is receiving the power. Controlling the Projector via Scheduling (16) © 3M 2007. All Rights Reserved.

  • Page 32: E-Shot(Still Image Transfer) Display

    4) Click the [Enable] check box to open the [Image Transfer Port (Port: 9716)]. Click the [Enable] check box for the [Authentication] setting when authentication is required, otherwise clear the check box. 5) Click the [Apply] button to save the settings. © 3M 2007. All Rights Reserved.
  • Page 33 (Still Image Transfer) Transmission e-SHOT transmission requires an exclusive application for your PC. Please visit www.3m.com/meetings to obtain the application and software update. Refer to the manual for the application for instructions. e-SHOT(Still Image Transfer) Display...

  • Page 34: Command Control Via The Network

    5) Click the [Enable] check box to open [Network Control Port (Port: 9715)] to use TCP #9715. Click the [Enable] check box for the [Authentication] setting when authentication is required, otherwise clear the check box. 6) Click the [Apply] button to save the settings. (9) © 3M 2007. All Rights Reserved.
  • Page 35 • The new configuration settings are activated after restarting the network. Restart the network when any configuration settings are changed. The network connection can be restarted using [Network Restart] on the main menu. Command Control via the Network © 3M 2007. All Rights Reserved.

  • Page 36: Command Format

    Connection ID → Random value from 0 to 255 (This value is attached to 0x00 RS-232Ccommand 13 bytes  bits from the header to the checksum. the reply data) © 3M 2007. All Rights Reserved. Connection Checksum  byte  byte...
  • Page 37 <Projector busy reply> Reply Status code 0x1F  bytes <Authentication error reply> Authentication Reply Error code 0x1F 0x04 Command Control via the Network Connection  byte Connection  byte Connection  byte Connection 0x00  byte © 3M 2007. All Rights Reserved.
  • Page 38 5) Add this “e3d97429adffa11bce1f7275813d4bde” in front of the commands and send the data. Send “e3d97429adffa11bce1f7275813d4bde”+command. 6) When the sending data is correct, the command will be performed and the reply data will be returned. Otherwise, an authentication error will be returned. © 3M 2007. All Rights Reserved.
  • Page 39 The use of other replacement lamps, outdoor operation, or different voltages has not been tested and could damage the projector peripheral equipment and/or create a potentially unsafe operating condition. 3M Multimedia projectors and Wall Display Systems are designed to operate in a normal office environment. • 16° to 29°C (60° to 85° F) •...
