3Com OfficeConnect 3CR100A97 Quick Start Manual

Adsl data
Hide thumbs Also See for OfficeConnect 3CR100A97:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
OfficeConnect
®
Gateway
ADSL Data (3CR100A97)
Quick Start Guide

Advertisement

Table of Contents
loading

Related Manuals for 3Com OfficeConnect 3CR100A97

Summary of Contents for 3Com OfficeConnect 3CR100A97

  • Page 1 OfficeConnect ® Gateway ADSL Data (3CR100A97) Quick Start Guide...
  • Page 2 Software is delivered as Commercial Computer Software as defined in DFARS 252.227-7014 (June 1995) or as a commercial item as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software.

  • Page 3: Before You Begin

    ADSL (Asymmetric Digital Subscriber Line) broadband access solution. This guide describes how to set up the OfficeConnect Gateway Data (3CR100A97) base unit. The OfficeConnect Gateway allows one or more networked computers to connect to the Internet or a remote LAN (Local Area Network).
  • Page 4 Package Contents Positioning Gateway Figure 1 Unpack the contents of your package, and ensure that it includes the following items: • AC/DC, 18 watt Power Adapter and Power Cord • LAN cable, RJ-45 (CAT-5), Blue • ADSL cable, RJ-11/RJ-11, Black •...

  • Page 5: Connect Cables

    To connect the OfficeConnect Gateway’s cables: 1. Connect the DSL cable. Note: If you will be using the 3Com OfficeConnect Connect the DSL cable (black) to the ADSL wall jack and the Gateway Voice Expansion other end to the DSL port (black) of your OfficeConnect Gateway.

  • Page 6: Operational Status

    Operational Once the unit is connected, the Power LED illuminates (green) on the front panel of the OfficeConnect Gateway Data unit. Wait for Status the Alert LED on the front panel to stop flashing (amber) and transition to off, within 1-2 minutes. When the Power LED is green and the Alert LED is off, it indi- cates that the OfficeConnect Gateway Data unit has successfully powered up, performed a Power On Self-Test (POST) and is now...
  • Page 7 Configure The following procedure describes how to initially configure the Wide Area Network (WAN) interface settings for your the Gateway OfficeConnect Gateway or re-configure them after resetting the unit to its factory default settings. Using a web browser on your PC, launch the OfficeConnect Gateway home page by entering the OfficeConnect Gateway’s Figure 3 If the WAN Interface Inactive message is displayed (Fig 4), your...

  • Page 8: Related Documents

    OfficeConnect Gateway User’s Guide. Alternately you can type www.3com.com/ocg/docs directly in your browser’s address bar. The only information required for an RFC 1483 configuration in a dynamic environment are the VPI/VCI numbers from your ISP.

  • Page 9: Static Configuration

    RFC1483 In an RFC 1483 or an RFC 1483-MER configuration with static IP addressing, the DHCP Client over WAN setting is disabled. You Static will also see fields for local and remote WAN IP addresses, and for the WAN IP Mask. Configuration Assign a meaningful name to your configuration in the PVC Name field, and record your settings here:...

  • Page 10: Rebooting The Unit

    OfficeConnect Gateway. Note the User’s Guide (available online at www.3com.com/ocg/docs) and the settings you recorded earlier to set up your workstations and the OfficeConnect Gateway for static IP addressing. An example of an eight-user connection is shown below (Fig 8), using a 3Com OfficeConnect Ethernet Hub 8.

  • Page 11: Front Panel Indicators

    Front Panel The LED Indicators on the front panels of the OfficeConnect Gateway Data unit provide the following information: Indicators Alert Amber (blinking) Power Green DSL Status Link Yellow (blinking) Green, then Yellow (blinking) Green Data Green (blinking) Green LAN Status Green Green Data...

  • Page 12: Technical Support

    If you are unable to contact your network supplier, see the following section on how to contact 3Com. Support from 3Com If you are unable to obtain assistance from the 3Com online technical resources or from your network supplier, 3Com offers technical telephone support services. To find out more about your support options, please call the 3Com technical telephone support phone number at the location nearest you.
  • Page 13 Returning Products for Repair Before you send a product directly to 3Com for repair, you must first obtain a Return Materials Authorization (RMA) number. Products sent to 3Com without RMA numbers will be returned to the sender unopened, at the sender’s expense.
  • Page 14 first forty-eight (48) hours of installation but no later than thirty (30) days after the date of purchase, and this is verified by 3Com, it will be considered dead- or defective-on-arrival (DOA) and a replacement shall be provided by advance replacement. The replacement product will normally be shipped not later than three (3) business days after 3Com’s...
  • Page 15 FOR BREACH OF THAT WARRANTY SHALL BE REPAIR, REPLACEMENT, OR REFUND OF THE PUR- CHASE PRICE PAID, AT 3COM’S OPTION. TO THE FULL EXTENT ALLOWED BY LAW, THE FORE- GOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WAR-...
  • Page 16 3Com Corporation, Corporate Headquarters, 5400 Bayfront Plaza, Santa Clara, CA 95052-8145, USA. To learn more about 3Com solutions, visit www.3com.com. 3Com Corporation is publicly traded on Nasdaq under the symbol COMS. All specifications are subject to change without notice. Printed in the U.S.A.
