Sylvania Roadsight Mirror Instruction Manual

Forward and rear dash camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Forward and Rear Dash Camera
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Sylvania Roadsight Mirror

Summary of Contents for Sylvania Roadsight Mirror

  • Page 1 Forward and Rear Dash Camera Instruction Manual...

  • Page 2: Table Of Contents

    1. Package Contents 2. Device Specifications 3. Device Layout 4. Installing Micro SD Card 5. Mounting SYLVANIA Roadsight Mirror Dash Camera 6. Wiring Rear Camera 7. Wiring Back Up Camera - Option 1 8. Wiring Back Up Camera - Option 2 9.
  • Page 3 WARNING: The Dash Cam must not be fitted in a position which obscures the driver’s view of the road ahead. Depending on the country of use, recordings made with this device may be subject to Data Protection Laws. Ensure these are complied with.
  • Page 4 Click here to view install video For Step-by-Step Install Videos. Go to: www.sylvania-automotive.com Travel the road with assurance.

  • Page 5: Package Contents

    1. Package Contents SYLVANIA Roadsight Mirror Dash Camera SYLVANIA Roadsight Mirror Rear Camera SYLVANIA Roadsight Mirror Quick Start Guide Rubber Mounting Straps (2X) Adhesive Strip Mounting Screws (2X) USB Charging Cable 32GB Micro SD Card Trim Removal Tool SYLVANIA Dash Camera Window Sticker (3X)

  • Page 6: Device Specifications

    2. Device Specifications Technical Specifications • 170° Ultra Wide Field of View • Intelligent Software Detects Collision or Motion • Continuous Loop Recording • Auto Locks and Saves Collision Video • Capture and Save Images Easily • 10” 1080p Full Width IPS Touch Screen •...
  • Page 7 170° Ultra Wide Field of View Forward and rear camera record at HD 1080p quality with 170° Ultra Wide field of view. Offering up to 340° field of view at 30 frames per second. Travel the road with assurance.
  • Page 8 Intelligent Software Detects Collision or Motion Whether you are inside or outside of your vehicle, our intelligent collision software senses if the vehicle has been bumped or hit and starts recording the incident. The recorded collision video is saved and locked on the camera. Intelligent motion detection software detects movement in the environment around and starts recording.
  • Page 9 Continuous Loop Recording Recordings are automatically saved over one another. No need to remove and empty micro SD card. Locked footage is saved and cannot be overwritten. Auto Locks and Saves Collision Video In the event of a collision the dash camera will automatically lock and save video.
  • Page 10 Capture and Save Images Easily Press the Take Photo button to quickly capture and save the image on your dash camera. Saved photos can be viewed in the playback menu under images. 10” 1080p Full Width IPS Touch Screen Built with a high quality 10” 1080p touch screen to give high resolution playback.
  • Page 11 Image Assisted Reverse Parking Guidance lines when reversing your vehicle gives you a better sense when objects are in the vehicle’s blind spot. Helps to prevent accidents when reversing your vehicle. IP67 Rated Waterproof Rear Camera Don’t worry about rain and snow affecting your rear mounted camera.

  • Page 12: Device Layout

    3. Device Layout 10” 1080p Full Width IPS Touch Screen Conical Dash Camera for Field of View Adjustment Mini USB Power Slot Rear View Camera Aux Power Slot Micro SD Card Slot Power Button System Speaker Cushion Pads to Prevent Scratches to OEM Mirror Rubber Mount Strap Brackets Adjustable Dash Camera Position Slide Travel the road with assurance.
  • Page 13 Right Angle Bracket (Correct mounting position as shown) Bracket Feet for Mounting Red Power Cable for Auto Switch to Rear Camera 19.3’ Rear Camera Aux Power Cable 11.7’ Camera Aux Power Cable with USB Port Mini USB Power Cable Travel the road with assurance.

  • Page 14: Installing Micro Sd Card

    4. Installing Micro SD Card Before installing the 32GB micro SD card, confirm the device is turned off. Insert included micro SD card into slot until it clicks into place. To remove micro SD card, press down slightly then remove micro SD card from the slot. WARNING: Do not apply excessive force when inserting a memory card to avoid damage to the device.

  • Page 15: Mounting Sylvania Roadsight Mirror Dash Camera

    5. Mounting SYLVANIA Roadsight Mirror Dash Camera The SYLVANIA Roadsight Mirror mounts over your OEM rear view mirror. Use the Adjustable Dash Camera Position Slide to extend dash camera fully out. Making sure the dash camera does not interfere with the OEM rear view mirror during install.
  • Page 16 Softly place the SYLVANIA Roadsight Mirror Dash Camera onto the front of your OEM rear view mirror and use the 2 Rubber Mounting Straps to hold it in place. To power the device and charge the battery, only use the included Mini USB Power Cable. Connect the Mini USB Power Cable to the top of the mirror dash camera.
  • Page 17 Plug the Camera Aux Power Cable into the 12V power socket. When the vehicle’s engine starts, the device turns on automatically. Travel the road with assurance.

  • Page 18: Wiring Rear Camera

    6. Wiring Rear Camera Option 2: Option 1: Splice Into Back No Splicing Up Light Back Up Camera View w/ Finger Swipe Automatically Switches Display to Back up View Back Up Guidance Lines Requires Splicing into Back Up Light Travel the road with assurance.

  • Page 19: Wiring Back Up Camera - Option

    7. Wiring Back Up Camera - Option 1 Connect Rear Camera Aux Power Cable to the top of the SYLVANIA Roadsight Mirror dash camera to power the rear camera. Using the included trim removal tool, to tuck rear camera wire to the back of your vehicle. Removing A Pilar to tuck wire inside is optional.
  • Page 20 Leave red cable disconnected as it is not required. With this option you will need to swipe the display screen from left to right to toggle to back up view. Guidance lines will not be available with this setup option. Travel the road with assurance.
  • Page 21 8. Wiring Back Up Camera - Option 2 Connect Rear Camera Aux Power Cable to the top of the SYLVANIA Roadsight Mirror dash camera to power the rear camera. Using the included trim removal tool, to tuck rear camera wire to the back of your vehicle. Removing A Pilar to tuck wire inside is optional.
  • Page 22 ATTENTION: • Make sure your vehicle and vehicle lighting is off before proceeding. NOT INCLUDED: • It is recommended to use a multimeter (A) to find positive and negative wires. • Detach battery terminal connectors to avoid electrical shock. • Determine the proper splice wire connectors to use for the gauge wire you will be splicing into.
  • Page 23 To enable automatic display switching from forward view camera to rear view camera, you will need to splice the red wire on the rear camera power cable into your positive wire of your vehicle back up lights. Determine the reverse light power wires for your vehicle.
  • Page 24 Once you have determined which wire is the positive wire, use a splice connector to connect your red wire. Turn vehicle on to power up the SYLVANIA Roadsight Mirror dash camera. Put the vehicle in reverse to check rear camera has been installed correctly.

  • Page 25: Placing Rear Camera

    WARNING: If you wish to use the provided screws to permanently install the back up camera, SYLVANIA is not liable for any damages you may cause to your vehicle. Travel the road with assurance.

  • Page 26: Toggle Camera Display From Led Display To Traditional Mirror

    10. Toggle Camera Display From LED Display to Traditional Mirror Press the power button to toggle between the LED display and the standard mirror function. When the display is on, you can toggle between 3 display screens: Forward dash camera field of view Rear camera back field of view (Option 1 wiring) Rear camera with guidance lines (Option 2 wiring) Travel the road with assurance.

  • Page 27: Main Camera Functions

    11. Main Camera Functions File Lock Recording Toggle Indicator Screen Brightness Battery Adjustment Status Dash Camera Date and Time Field of View Adjustment Camera Settings Controls View Saved Files Lock Video Override Record Audio On/Off Take Photo Record On/Off Travel the road with assurance.

  • Page 28: Dash Camera Viewing Angle

    12. Dash Camera Viewing Angle Adjusting the viewing angle can only be done along the vertical axis, so be sure to position the device correctly on the windshield along the horizontal axis as close as possible to the windshield’s center. While pulling or pushing the device in the holder, ensure that the camera captures the image in proportions of 30% sky / 70% road.

  • Page 29: Playback Menu

    13. Playback Menu Press the Playback button to view saved files. ATTENTION: You must take the camera out of video recording mode to access the playback functionality, otherwise you will see this screen. Travel the road with assurance.

  • Page 30: Video Folders

    14. Video Folders After clicking the Playback button, you are taken to the saved video files. Level 1 Go to Saved Image Files Toggle between file folder pages Go to Saved Video Files Previous Menu Return to Home Screen Level 2 Folder 2: Rear Dash Camera Folder 1: Forward Dash Camera Travel the road with assurance.
  • Page 31 Level 3 Locked Video File All saved video files are available here. Use the page toggle controls to see more saved videos. Locked video files are saved and stored after a collision is detected. Video File Name Format: VID_20200713_125532 Seconds Military Time Month Year...

  • Page 32: Video Player

    15. Video Player Click any video file to open Video Player. VID_20200207_11230 Play Button Previous Menu Lock/Unlock Video File Delete Current File VID_20200207_11230 Cancel Delete Delete Press to Video File Travel the road with assurance.

  • Page 33: Image Folder

    16. Image Folder After clicking the Playback button, you are taken to the saved video files. Press the Saved Images icon to see saved photos. Level 1 Saved Image Go to Files Level 2 Folder 2: Rear Dash Camera Folder 1: Forward Dash Camera Travel the road with assurance.
  • Page 34 Level 3 Locked Video File All saved image files are available here. Use the page toggle controls to see more saved images. Image File Name Format: IMG001.JPG File Format Image Number Image Acronym Travel the road with assurance.

  • Page 35: Image Viewer

    17. Image Viewer Click any video file to open Image Viewer. Previous Menu Lock/Unlock Image File Delete Current File Cancel Delete Delete Press to Image File Travel the road with assurance.

  • Page 36: Menu Settings

    18. Menu Settings Resolution: Toggle between 1080p and 720p. Loop Recording: Choose to record videos in 1, 3, or 5 minute intervals. Contrast: Adjusts the exposure of the capture image/ video up or down manually. Travel the road with assurance.
  • Page 37 Parking Mode: Choose to record videos in 1, 3, or 5 minute intervals. G-senor: Choose collision detection sensitivity level. Vehicle Formatting: Reformat the micro SD card that is WARNING: inserted in the dash camera. Reformatting will erase all data on SD card. Travel the road with assurance.
  • Page 38 Date & Time: Set Year | Month | Day | Hour | Minute Default: Returns camera settings to default. Parking Monitor: Turns on and off G-Sensor to power up the camera when it is in standby mode once it detects a force to start recording.
  • Page 39 Key Sound: Turns on and off the audible cues when touching buttons on the touch screen. Language: Default is English, but there are options to change to Spanish and French. Motion: Turns on and off motion detection. Travel the road with assurance.
  • Page 40 Version: Displays latest firmware version name. White text that says no SD lets you know how much available space you have on the micro SD card when there is one inserted. Travel the road with assurance.

  • Page 41: Updating Firmware

    19. Updating Firmware SYLVANIA Roadsight Mirror software can be updated. Check regularly for firmware updates to keep camera in best working condition. www.sylvania- Download the firmware file at automotive.com/firmware and extract the file from the archive. Format the memory card and transfer the extracted file to the micro SD memory card.

  • Page 42: Camera Information

    20. Camera Information Power Requirements: ATTENTION! Once there is no external power input, the battery cannot support recording for a long time, please make sure power supply is connected when recording . Input voltage: 5VDC, 1.5A Charging input voltage: 12-24VDC Mini USB Connection for Power Operating Temperatures: Storage temperature: -4˚...
  • Page 43 Forward and Rear Dash Camera Instruction Manual...
