- Page 1 BASIC R O A D S I G H T BASIQUE BÁSICA Dash Camera Caméra-témoin de circulation Cámara Delantera...
- Page 2 WARNING The Dash Cam must not be fitted in a position which obscures the driver’s view of the road ahead. Depending on the country of use, recordings made with this device may be subject to Data Protection Laws. Ensure these are complied with. If the dash cam is to be used in a commercial environment e.g.
-
Page 3: Package Contents
PACKAGE CONTENTS Dash Cam Quick Start Guide Magnetic Mount USB Charging Cable Trim Removal Tool Window Sticker RECORDING GRABANDO NOUS ENREGISTRONS... - Page 4 ATTENTION! Choose the installation location in advance, as the adhesive tape on the mount is of single use. Ensure glass is dirt, dust and grease free. Warm adhesive pad part of mount in hands to ensure strong adhesion to glass. Once mount has been positioned connect dash camera to the magnetic mount.
- Page 5 To power the device and charge the battery, use only the power adapter included. Connect the power cable to the mount, and then plug the USB charger into the vehicles 12v power socket. When the vehicle’s engine starts, the device turns on automatically.
-
Page 6: Adjusting Viewing Angle
ADJUSTING VIEWING ANGLE ATTENTION! Adjusting the viewing angle can only be done along the vertical axis, so be sure to position the device correctly on the windshield along the horizontal axis as close as possible to the windshield’s center. While pulling or pushing the device in the holder, ensure that the camera captures the image in proportions of 30% sky / 70% road. - Page 7 CONFIGURATION Power Button: Press to turn the device on. Press and hold to turn the device off. Menu Button: Use this button to switch between the video, photo and playback. Press this button during recording to take picture. Up Button: Press to move up the menu. In the VIDEO and PHOTO mode, press and hold to zoom in;...
-
Page 8: Photo Mode
PHOTO MODE Stop recording and then press and hold Menu button for 2 seconds to enter Photo Mode. Press Rec to capture image. PLAYBACK MODE When in Photo Mode press and hold the Menu button for 2 seconds to enter Playback Mode. Press the Up and Down button to choose video playback or image viewer. -
Page 9: Installing Microsd Card
INSTALLING microSD CARD Before installing a memory card, make sure the device is turned off. Insert the memory card until it clicks into place. Removing a card: press the card slightly and then remove it from the slot. WARNING! Do not apply excessive force when inserting a memory card to avoid damage to the device. -
Page 10: Turning On/Off
TURNING ON / OFF • When the vehicle ignition is turned ON the dash cam turns on automatically. • To turn the device on manually, press the power button. • To turn the device off press and hold the power button for approx. 3 seconds. -
Page 11: Loop Recording
LOOP RECORDING Insert the microSD card into the memory card slot; the Loop Recording mode is set to 3 minutes as default. When the memory card storage is full, the device will automatically replace the oldest video file with the newest one;... -
Page 12: Emergency Recording
EMERGENCY RECORDING Emergency recording is to protect the current video file from being overwritten and deleted. Emergency recording is activated automatically when the G-sensor triggers (sudden acceleration / deceleration), or at point of collision. Emergency recording is locked automatically to avoid erasing during loop recording. - Page 13 RECORDING PLAYBACK Playback (ensure dash cam recording has stopped). • In the standby mode, press and hold the MENU button to switch between Video & Photo. Video & Photo Mode. • Select the file to view using the Up / Down and Confirm buttons. •...
-
Page 14: Delete Files
DELETE FILES Press the Menu button to enter the submenu (ensure dash cam recording has stopped). Use the Up / Down buttons to select Delete and press the Rec button. Select the option to delete all files/one file, then confirm your choice by following the instructions on the display. -
Page 15: General Settings
GENERAL SETTINGS To access General Settings, press the Menu Button once from the Home screen. Video Resolution: Select required option (the highest option provides the optimum viewing performance). Loop Recording: 3 or 5 minutes Record Audio: OFF / ON Time & Date Stamp: OFF / ON G-Sensor: OFF / LOW / MEDIUM / HIGH Parking Mode: OFF / ON License Plate: OFF / ON... -
Page 16: License Plate
LICENSE PLATE When choosing ON, you will be prompted to enter in your license plate number. The license plate number will display on your recording... -
Page 17: Advanced Settings
ADVANCED SETTINGS To access Advanced Settings, press the Menu Button twice from the Home screen. Screen Saver: OFF / 30 Seconds / 1 Minute / 2 Minute Device Sounds: OFF / ON Language: Select the preferred menu language from the list. Date / Time: Adjust for correct Date and Time. -
Page 18: Blurred Image
FAILURE TO PHOTOGRAPH/RECORD VIDEO Check if there is enough free space on the micro SD card. RECORDING HAS STOPPED Too many video files stored. Only use at least class 10 U1 high-speed micro SD cards by proven manufacturers. When you try to view a photo/play a video file, the “wrong file” message appears. File writing failure due to micro SD card file system error. - Page 19 HANG UP (NO IMAGE, NO BUTTON RESPONSE) Press the RESET button to reboot the device.
-
Page 20: Updating Firmware
UPDATING FIRMWARE Download the firmware file at www.sylvania-automotive.com/firmware and extract the file from the archive. Format the memory card and transfer the extracted file to the micro SD memory card. Insert the memory card with the downloaded file into the dash cam slot. - Page 21 FEATURES STEALTH 1440P 140° 128GB 20 HRS Greatest Image Full HD at 30 FPS Field of View Memory Size* Record Quality Time** 1296P 130° 64GB 12 HRS Most Features Full HD at 30 FPS Field of View Memory Size* Record Time** PLUS 1080P 120°...
-
Page 22: Power Requirements
POWER REQUIREMENTS ATTENTION! Once there is no external power input, the battery cannot support recording for a long time, please make sure power supply is connected when recording . Input voltage: 5VDC, 1.5A Charging input voltage: 12-24VDC Mini USB Connection for Power OPERATING TEMPERATURES (all models) Storage temperature: -4˚... - Page 23 PLEASE RECYCLE YOUR SPENT BATTERIES Batteries should not be disposed of in unsorted municipal waste, but separately collected to facilitate the correct treatment and recycling of the substances they contain. The recycling of batteries ensures the recovery of these valuable materials and prevents any potentially harmful effects upon both the environment and human health.
