Setting Up Traffic Priority Schedule Policy - 3Com IntelliJack NJ205 Features Manual

3 C O M ® N J 2 0 5 I N T E L L I J A C K
Figure 8. Traffic priority schedules are individually
configured for each PAN port.
™ S W I T C H — V L A N S & T R A F F I C P R I O R I T I Z AT I O N

Setting Up Traffic Priority Schedule Policy

Use this setting to modify how the switch will receive frames from each queue:
1. Open 3Com Central Configuration Manager
2. From the list of devices, select an NJ205 IntelliJack Switch and then select
You can also highlight and right-click its IP address and select
Hardware Settings
3. Click on the
Policy settings. You should see a window like this:
4. Under Priority Schedule Policy
a) 8,4,2,1 weighted fair queuing (default)
b) Strict Priority Scheme (all queues weighted the same)
5. When all configuration settings are complete, click on the
opens a password-prompt window. After the password is accepted a screen will
appear summarizing the new settings. Click
window.
and select Devices
Property
tab to view and configure the
, choose one of the following:
Apply
OK
to accept and close configuration
from the main menu.
Property
.
from the menu.
Priority Schedule
button, which
11
