950 Series Sealant Gun
For dispensing sealant from caulking tubes. For professional use only.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
More warnings.
Models
Palm Grip Gun:
2.5 oz. (C04074) and 6 oz (C04087)
Pistol Grip Gun:
2.5 oz. (C04076), 6 oz. (C04090), and 12 oz. (C04068)
PROVEN QUALITY. LEADING TECHNOLOGY.
309968D
ENG
Advertisement
Table of Contents
Related Manuals for Graco 950 Series
Summary of Contents for Graco 950 Series
- Page 1 Instructions-Parts 950 Series Sealant Gun 309968D For dispensing sealant from caulking tubes. For professional use only. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. More warnings. Models Palm Grip Gun: 2.5 oz. (C04074) and 6 oz (C04087) Pistol Grip Gun: 2.5 oz.
-
Page 2: Table Of Contents
Air Requirements ......... 4 Parts..............8 Operation ............4 Air-Powered Sealant Guns ......4 Technical Data ........... 10 Manual Sealant Guns........4 Accessories............10 Gun Tip/Nozzle Safety......4 Notes ............... 11 Pressure Relief Procedure......5 Troubleshooting..........6 Graco Standard Warranty........12 309968D... -
Page 3: Warnings
Warnings The following warnings are for the setup, use, grounding, maintenance and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risks. When these symbols appear in the body of this manual refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. -
Page 4: Installation
♦ Air Requirements Air-Powered Sealant Guns Note Read this manual thoroughly before installing The 950 Series, air-powered sealant guns dispense sealant gun. adhesives or sealants from 2.5, 6 or 12 ounce Inspect sealant gun for shipping damage. If polyethylene cartridges. Each size of these damaged, notify the carrier immediately. -
Page 5: Pressure Relief Procedure
Pressure Relief Procedure 3. Open drain valve (required in your system) having a container ready to catch drainage. 4. Leave drain valve open until you are ready to dispense sealant again. Note This procedure describes how to relieve pressure for the sealant gun. To reduce the risk of serious If you suspect that the nozzle or hose is injury, use this procedure whenever you shut off completely clogged, or that pressure has not... -
Page 6: Troubleshooting
Troubleshooting Problem Cause Solution Gun fails to dispense when trigger Material lodged in nozzle Follow Pressure Relief Procedure, is actuated. page 5 . Clear nozzle of blockage. Material supply, hose, passages, Check material supply settings, clogged hoses, etc. for proper material supply. -
Page 7: Service
Service 3. Remove the trigger (107) and trigger spring (104) from the handle (103). Sealant Gun Reassembly (C04093) Topics Covered in this Chapter ♦ Sealant Gun Body Disassembly (C04093) ♦ Gun Handle Disassembly (C04079) Note ♦ Sealant Gun Reassembly (C04093) •... -
Page 8: Parts
Parts Pistol Grip Guns Included Parts and Quantity Palm Grip Guns C04093 C04079 Retainer (21x) Sealant Included Parts and Quantity Size Part Handle C04093 Retainer (21x) Size Part Body Assembly Retainers Sealant Gun See Retainers Assembly Table, page Body Assembly Table, page 9 C04074 (21a) 1... - Page 9 Retainers Ref. Description Part No. C04077 2–1/2 oz. retainer (zinc plated) C04091 6 oz. retainer (zinc plated) C04069 12 oz. retainer (zinc plated 309968D...
-
Page 10: Technical Data
Technical Data Accessories Data Brand Part No. Inlet Category Connector Maximum working pressure 100 psi (7 MPa, 0.7 bar) Hansen C04038 0.125 ID x 5 ft air hose Outlet port size 1/4 npt(f) with male Q.D. Wetted parts Polyethylene inlet Weight: C04026 0.125 ID x... -
Page 11: Notes
Notes 309968D... -
Page 12: Graco Standard Warranty
Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts.
