Safety Instructions 安全說明 Important Safety Instructions 重要的安全說明 Read all of these instructions before setting up your printer. Also be sure to follow all warnings and 使用印表機之前,請閱讀下列這些指示說明。同時,請務必遵守印表機上所標示的警告訊息和指示。 instructions marked on the printer. Make sure you read the General Information (PDF) before using 使用印表機之前,請務必閱讀一般資訊...
Page 6
設置場所の確認 Choosing a Place for the Printer 選擇放置印表機的位置 Instructions for Placing the Printer ❏ Leave adequate room as shown in the table for setting up the printer. ❏ Choose a flat and stable location that can support the printer weight. SC-S60600L series: about 331 kg SC-S80600L series: about 326 kg ❏...
Page 7
Unpacking 梱包内容の確認 清點配件 ~ は、セットアップでは使用しません。使い方や詳細は、 『操作ガイド』 (冊子)または、 『ユーザーズガイド』 (オンラインマニュアル ) をご覧ください。 A to F are not used during setup. For information on using the printer and more details, see the "Operator's Guide" (booklet) or the "User's Guide" (online manual). 安裝時不會用到項目 A 至 F 。關於如何使用印表機及詳細說明,可查看〝操作說明〞 ( 紙本手冊...
Page 8
梱包内容の確認 Unpacking 清點配件 イラストは、大容量インクサーバー 2(SC-S80650L 用)です。お使いの機種によりインクトレイの数が異なります。 The illustrations show Bulk Ink Solution 2 for SC-S80600L Series printers. The number of ink trays varies with the model. SC-S80670L 插圖所示的是適用於 印表機的大容量供墨系統 。墨盤的數量因機型而異。...
Page 9
梱包内容の確認 Unpacking 清點配件 SC-S60650L には外付け乾燥ファンユニットが付属します。 梱包内容や取り付け方は、外付け乾燥ファンユニットに付属のマニュアルをご覧ください。 SC-S60600L series printers come with an additional print drying system. See the additional print drying system manual for information on installation and package contents. SC-S60670L 印表機有一個附加乾燥系統。關於安裝和包裝內容的說明,請查看附加乾燥系統的使用手冊。 本製品の組み立て作業は、梱包用シート、梱包材、同梱品を作業場所の外に片付けてから行ってください。 Caution: Before assembling the printer, clear the work area by putting away the removed packing materials and bundled items. 注意:...
Page 10
組み立て Assembly 組裝 スタンド スタンドの組み立て作業は 3 人で行うことをお勧めします。 It is recommended to assemble the stand by a group of Stand three. 腳架 建議三人一起組裝腳架。 [ 1 ] [ 2 ] [ 3 ] [ 4 ] [ 5 ]...
Page 11
組み立て Assembly 組裝 [ 6 ] [ 7 ] プリンターの取り付け Printer Installation 安裝印表機 [ 1 ] 必ず固定した状態で本機をお使いください。本機を移動するときはキャスターのロックを外してください。 Before using the printer, be sure the stand is fixed in place. When moving the printer unlock the casters. 使用印表機之前,請確認腳架已固定到位。當要搬動印表機時,請解開腳輪的鎖定。...
Page 12
組み立て Assembly 組裝 [ 2 ] [ 3 ] [ 4 ] 本製品は重いので、1 人で運ばないでください。 開梱や移動の際は 8 人以上で運んでください。 Caution: When carrying the printer, use at least eight persons. 注意: 搬運印表機至少需要 人。...
Page 14
組み立て Assembly 組裝 [ 10 ] 廃インクボトルの蓋は、廃インクを廃棄するときに必要です。捨てずに保管しておいてください。 The lid of the Waste Ink Bottle is required when disposing of the waste ink. Keep the lid. Do not throw it away. 處理廢墨時需要使用廢墨桶的蓋子。請收好蓋子。切勿丟棄。 [ 11 ] [ 12 ] あらかじめ貼られている英語ラベルの上に、付属の日本語 ラベルを貼り付けてください。 Place the caution label for your language over the English label.
Page 15
組み立て Assembly 組裝 自動巻取りユニット Auto Take-up Reel Unit 自動收紙單元 自動巻取りユニットは、2 人で 2 本のバーを右図のように持って運んでください。 Carry the Auto Take-up Reel Unit using two persons, each holding the two bars as shown in the figure on the right. 搬運自動收紙單元需要兩人,請如右圖所示,各自緊握兩根長桿。 [ 1 ] [ 2 ]...
Page 16
組み立て Assembly 組裝 [ 3 ] [ 4 ] 側のネジは、 パイプを押さえながら締めてください(右 図) 。続いて、 側のネジを締めてください。 Fasten the screws on the side, keeping the pipes pressed as shown, and then fasten the screws on the side. 鎖緊 側的螺絲,繼續壓住管子 ( 如圖所示 ),然 後鎖緊 側的螺絲。...
Page 18
組み立て Assembly 組裝 メディア搬送ユニット Media Feeding Unit 材料進紙單元 ❏ メディア搬送ユニットは、右図のように 2 人で 2 本のバーを持って運んでください。 ❏ 取り付ける前に、メディア搬送ユニットから紙管を取り外してください。取り外し た紙管は、巻き取り紙管として使いますので捨てずに保管してください。 ❏ Two people should hold the two bars when carrying the Media Feeding Unit. ❏ Remove the roll core from the Media Feeding Unit before installing. Do not throw this away as it will be used as the roll core for the new media.
Page 19
組み立て Assembly 組裝 [ 3 ] [ 4 ] 側のネジは、パイプを押さえながら締めてください(右 図) 。続いて、 側のネジを締めてください。 Fasten the screws on the side, keeping the pipes pressed as shown, and then fasten the screws on the side. 鎖緊 側的螺絲,繼續壓住管子 ( 如圖所示 ),然後 鎖緊 側的螺絲。 [ 1 ] ケーブル類の接続...
Page 21
組み立て Assembly 組裝 外付け乾燥ファンユニット * に付属のマニュアルを参照し て、取り付けてください。 外付け乾燥ファン Install the additional print-drying system * as described in the manual supplied with the system. Additional Print Drying 請按照附加乾燥系統內附手冊中的說明安裝附加乾燥 系統 * 。 System *❏ SC-S60650L は標準添付。 SC-S80650L はオプション。 附加乾燥系統 * Supplied with SC-S60600L series printers; available as an option for SC-S80600L series printers.
Page 22
組み立て Assembly 組裝 [ 1 ] [ 2 ] [ 3 ] [ 4 ] 必ず、固定用ワイヤーをプリンターの脚の正面と背面にネジで固定 してお使いください。固定用ワイヤーでつながずに、インクユニッ トをプリンターに接続してからインクユニットを動かすと、イン クチューブが破損するおそれがあります。 Be sure to secure the restraining wire to front and back of the printer leg using screws. If the ink unit is not secured with the restraining wire, the ink tube may be damaged if the ink unit is moved while the ink unit is connected.
Page 24
組み立て Assembly 組裝 [ 11 ] [ 12 ] [ 13 ] [ 14 ] [ 1 ] [ 2 ] 電源ケーブルの接続 AC100V 以外の電源は使用しな いでください。 Connecting the Power Cable Use only the type of power source Warning: indicated on the printer’s label. 連接電源線...
Page 25
組み立て Assembly 組裝 水準器が右図の OK の状態になっていることを確認して次 項に進んでください。 のときは、床面が水平ではありません。本機はアジャス ターを調整し、機体を水平に補正できます。 アジャスターを調整後は、直近のキャスターが床から浮い ていることを推奨します。 Check that the status of the levels are OK as shown in the illustration before moving to the next step. indicates that the status of the printer is not level. You can adjust the printer's level by using the adjusters.
初回設定 Initial Setup 初始化設定 初めて本機の電源を入れると初回設定が始まります。表示言語を選択して以降は画面の指 示に従って日時と単位を設定します。 SC-S80650L は、続いてカラーモードを選択します。ここで選択したカラーモードは後 から変更できます。カラーモードの変更方法は、 『ユーザーズガイド』 (オンラインマニュ 表示環境の設定 アル)をご覧ください。 Display Settings Initial setup begins when the printer is turned on for the first time. Choose a language and follow the on-screen instructions to set the clock and choose units of measurement. Users of the SC-S80600L series will then be prompted to choose a color mode.
Page 27
初回設定 Initial Setup 初始化設定 ヘッドクリーニング中およびインク充填中は、次の注意事項を守ってください。注意事項を守らないと、作業のやり直しが発生して通常よりもインクを多く消費することがあります。 ❏ 電源コードをコンセントから抜いたり、電源を切ったりしないでください。 ❏ プリンター背面のインクコネクターロックレバーを操作しないでください。 ❏ 画面の指示以外の操作は行わないでください。 Observe the following precautions when cleaning the head and charging it with ink, as otherwise this step may have to be repeated, increasing the amount of ink consumed. ❏ Do not disconnect the power cable from the outlet or turn off the power. ❏...
Page 28
初回設定 Initial Setup 初始化設定 [ 4 ] インクパックとインクユニットのラベルの色が合っていることを確認してトレイを奥まで押し込みます。 After confirming that the colors of the labels on the ink supply unit and ink unit match, slide the tray in until it contacts the back of the slot. 確認供墨單元和墨水單元上的標籤顏色一致後,將墨盤推入,直至其接觸到插槽後部。 9 色 クリーニングインクパック...
Page 29
初回設定 Initial Setup 初始化設定 ワイパーユニットの装着 操作パネルの画面に[ワイパーユニットなし]と表示されたら以下の手順でワイパーユニットを装着してください。 Installing the Wiper Unit If the control panel displays the message Wiper Unit Out, follow the steps below to install the supplied wiper unit. 若控制面板上顯示, 〝Wiper Unit Out〞訊息,請依照下列步驟安裝刷具單元。 安裝刷具單元 [ 1 ] [ 2 ] [ 3 ] [ 4 ] 以降は、画面の指示に従ってインク充填を完了させてください。...
No CD/DVD drive インターネットブラウザーで epson.sn と入力してから、お 無 / 光碟機 使いの製品名を入力して をクリックします。 ソフトウェアディスク / Windows Software Disc/ Enter “epson.sn” and the printer model name into a web browser 軟體光碟片 and click “epson.sn” 請在網頁瀏覽器中輸入 和印表機機型名稱並按一下 。 [ 2 ] [ 3 ] ダウンロードしたインストーラーを実行します。...
Page 31
請依照螢幕上的操作說明,完成安裝步驟。 Windows Epson❏ Edge❏ Print をお使いのときは、 引き続き次項をご覧になりインストール してください。 Users of Epson Edge Print can now install it as described in the following section. Epson Edge Print 的使用者現在即可按照 以下說明進行安裝。 ❏ 上 の 画 面 が 表 示 さ れ た ら、 発 行 元 が...
Page 32
Epson Edge Print のインストール イブをご用意ください。 Installing Epson Edge Print Install Epson Edge Print to the computer to which you installed the basic software. If your computer is not equipped with a built-in disk drive, connect an external drive. 安裝 Epson Edge Print Epson Edge Print 將...
Page 33
Launch Epson Edge Print using either of the following two methods: How to Start Epson Edge Print ❏ Double-click the shortcut icon on the desktop. ❏ Click the Windows start button and select All Programs > Epson Software > Epson Edge Print. 如何啟動 Epson Edge Print Epson Edge Print 使用下列其中一種方式啟動...
Page 34
接続とインストール Installing the Software 安裝軟體 ネットワーク接続のときは、続けてネットワーク設定を保護するためのパスワードの設定を行います。 管理者パスワードは忘れないように管理してください。忘れたときは、 『ユーザーズガイド』 (オンラインマニュアル )「困ったときは」 パスワードの設定(ネットワークのみ) を参照して対処してください。 In a network connection, continue by setting a password for protecting the network settings. Setting a Password (Networks Only) Do not forget the administrator password. For information on what to do if you forget the password, see “Problem Solver” in the User’s Guide (online manual).
Page 35
接続とインストール Installing the Software 安裝軟體 [ 3 ] 任意のパスワードを設定して、Web ブラウザを終了します。 Set your desired password and then close the Web browser. 設定您想要的密碼,然後關閉網頁瀏覽器。...
