Digital Video Camcorder
SC-D453/D455/D457
AF
Auto Focus
CCD
Charge Coupled Device
LCD
Liquid Crystal Display
Owner's Instruction Book
Before operating the unit, please read this
Instruction Book thoroughly, and retain it for
future reference.
US PATENT 4415844
ENGLISH
