A Series Ethernet
Interface Module
AJ71E71N3-T, A1SJ71E71N3-T
AJ71E71N-B5, A1SJ71E71N-B5
AJ71E71N-B2, A1SJ71E71N-B2
Thank you for buying the Mitsubishi general-purpose programmable
controller MELSEC-A Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
© 2004 MITSUBISHI ELECTRIC CORPORATION
User's Manual
MODEL
AJ71E71N-U-HW
MODEL
CODE
IB (NA)-0800308-C(1112)MEE
(Hardware)
13JP67
Advertisement
Table of Contents
Related Manuals for Mitsubishi MELSEC A Series
Summary of Contents for Mitsubishi MELSEC A Series
- Page 1 User’s Manual (Hardware) AJ71E71N3-T, A1SJ71E71N3-T AJ71E71N-B5, A1SJ71E71N-B5 AJ71E71N-B2, A1SJ71E71N-B2 Thank you for buying the Mitsubishi general-purpose programmable controller MELSEC-A Series Prior to use, please read both this manual and detailed manual thoroughly and familiarize yourself with the product. MODEL AJ71E71N-U-HW...
- Page 2 SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. In this manual, the safety precautions are classified into two levels: "...
- Page 3 [Design Precautions] CAUTION When laying the control wire or communication cable, do not bundle with or place near main circuit or power line. Keep them at least 100 mm (3.94 in.) away from such cables. Noise may cause erroneous operation. [Installation Precautions] CAUTION Use the PLC in the environment given in the general specifications section of...
- Page 4 [Wiring Precautions] CAUTION Do not connect the AUI cable when the module installation station's power is turned on. Perform correct pressure-displacement, crimp-contact or soldering for external wire connections using the tools specified by the manufactures. Incorrect connection may cause short circuits, fire or malfunction. Attach connector to the module securely.
- Page 5 [Startup and Maintenance Precautions] WARNING Do not touch the terminals while the electricity is on. Doing so could cause erroneous operation. Make sure to switch all phases of the external power supply off before cleaning or re-tightening screws. If you do not switch off the external power supply, it will cause failure or erroneous operation of the module.
- Page 6 [Operating Precautions] WARNING Do not write data in the “system area” in the buffer memory of the special function module. Also, of the output signals directed to the special function module from the PLC CPU, do not output (switch on) the signals that are “use-prohibited”. If data is written to the ”system area”...
- Page 7 CONDITIONS OF USE FOR THE PRODUCT (1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; and...
- Page 8 PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.
- Page 9 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
-
Page 10: Table Of Contents
CONTENTS 1. OVERVIEW ....................1 2. PERFORMANCE SPECIFICATIONS ............. 2 3. SETTINGS AND NAMES OF EACH PART ........... 6 4. LOADING AND INSTALLATION ..............10 4.1 Handling Precautions ................10 4.2 Installation Environment ................. 10 5. CONNECTION TO A NETWORK ..............11 5.1 Connecting to the 10BASE-T (AJ71E71N3-T, A1SJ71E71N3-T) ............ - Page 11 (13JR45) COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES (1) Method of ensuring compliance To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated into other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals.
-
Page 12: Overview
1. OVERVIEW This manual explains how to install the following Ethernet interface modules (abbreviated as E71 hereafter) for A series PLC CPU and how to wire them with external devices. After unpacking E71, verify that the following parts are contained. Model name Product name No. -
Page 13: Performance Specifications
2. PERFORMANCE SPECIFICATIONS The performance specifications of E71 is shown below. See CPU module user's manual to be used for E71 general specifications. Specifications AJ71E71N3-T Item A1SJ71E71N3-T 10BASE-T Data transmission 10 Mbps speed Communication mode Half-duplex Transmission method Base band Maximum distance —... - Page 14 Specifications AJ71E71N-B5 AJ71E71N-B2 Item A1SJ71E71N-B5 A1SJ71E71N-B2 10BASE5 10BASE2 Data transmission 10 Mbps speed Communication mode Half-duplex Transmission method Base band Maximum distance 2500 m (8202.10 ft.) 925 m (3034.77 ft.) Transmission between nodes specifications Maximum segment 500 m (1640.42 ft.) 185 m (606.96 ft.) length Maximum number of...
- Page 15 The weight of the A1SJ71E71N-B5 is 0.19kg (0.42lb.) when the hardware version is "A". The weight of the A1SJ71E71N-B2 is 0.20kg (0.44lb.) when the hardware version is "B" or earlier.
- Page 16 Notes (1) Each item in the transmission specifications gives supplementary explanation. • When connected by 10BASE2, 10BASE5 Segment length Transceiver Node Terminator Repe- Repe- ater ater Node Node Maximum distance between nodes Node Node • When connected by 10BASE-T Maximum 100 m Cascade connection (328.08 ft.) is a maximum of 4 stages...
-
Page 17: Settings And Names Of Each Part
3. SETTINGS AND NAMES OF EACH PART AJ71E71N3-T AJ71E71N-B5 AJ71E71N-B2 (*1) Side view indicated by arrow A A1SJ71E71N3-T A1SJ71E71N-B5 A1SJ71E71N-B2 (*1) The LED provided on the connector does not light up. - Page 18 Designation Contents Display LED Refer to (1) Operation mode setting switch Refer to (2) Exchange condition setting Refer to (3) switch 10BASE-T connector (RJ45) Connector for connecting the E71 to the 10BASE-T. Lamp for verifying if power is being supplied to the transceiver.
- Page 19 Remarks The order of the display LEDs is shown below. AJ71E71N3-T,AJ71E71N-B5, A1SJ71E71N3-T,A1SJ71E71N-B5, AJ71E71N-B2 A1SJ71E71N-B2 (2) Operation mode setting switch setting Set the E71 operation mode. (Usually set to on-line) Operation mode Setting Setting Setting contents setting switch number designation Performs exchange with remote node in the On-line normal operation mode.
- Page 20 (3) Communications exchange condition setting switch setting Set the conditions for data communication with other nodes. Communications exchange condition Switch Setting designation Setting contents setting switch Selects the line processing when the TCP Line processing ULP time out error occurrence. (*1) selection during Close the circuit.
-
Page 21: Loading And Installation
4. LOADING AND INSTALLATION The following is explanations of the handling precautions and installation environment which is common to modules when handling E71 from unpacking to installation. For the details of loading and installation of the module, refer to User's Manual of CPU module to be used. -
Page 22: Connection To A Network
5. CONNECTION TO A NETWORK The following is an explanation of the connection method of the E71 to the 10BASE-T, 10BASE5 or the 10BASE2. Point (1) Installation procedures of the network require sufficient safety measures. For the execution of such operations as terminal processing of connection cable, trunk line cable etc., please consult with a trained professional. -
Page 23: Connecting To The 10Base-T (Aj71E71N3-T, A1Sj71E71N3-T)
5.1 Connecting to the 10BASE-T (AJ71E71N3-T, A1SJ71E71N3-T) <Connection procedure> 1) Connect the twisted pair cable and the hub. 2) Connect the twisted pair cable to the E71. For AJ71E71N3-T 5.2 Connecting to the 10BASE5 (AJ71E71N-B5, A1SJ71E71N-B5) <Connection procedure> (*1) 1) Slide the retainer toward the direction A Supply power for transceiver as shown in the figure. -
Page 24: External Dimensions
6. EXTERNAL DIMENSIONS (1) AJ71E71N3-T (*1) 37.5 (Unit: mm (in.)) (0.17) (4.17) (1.48) When connecting the twisted pair cable, make the bend radius (R1: scale value) in the vicinity of the connector to (cable outside diameter × 4) or more. (2) AJ71E71N-B5 (*2) 37.5... - Page 25 (3) AJ71E71N-B2 (2.20) 37.5 (Unit: mm (in.)) (0.17) (4.17) (1.48) (4) A1SJ71E71N3-T (*3) 34.5 (Unit: mm (in.)) (0.26) (3.70) (1.36) When connecting the twisted pair cable, make the bend radius (R1: scale value) in the vicinity of the connector to (cable outside diameter × 4) or more.
- Page 26 (5) A1SJ71E71N-B5 (*4) 34.5 (Unit: mm (in.)) (0.26) (3.70) (0.30) (1.36) When connecting the AUI cable, make the bend radius (R2: scale value) in the vicinity of the connector to (cable outside diameter × 4) or more. (6) A1SJ71E71N-B2 (2.20) 34.5 (Unit: mm (in.)) (0.26)
- Page 27 MEMO...
- Page 28 MEMO...
- Page 29 MEMO...
- Page 30 WARRANTY Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
