Page 3 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 4: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Operation of Reading this manual ....12 each component How to search......13 Pictorial index ......14 3-1. Key information Keys........102 For safety and security Side doors ......110 3-2. Opening, closing and locking the doors 1-1.
Page 5 Opening the fuel tank cap........242 4-5. Using the driving 4-1. Before driving support systems Driving the vehicle..... 176 Toyota Safety Sense P..245 Cargo and luggage.... 186 PCS (Pre-Collision Vehicle load limits ..... 191 System) ......254 Trailer towing..... 192 LDA (Lane Departure Dinghy towing....
Page 6 TABLE OF CONTENTS 5-3. Using the storage Interior features features List of storage features ..360 • Glove box ......361 5-1. Using the air conditioning system • Console box ....361 and defogger • Cup holders ....362 Manual air conditioning • Auxiliary box ....364 system......
Page 7 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers...462 the vehicle exterior..392 If your vehicle has to be Cleaning and protecting stopped in an the vehicle interior... 395 emergency.......463 If the vehicle is trapped in 6-2.
Page 8 TABLE OF CONTENTS Vehicle specifications For owners 8-1. Specifications Reporting safety defects for U.S. owners ......560 Maintenance data (fuel, oil level, etc.) ..520 Seat belt instructions for Canadian owners Fuel information ....530 (in French)........561 Tire information ....533 SRS airbag instructions 8-2.
Page 9 Index What to do if... (Troubleshooting) ....574 Alphabetical index...... 579 For vehicles with a audio/navigation system, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL” for information regard- ing the audio/navigation system.
Page 10: For Your Information
Also, remodeling like this will have an effect on advanced safety equipment such as Toyota Safety Sense P and there is a danger that it will not work properly or the danger that it may work in situations where it should not be working.
Page 11 • Operation status of the driving assist systems • Images from the cameras Your vehicle is equipped with cameras. Contact your Toyota dealer for the location of recording cameras. The recorded data varies according to the vehicle grade level and options with which it is equipped.
Page 12 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 13 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 579 Searching installation ■ position • Pictorial index....P. 14 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 574 Searching by title ■ • Table of contents .....P. 2...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 110 Locking/unlocking .
Page 17 Pictorial index Tires ......... . P. 422 Tire size/inflation pressure .
Page 18 Pictorial index ■ Instrument panel Engine switch....... . . P. 209, 212 Starting the engine/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 90 Display ..........P. 90 When the warning messages are displayed .
Page 20 Pictorial index ■ Switches Outside rear view mirror switches ....P. 160 Instrument panel light control dial ..... P. 89 Automatic High Beam switch .
Page 21 Pictorial index USB port Seat heater/ventilator switches ..... P. 355 Power outlets ........P. 378 Front-wheel drive control lever .
Page 22 Pictorial index Audio remote control switches Talk switch Meter control switches ......P. 91 Cruise control switch Dynamic radar cruise control .
Page 23 Pictorial index ■ Interior SRS airbags ........P. 35 Floor mat .
Page 24 Pictorial index Inside rear view mirror ......P. 158 Sun visors ........P. 372 Vanity mirrors.
Page 25 Pictorial index Back door handles....... . . P. 132 Luggage compartment lights ......P. 133 Back door strap .
Page 26 Pictorial index...
Page 27: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......35 Front passenger occupant classification system ..46 Safety information for children ......52 Child restraint systems..53 Installing child restraints..
Page 28: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 29 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 30: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust angle seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 31 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 158, 160) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 32: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 33 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.
Page 34 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 35 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 36 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 37: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 38 1-1. For safe use SRS airbag system components Side airbags Front passenger’s seat belt buckle switch “AIR BAG ON” and “AIR BAG OFF” indicator lights Front passenger occupant classification system (ECU Curtain shield airbags and sensors) Front passenger airbag Side impact sensors (rear) Knee airbags SRS warning light Side impact sensors (front...
Page 39 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 42 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger's seat.
Page 43 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 44 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 45 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 47 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 48: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag, front passenger knee airbag, and front passenger's seat belt pretensioner.
Page 49 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Devices Front passenger knee airbag...
Page 50 1-1. For safe use Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Front passenger knee airbag Devices Activated Front passenger's seat belt pretensioner deactivated...
Page 51 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light On or flashing Front passenger airbag Deactivated Devices Front passenger knee airbag...
Page 52 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 53 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 54: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 55: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 56 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/con- Forward facing  Convertible   vertible seat seat Booster seat ...
Page 57 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 58 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 59: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH (Lower Anchors and Tethers for Children) anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH system.
Page 60 1-1. For safe use Vehicles without third row seats  Anchor brackets (for top tether strap) An anchor bracket is provided for each rear seat. Vehicles with third row seats  Anchor brackets (for top tether strap) An anchor bracket is provided for each second row seat.
Page 61 1-1. For safe use Installation with LATCH system (rear/second row seats only) Installing on the rear seats (vehicles without third row seats) ■ Fold the seatback while pull- seatback angle adjustment lever. Return the seatback and secure it at the first lock position.
Page 62 1-1. For safe use Type B  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the...
Page 63 1-1. For safe use Type A  Latch the hooks of the lower straps onto LATCH anchors. If the child restraint has a top tether strap, the top tether strap should latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the...
Page 64 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 65 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 66 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 67 1-1. For safe use Booster seat ■ Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 68 1-1. For safe use Child restraint systems with a top tether strap Secure the child restraint sys- tem using the seat belt or the lower anchors, and remove the head restraint. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 69 1-1. For safe use ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. WARNING ■...
Page 70 1-1. For safe use WARNING ■ When installing a child restraint system ● Vehicles with third row seats: When using the LATCH anchors for a child restraint system, move the seat as far back as possible, with the seatback close to the child restraint system. ●...
Page 71: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 72: Emergency Assistance Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada.
Page 73 A variety of subscription terms are available for purchase. Contact your Toyota dealer, call the following appropriate Customer Experi- ence Center or push the “SOS” button in your vehicle for further subscription details.
Page 74 Safety Connect is active and in use. ● Safety Connect is available beginning Fall 2009 on select Toyota models (in the contiguous United States only). Contact with the Safety Connect response center is dependent upon the telematics device being in operative...
Page 75 Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Emergency Assistance Button (“SOS”) ■...
Page 76 For a description of the Enhanced Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 77 1-2. Emergency assistance ■ Certification for Safety Connect...
Page 78: 1-3. Theft Deterrent System
1-3. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 79 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system (vehicles without a smart key system) For vehicles sold in the U.S.A.  For vehicles sold in Canada ...
Page 80 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system (vehicles with a smart key system) For vehicles sold in the U.S.A.  For vehicles sold in Canada  WARNING ■ Certifications for the engine immobilizer system Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 81: Alarm
1-3. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 82 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 83: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......82 Gauges and meters .... 88 Multi-information display ..90...
Page 84: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 85 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Slip indicator (P. 475) light (P. 474) (U.S.A.) Brake system warning Four-wheel drive indica- light (P. 474) tor light (P. 476) (Canada) (if equipped) High coolant tempera-...
Page 86 There may be a malfunction in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : This light flashes to indicate a malfunction.
Page 87 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “TRAC OFF” indicator (P. 223) (P. 322) 1, 2 Headlight indicator Slip indicator (P. 321) (P. 225) (U.S.A.) Tail light indicator VSC OFF indicator (P.
Page 88 There may be a malfunction in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : This light flashes to indicate that the system is operating.
Page 89 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 90: Gauges And Meters
2. Instrument cluster Gauges and meters The displayed content may differ depending on the type of meter. Tachometer Displays the engine speed in revolutions per minute Engine coolant temperature gauge Displays the engine coolant temperature Multi-information display Presents the driver with a variety of vehicle data (P. 90) Fuel gauge Displays the quantity of fuel remaining in the tank Speedometer...
Page 91 2. Instrument cluster Changing the display Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the button will reset the trip meter. Instrument panel light control The brightness of the instrument panel lights can be adjusted. Brighter Darker ■...
Page 92: Multi-Information Display
2. Instrument cluster Multi-information display Summary of functions The multi-information display presents the driver with a variety of driv- ing related data, such as the current outside temperature. The multi- information display can also be used to change the display settings and other settings.
Page 93 2. Instrument cluster Operating the meter control switches The multi-information display is operated using the meter control switches. Scroll screens , change the displayed content and move the cursor Press: Enter/Set Press and hold: Reset/Display the next screen Press: Displays the screen reg- istered as the top screen When no screen has been regis- tered, the drive information screen...
Page 94 2. Instrument cluster Menu icons Drive information Select to display various drive data. (P. 93) Vehicle information display Select to display the vehicle information. (P. 95) Navigation system-linked display (if equipped) Select to display the following navigation system-linked information. • Route guidance •...
Page 95 2. Instrument cluster Drive information Items displayed can be switched by pressing up and down. After Start ■ Average fuel economy Displays the average fuel con- sumption since the engine was started. Average vehicle speed Displays the average vehicle speed since the engine was started.
Page 96 2. Instrument cluster After Refuel ■ Range Displays the driving range with remaining fuel. Average fuel economy Displays the average fuel con- sumption since the vehicle was refueled. : This distance computed based on your average fuel con- sumption. As a result, the actual distance that can be driven may differ from that displayed.
Page 97 2. Instrument cluster Vehicle information Items displayed can be switched by pressing up and down. Steering angle ■ Displays the direction of the front tires. The tire direction is displayed in 3 stages for both left and right, in accor- dance with the angle of the tire.
Page 98 2. Instrument cluster Setting items ■ ● LDA (Lane Departure Alert) Select to set up LDA. (P. 556) • Alert sensitivity • Sway warning • Sway sensitivity ● PCS (Pre-Collision System) Select to set the following items. (P. 257) • PCS on/off •...
Page 99 2. Instrument cluster Other contents Multi-terrain Select display (if equipped) ■ P. 313 Crawl Control display (if equipped) ■ P. 310 Outside temperature display ■ Displays the outside temperature The temperature range that can be displayed is from -40 °F (-40 °C) to 122 °F (50 °C).
Page 100 ● When “--” or “E” is displayed, the system may be malfunctioning. Take your vehicle to Toyota dealer. ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display.
Page 101 2. Instrument cluster WARNING ■ Caution for use while driving For safety, avoid operating the meter control switches while driving as much as possible, and do not look continuously at the multi-information display while driving. Stop the vehicle and operate the meter control switches. Fail- ure to do so may cause a steering wheel operation error, resulting in an unexpected accident.
Page 102 2. Instrument cluster...
Page 103: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........102 Side doors......110 3-2. Opening, closing and locking the doors Smart key system ..... 118 Automatic running boards ......128 Back door......131 3-3. Adjusting the seats Front seats ......136 Rear seats......
Page 104: 3-1. Key Information
3-1. Key information Keys The keys Vehicles without a smart key system  Master keys Operating the wireless remote con- trol function Valet key Key number plate Vehicles with a smart key system  The following keys are provided with the vehicle. Electronic keys •...
Page 105 Opens the windows and moon roof (press and hold) Sounds the alarm (press and hold) (P. 104) : This setting must be customized at your Toyota dealer. Vehicles with a smart key system  Locks all the doors (P. 110) Unlocks all the doors (P.
Page 106 3-1. Key information Using the mechanical key (vehicles with a smart key system) To take out the mechanical key, push the release button and take the key out. The mechanical key can only be inserted in one direction, as the key only has grooves on one side.
Page 107 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other key (vehicles without a smart key system) or mechanical key (vehicles with a smart key system) and the key number stamped on your key number plate.
Page 108 3-1. Key information ■ Key battery depletion Vehicles with a smart key system  ● The standard battery life is 1 to 2 years. ● If the battery becomes low, an alarm will sound in the cabin when the engine stops.
Page 109 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used (vehicles with a smart key system) The key cylinder rotates freely to isolate inside mechanism.
Page 110 3-1. Key information For vehicles sold in Canada ...
Page 111 When an electronic key is lost (vehicles with a smart key system) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
Page 112: Side Doors
Pressing the button unlocks the driver's door. Pressing the but- ton again within 3 seconds unlocks the other doors. Press and hold to open the win- dows and moon roof. (P. 164, 172) : This setting must be customized at your Toyota dealer.
Page 113 Press and hold to open the win- dows and moon roof. (P. 164, 172) : This setting must be customized at your Toyota dealer. ◆ Turning the key operates the doors as follows: Vehicles without a smart key system ...
Page 114 3-1. Key information ■ Operation signals Vehicles without a smart key system  The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: once; Unlocked: twice) Vehicles with a smart key system  A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 115 3-1. Key information Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 116 3-1. Key information Locking the doors from the outside without a key Move the inside lock button to the lock position. Close the door. Vehicles without a smart key system  The door cannot be locked if either of the front doors is open and the key is in the engine switch.
Page 117 3-1. Key information Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 545. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- mately 12 mph (20 km/h) or higher.
Page 118 3-1. Key information Shift the shift lever to P or N, and press and hold the driver's door lock switch approxi- mately 5 seconds and then release. The shift lever and switch posi- tions corresponding desired function to be set are shown in the following table.
Page 119 3-1. Key information ■ Switching the door unlock function (vehicles with a smart key system) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for about 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 120: Smart Key System
3-2. Opening, closing and locking the doors  Smart key system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ●...
Page 121 3-2. Opening, closing and locking the doors Effective range (areas within which the electronic key is ■ detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) either of the outside front door handles and back door.
Page 122 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
Page 123 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure The engine switch was pressed after the doors were unlocked with the Touch electronic mechanical key. Interior alarm sounds engine The engine switch was once. switch while depressing pressed two consecu- the brake pedal.
Page 124 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
Page 125 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 126 To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. Ask your Toyota dealer for details. ● Setting the electronic key to battery- saving mode helps to reduce key bat- tery depletion.
Page 127 3-2. Opening, closing and locking the doors ■ Certification for the smart key system For vehicles sold in the U.S.A. ...
Page 128 3-2. Opening, closing and locking the doors For vehicles sold in Canada  For vehicles sold in the U.S.A. ...
Page 129 (P. 118) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 130: Automatic Running Boards
3-2. Opening, closing and locking the doors  Automatic running boards The Automatic running boards are linked to the side door opera- tions, extending and retracting when a side door is opened and closed. When a door is opened or closed, the board on the same side extends or retracts.
Page 131 If the Automatic running boards indicator light flashes There may be a malfunction in the Automatic running boards system. Have the vehicle inspected by your Toyota dealer immediately. ■ When snow or mud is attached to the board or the board is frozen The Automatic running boards may not operate correctly.
Page 132 3-2. Opening, closing and locking the doors WARNING ■ Jam protection function Observe the following precautions. Failure to do so may cause serious injury. Never use any part of your body to intentionally activate the jam protection function. The jam protection function may not work depending on the shape of the object that is caught.
Page 133: Back Door
3-2. Opening, closing and locking the doors Back door Unlocking and locking the back door from the outside ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Press the button to unlock the door. Press the button to lock the door.
Page 134 3-2. Opening, closing and locking the doors Unlocking and locking the back door from the inside Locks all the doors Unlocks all the doors Opening the back door from outside the vehicle Raise the back door while pushing up the back door opener switch. Rear step bumper The rear step bumper is intended for rear end protection and easier...
Page 135 3-2. Opening, closing and locking the doors ■ Luggage compartment lights Each luggage compartment light has the following 3 positions: Turns the light off Turns the light on Turns the light on/off linked to back door position If the luggage compartment lights remain on, the lights will go off automati- cally after 20 minutes.
Page 136 3-2. Opening, closing and locking the doors WARNING ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 137 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
Page 138: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Power seat  Seat position adjustment Vertical height adjustment switch switch (driver’s side only) Seatback angle adjustment Lumbar support adjustment switch switch (driver’s side only) Seat cushion (front) angle adjustment switch (driver’s side only) Manual seat ...
Page 139 3-3. Adjusting the seats Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward and upward to help reduce the risk of whiplash to the seat occupant. ■...
Page 140 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 141: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedures Vehicles without third row seats  Rear seat ■ Pull up the seatback angle adjustment lever until the lock is released.
Page 142 3-3. Adjusting the seats Vehicles with third row seats  Second row seats ■ Seat position adjustment lever Seatback angle adjustment lever Third row seats ■ The third row seats do not have a seat adjustment function.
Page 143 3-3. Adjusting the seats Folding down the rear seats (vehicles without third row seats) Before folding down the rear seats ■ Adjust the head restraints to the downmost position. Fold down head restraints. When returning head restraints to their original posi- tions, make sure they are locked securely.
Page 144 3-3. Adjusting the seats Folding down the rear seats ■ Swing the bottom cushions up by pulling the lock release strap. When returning the rear seat cushions to their original posi- tions, make sure they are locked securely. Push the lock release button and fold down the seatbacks.
Page 145 3-3. Adjusting the seats Folding down the second row seats (vehicles with third row seats) Before folding down the second row seats ■ Adjust the head restraints to the downmost position. Stow the second row seat belt buckles. Folding down the second row seats ■...
Page 146 3-3. Adjusting the seats Moving a second row seat for access to the third row seats (vehi- cles with third row seats) Getting in the vehicle (right side only) ■ Pull up the lever and fold down the seatback. The seat will slide forward.
Page 147 3-3. Adjusting the seats Folding down the third row seats (vehicles with third row seats) Before folding down the third row seats ■ Pass the seat belts through the seat belt hangers and secure the seat belt plates. This prevents the shoulder belts from being damaged.
Page 148 3-3. Adjusting the seats From outside  Pull the strap to fold down the head restraint. Pull the lever up. The seat cushion will slide back- ward and the seatback will be unlocked. Fold the seatback down.
Page 149 3-3. Adjusting the seats Returning the third row seats ■ As the seat cushions cannot be pulled forward from outside, this operation can only be performed from inside. Raise the seatbacks to their original positions. Make sure they are locked securely.
Page 150 3-3. Adjusting the seats WARNING ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 151: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory.
Page 152 3-3. Adjusting the seats ■ To stop the position recall operation part-way through Perform any of the following: ● Press the “SET” button. ● Press button “1” or “2”. ● Operate any of the seat adjustment switches (only cancels seat position recall).
Page 153 3-3. Adjusting the seats While pressing the recalled button, press and hold the door lock switch (either lock or unlock) until the buzzer sounds. If the button could not be regis- tered, the buzzer sounds contin- uously approximately seconds. Recall procedure ■...
Page 154 3-3. Adjusting the seats WARNING ■ Seat adjustment caution Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel.
Page 155: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Second seats Vertical adjustment Pull the head restraints up.
Page 156 3-3. Adjusting the seats Third seats (vehicle with third row seats) To use Lift up the head restraint until it locks. To fold Pull the strap to fold the head restraint. ■ Removing the head restraints (except third row seats) Pull the head restraint up while pressing the lock release button.
Page 157 3-3. Adjusting the seats WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 158: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 159 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 160: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 161 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 162: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 163 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when Vehicles without a smart key system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system  The engine switch is in ACCESSORY or IGNITION ON mode. ■...
Page 164: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 165 3-5. Opening, closing the windows and moon roof ■ The power windows can be operated when Vehicles without a smart key system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system  The engine switch is in IGNITION ON mode.
Page 166 (P. 111, 507) ● The power windows can be opened using the wireless remote control. (P. 110) : These settings must be customized at your Toyota dealer. ■ Customization Settings (e.g. key linked operation) can be changed. (Customizable features P. 545)
Page 167 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 168: Power Back Window
3-5. Opening, closing the windows and moon roof Power back window The power back window can be opened and closed using the switch or key. Opening and closing procedures From inside the vehicle  Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 169 3-5. Opening, closing the windows and moon roof From outside the vehicle (vehicles with a smart key system)  Opening (push and hold) Closing (push and hold) This operation can only be per- formed when the electronic key is within the detection range. ■...
Page 170 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 171 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Caution while driving Keep the back door and back window closed while driving. If the back door or the back window is left open, the back door may hit nearby objects while driving or luggage may be unexpectedly thrown out, causing an accident.
Page 172: Moon Roof
3-5. Opening, closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 173 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when Vehicles without a smart key system  The engine switch is in the “ON” position. Vehicles with a smart key system  The engine switch is in IGNITION ON mode. ■...
Page 174 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open reminder function An alarm will sound when the driver’s door is opened with the moon roof not...
Page 175 3-5. Opening, closing the windows and moon roof ■ Customization that can be configured at Toyota dealer Settings (e.g. key linked operation) can be changed. (Customizable features P. 545) WARNING Observe the following precautions. Failure to do so may cause death or serious injury.
Page 176 3-5. Opening, closing the windows and moon roof...
Page 177: Driving
........242 Cargo and luggage ... 186 4-5. Using the driving Vehicle load limits ..... 191 support systems Trailer towing..... 192 Toyota Safety Sense P ..245 Dinghy towing ....208 PCS (Pre-Collision 4-2. Driving procedures System)......254 Engine (ignition) switch...
Page 178: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 212 Driving With the brake pedal depressed, shift the shift lever to D. (P. 218) Release the parking brake. (P. 224) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 179 4-1. Before driving Starting off on a steep uphill Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. ■ Driving in the rain ● Drive carefully when it is raining, because visibility will be reduced, the win- dows may become fogged-up, and the road will be slippery.
Page 180 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 181 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
Page 182 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ●...
Page 183 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 184 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 185 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 186 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 187 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 188: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 189 4-1. Before driving Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) — (Total weight of occupants) Steps for Determining Correct Load Limit — (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 190 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 520) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 191 To use the roof rails as a roof luggage Roof rails carrier, you must fit the roof rails with Cross rails two or more genuine Toyota cross rails or their equivalent. ● When there is no luggage on the roof...
Page 192 4-1. Before driving WARNING ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 193: Vehicle Load Limits
4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): P. 520 Total load capacity means the combined weight of occupants, cargo and luggage.
Page 194: Trailer Towing
To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about addi-...
Page 195 4-1. Before driving Towing related terms GCWR (Gross Combination Weight Rating) ■ The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 196 4-1. Before driving GAWR (Gross Axle Weight Rating) ■ The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR TWR (Trailer Weight Rating) ■ The maximum allowable gross (With brakes) trailer weight.
Page 197 4-1. Before driving Unbraked TWR (Unbraked Trailer Weight Rating) ■ The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. Tongue Weight ■ The load placed on the trailer hitch ball. (P. 197)
Page 198 4-1. Before driving Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (P. 197) ● The gross combination weight must never exceed the GCWR described in the table. (P. 197) ● The gross vehicle weight must never exceed the GVWR indi- cated on the Certification Label.
Page 199 4-1. Before driving GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. GCWR and TWR ■ Trailer Weight Driving system GCWR Rating 11100 lb.
Page 200 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 201 4-1. Before driving Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 202 4-1. Before driving Positions for towing hitch receiver and hitch ball Weight carrying ball position: 50.1 in. (1272 mm) Hitch receiver pin hole position: 43.7 in. (1109 mm) Connecting trailer lights Use the wire harness stored in the rear end under body. Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights.
Page 203 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 204 4-1. Before driving ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before making turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 205 4-1. Before driving ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 206 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 207 4-1. Before driving ● After the trailer swaying has stopped: • Stop in a safe place. Get all occupants out of the vehicle. • Check the tires of the vehicle and the trailer. • Check the load in the trailer. Make sure the load has not shifted.
Page 208 ■ When towing a trailer Toyota recommends trailers with brakes that conform to any applicable fed- eral and state/provincial regulations. ● If the gross trailer weight exceeds unbraked TWR, trailer brakes are required.
Page 209 4-1. Before driving NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 210: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground.
Page 211: Engine (Ignition) Switch (Vehicles Without A
4-2. Driving procedures Engine (ignition) switch (vehicles without a smart key system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START” position to start the engine. Changing the engine switch positions “LOCK”...
Page 212 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (P. 76) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 213 4-2. Driving procedures WARNING ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 214: Engine (Ignition) Switch (Vehicles With A Smart Key System)
4-2. Driving procedures Engine (ignition) switch (vehicles with a smart key system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P.
Page 215 4-2. Driving procedures Stopping the engine Stop the vehicle. Set the parking brake (  P. 224), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that “ACCESSORY” or “IGNI- TION ON” is not shown on the meter. Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal released.
Page 216 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 217 If the engine does not start ● The engine immobilizer system may not have been deactivated. (P. 76) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 218 4-2. Driving procedures WARNING ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 219 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 220: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever Vehicles without a smart key system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 221 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving : To improve fuel efficiency and reduce noises, set the shift lever in the D position for normal driving. : Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges, controls engine braking forces, and prevents unnecessary upshifting...
Page 222 4-2. Driving procedures ■ S mode When the shift range is “3” or lower, holding the shift lever toward “+” sets the shift range to “5”. ■ AI-SHIFT AI-SHIFT automatically selects the optimal gear according to driver perfor- mance and driving conditions. AI-SHIFT automatically operates when the shift lever is in the D position.
Page 223 If the “S” indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 224 4-2. Driving procedures WARNING ■ When driving on slippery road surfaces Be careful of downshifting and sudden acceleration, as this could result in the vehicle skidding to the side or spinning. ■ To prevent an accident when releasing the shift lock Before pressing the shift lock override button, make sure to set the parking brake and depress the brake pedal.
Page 225: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until...
Page 226: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal U.S.A. Canada with your left foot while depress- ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Parking the vehicle P.
Page 227: Operating The Lights
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: Type A  daytime running lights turn on. (P. 228) The side marker, park- ing, tail, license plate, instrument panel lights, daytime...
Page 228 4-3. Operating the lights and wipers Type B  The headlights, parking lights, daytime running lights (P. 228) and so on turn on and off auto- matically (when engine switch is in IGNI- TION ON mode). The side marker, park- ing, tail, license plate, instrument panel lights, daytime...
Page 229 4-3. Operating the lights and wipers Type C  The headlights, parking lights, daytime running lights (P. 228) and so on turn on and off auto- matically (when engine switch is in IGNI- TION ON mode). The side marker, park- ing, tail, license plate, instrument panel lights, daytime...
Page 230 4-3. Operating the lights and wipers ■ Daytime running light system ● Vehicles with a headlight high beam/daytime running lights: The daytime running lights illuminate using the same lights as the headlight high beam and illuminate dimmer than the headlight high beam. ●...
Page 231 4-3. Operating the lights and wipers ■ Automatic light off system (if equipped) Vehicles without a smart key system  ● When the headlights come on: The headlights and tail lights turn off 30 sec- onds after a door is opened and closed if the engine switch is turned to the “ACC”...
Page 232: Automatic High Beam
4-3. Operating the lights and wipers Automatic High Beam The Automatic High Beam uses a camera sensor located behind the upper portion of the windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc., and automatically turns the high beams on or off as necessary. WARNING ■...
Page 233 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 234 4-3. Operating the lights and wipers ■ Conditions to turn the high beams on/off automatically ● When all of the following conditions are met, the high beams will be turned on automatically (after approximately 1 second): • The vehicle speed is approximately 21 mph (34 km/h) or more. •...
Page 235 4-3. Operating the lights and wipers • When driving in inclement weather (heavy rain, snow, fog, sandstorms, etc.) • When the windshield is obscured by fog, mist, ice, dirt, etc. • When the windshield is cracked or damaged • When the camera sensor is deformed or dirty •...
Page 236: Fog Light Switch
4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Type A  Turns the front fog lights Turns the front fog lights...
Page 237 4-3. Operating the lights and wipers Type B  Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam.
Page 238: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows: Type A  Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation...
Page 239 4-3. Operating the lights and wipers Type B  Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 240 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 241: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Before operating the rear window wiper and washer switch, make sure the back window is completely closed. (P. 166) Operating instructions Operating the switch operates the rear wiper or washer as fol- lows: Type A ...
Page 242 4-3. Operating the lights and wipers Type B  Intermittent window wiper operation Normal window wiper operation Washer/wiper dual oper- ation Washer/wiper dual oper- ation The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operates one more time after a short delay to pre- vent dripping.)
Page 243 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 244: 4-4. Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Turn the engine switch to the “LOCK” position and ensure that all the doors and windows are closed. ●...
Page 245 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 246 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 247: Toyota Safety Sense P
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 248 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Front camera...
Page 249 Do not subject the radar sensor or its surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 250 Do not attach window tint to the windshield. ● Replace the windshield if it is damaged or cracked. After replacing the windshield, the front camera must be recalibrated. Con- tact your Toyota dealer for details. ● Do not allow liquids to contact the front camera. ●...
Page 251 When cleaning the inside of the windshield, do not allow glass cleaner to contact the lens of the front camera. Also, do not touch the lens. If the lens is dirty or damaged, contact your Toyota dealer. ● Do not subject the front camera to a strong impact.
Page 252 4-5. Using the driving support systems ■ Certification For vehicles sold in the U.S.A. ...
Page 253 4-5. Using the driving support systems For vehicles sold in Canada  ■ If a warning message is displayed on the multi-information display A system may be temporarily unavailable or there may be a malfunction in the system. ● In the following situations, perform the actions specified in the table. When the normal operating conditions are detected, the message will disappear and the system will become operational.
Page 254 4-5. Using the driving support systems If the message does not disappear, contact your Toyota dealer. Situation Actions When the area around a cam- era is covered with dirt, mois- Using the wiper and A/C function, ture (fogged up, covered with...
Page 255 If the message does not disappear, contact your Toyota dealer. • When the temperature around the radar sensor is outside of the opera- tional range, such as when the vehicle is in the sun or in an extremely cold environment •...
Page 256: Pcs (Pre-Collision System)
4-5. Using the driving support systems PCS (Pre-Collision System) The pre-collision system uses a radar sensor and front camera to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal collision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pres- sure is increased to help the driver avoid the collision.
Page 257 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 258 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 259 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on (P. 96) of the multi-information display. The system is automatically enabled each time the engine switch is turned to the “ON”...
Page 260 4-5. Using the driving support systems ■ Operational conditions The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high. Each function is operational at the following speeds: ●...
Page 261 4-5. Using the driving support systems ■ Cancelation of the pre-collision braking If either of the following occur while the pre-collision braking function is oper- ating, it will be canceled: ● The accelerator pedal is depressed strongly. ● The steering wheel is turned sharply or abruptly. ■...
Page 262 4-5. Using the driving support systems • When there is a vehicle, pedestrian, or object by the roadside at the entrance of a curve • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge •...
Page 263 4-5. Using the driving support systems • When driving through under objects that may contact the vehicle, such as thick grass, tree branches, or a banner • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead •...
Page 264 4-5. Using the driving support systems • If a vehicle ahead makes an abrupt maneuver (such as sudden swerving, acceleration or deceleration) • When suddenly cutting behind a preceding vehicle • When a vehicle ahead is not directly in front of your vehicle •...
Page 265 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 266: Lda (Lane Departure Alert)
4-5. Using the driving support systems LDA (Lane Departure Alert) Summary of functions When driving on roads with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visi- ble white (yellow) lines with the camera sensor on the upper por- tion of the windshield.
Page 267 4-5. Using the driving support systems Functions included in LDA system ◆ Lane departure alert function When the system determines that the vehicle might depart from its lane, a warning is dis- played on the multi-information display and the warning buzzer sounds to alert the driver.
Page 268 Do not modify the suspension etc. If the suspension etc. needs to be replaced, contact your Toyota dealer. ● Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer.
Page 269 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates and a message is displayed on the multi-information display. Press the LDA switch again to turn the LDA system off.
Page 270 4-5. Using the driving support systems Indications on multi-information display The illustration used is intended as an example, and may differ from the image that is actually displayed on the multi-information display. LDA indicator The illumination condition of the indicator informs the driver of the system operation status.
Page 271 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 272 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 273 The system may not be operating “LDA Malfunction properly.  Have the vehicle inspected at your Visit Your Dealer” Toyota dealer. The operation conditions of the cam- era sensor (temperature, etc.) are not met.  When the operation conditions of the camera sensor (temperature, “Front Camera Unavailable”...
Page 274: Dynamic Radar Cruise Control
4-5. Using the driving support systems Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 275 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings.
Page 276 4-5. Using the driving support systems WARNING ■ Cautions regarding the driving assist systems Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. ●...
Page 277 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 278 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 320 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 279 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 280 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 281 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to the “ON”...
Page 282 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed setting is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 283 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 284 The sensor cannot detect correctly because it is covered in some way. ● Pre-collision braking is activated. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer.
Page 285 ● Pre-collision braking is activated. If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 286 4-5. Using the driving support systems ● When water or snow thrown up by the surrounding vehicles hinders the detecting of the sensor ● When your vehicle is pointing upwards (caused by a heavy load in the luggage compartment, etc.) ●...
Page 287: Intuitive Parking Assist
4-5. Using the driving support systems  Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display and a buzzer. Always check the surrounding area when using this system.
Page 288 4-5. Using the driving support systems Display Multi-information display ■ Front corner sensor opera- tion Rear corner sensor operation Rear center sensor operation...
Page 289 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Multi-information Front and rear corner display Rear center sensor sensor 4.9 ft. (150 cm) to ...
Page 290 4-5. Using the driving support systems Buzzer operation and distance to an obstacle ■ A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously: Approximately 1.2 ft.
Page 291 ■ Intuitive parking assist display When an obstacle is detected while the Toyota parking assist monitor is in use, the warning indicator will appear in the upper part of the screen even if the display setting has been set to off.
Page 292 ● If “Check park sonar system” is shown Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Toyota dealer. ■ Customization that can be configured at Toyota dealer Some functions can be customized. (Customizable features P. 545) ■...
Page 293 When using intuitive parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● The intuitive parking assist operation display flashes, and a beep sounds when no obstacles are detected.
Page 294: Four-Wheel Drive System (Part-Time 4Wd Models)
4-5. Using the driving support systems Four-wheel drive system (part-time 4WD models) Use the front-wheel drive control lever or switch to select the fol- lowing transfer modes: Type A  The four-wheel drive indicator comes on when H4, N or L4 mode is selected.
Page 295 4-5. Using the driving support systems Type B  The four-wheel drive indicator comes on when H4 or L4 mode is selected. H2 (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear.
Page 296 4-5. Using the driving support systems Shifting between H2 and H4 Shifting from H2 to H4 ■ Type A  Reduce vehicle speed to less than 50 mph (80 km/h). Shift the front-wheel drive control lever to H4. Type B ...
Page 297 If the four-wheel drive or low speed four-wheel drive indicator flashes rapidly There may be a malfunction in the four-wheel drive system. Have the vehicle inspected by your Toyota dealer immediately. ■ Four-wheel drive usage frequency You should drive in four-wheel drive for at least 10 miles (16 km) each month.
Page 298: Four-Wheel Drive System (Full-Time 4Wd Models)
4-5. Using the driving support systems Four-wheel drive system (full-time 4WD models) Use the four-wheel drive control switch to select the following transfer modes: H4F (high speed position) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear.
Page 299 4-5. Using the driving support systems Shifting between H4F and H4L Push the “UNLOCK” button and turn the four-wheel drive control switch to H4L or H4F. This can be done at any speed. The center differential lock indica- tor will turn on (H4L) or go off (H4F).
Page 300 4-5. Using the driving support systems Shifting from L4L to H4L ■ Stop the vehicle completely and continue to depress the brake pedal. Shift the shift lever to N. Push the “UNLOCK” button and turn the four-wheel drive control switch to H4L. Maintain this condition until the low speed four-wheel drive indi- cator goes off.
Page 301 If the low speed four-wheel drive indicator or the center differential lock indicator flashes rapidly There may be a malfunction in the four-wheel drive system. Have the vehicle inspected by your Toyota dealer immediately. WARNING ■ Operating the four-wheel drive control switch Never operate the four-wheel drive control switch if the wheels have lost traction.
Page 302: Active Traction Control System
4-5. Using the driving support systems  Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or acceler- ated on slippery road surfaces. System operation ■ Part-time 4WD models: Stop the vehicle, shift the shift lever to N and shift the front-wheel drive control lever into L4.
Page 303 4-5. Using the driving support systems When the active traction control system is operating If all wheels spin, the slip indicator flashes to indicate that the active traction control system has been engaged. ■ When the rear differential is locked (vehicles with a rear differential lock system) The active traction control system is activated only when vehicle speed is less than 4 mph (6 km/h).
Page 304: Auto Lsd System (2Wd Models)
4-5. Using the driving support systems AUTO LSD system (2WD models) The AUTO LSD system aids traction by using the traction con- trol system to control engine performance and braking when one of the drive wheels begins to spin. The system should be used only when one of the drive wheels spinning occurs in a ditch or rough surface.
Page 305 4-5. Using the driving support systems When the AUTO LSD system is operating If the drive wheels spin, the slip indicator flashes to indicate that the AUTO LSD system has con- trolled the spinning of the drive wheels. ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off.
Page 306: Rear Differential Lock System
4-5. Using the driving support systems  Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged sur- face. The rear differential lock system is effective in case one of the rear wheels is spinning.
Page 307 After unlocking the rear differential Check that the indicator goes off. ■ If the rear differential lock indicator flashes rapidly There may be a malfunction in the rear differential lock system. Have the vehicle inspected by your Toyota dealer immediately.
Page 308 4-5. Using the driving support systems WARNING ■ To avoid an accident ● Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or rugged surface. Large steering effort and careful cornering control will be required. ●...
Page 309: Downhill Assist Control System
4-5. Using the driving support systems  Downhill assist control system The downhill assist control system helps to prevent excessive speed on steep downhill slopes. The system will operate when the vehicle is traveling under 15 mph (25 km/h) with the acceler- ator and brake pedals released and the transfer mode is in L4 (part-time 4WD models) or L4L (full-time 4WD models).
Page 310 4-5. Using the driving support systems ■ Operating tips The system will operate when the shift lever is in a position other than P, how- ever to make effective use of the system it is recommended to select a lower shift range.
Page 311 • A motor sound may be heard after the vehicle comes to a stop. ■ System malfunction In the following cases, have your vehicle checked by your Toyota dealer. ● The downhill assist control system indicator does not come on when the engine switch is turned to the “ON”...
Page 312: Crawl Control
4-5. Using the driving support systems  Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Mini- mizes loss of traction or vehicle slip when driving on slippery road surfaces, allowing for stable driving.
Page 313 4-5. Using the driving support systems Speed modes ■ following table shows some typical terrains and the recommended speed modes. Mode Road condition L (Low) Rock, mogul (downhill) and gravel (downhill) Between L and M Mogul (uphill) M (Medium) Between M and H Snow, mud, gravel (uphill), sand, dirt, mogul (uphill) and grass H (High)
Page 314 4-5. Using the driving support systems ■ Automatic system cancelation In the following situations, the system will cease operation and a buzzer will sound to alert the driver. The Crawl Control indicator will flash until the system is turned off completely. ●...
Page 315: Multi-Terrain Select
4-5. Using the driving support systems  Multi-terrain Select The Multi-terrain Select system has 4 terrain modes. When a ter- rain mode is selected in accordance with terrain conditions, engine power and active traction control system is controlled to enhance off-road drivability. Additionally, guidance messages such as transfer mode selection advice are displayed on the multi-information display to assist the driver in operating the vehicle.
Page 316 4-5. Using the driving support systems Multi-terrain Select modes ■ Symbol Mode MUD & SAND LOOSE ROCK MOGUL ROCK...
Page 317 4-5. Using the driving support systems The following table shows some typical terrains and the recom- mended Multi-terrain Select modes. Mode LOOSE MUD & ROCK MOGUL Road ROCK SAND condition Rock Mogul Bump, groove Slope/ V-ditch Uphill/ downhill Riverbed Gravel Bush Deep snow Sand...
Page 318 4-5. Using the driving support systems Selecting modes Press the “ON/OFF” switch. All of the mode indicators will turn on and then off except the indicator for the current mode. The Multi-ter- rain Select indicator on the instru- ment cluster will remain illuminated while this system is enabled.
Page 319 4-5. Using the driving support systems Messages displayed on the multi-information display Depending on switch operation, one of the following messages may appear on the multi-informa- tion display to provide guidance on transfer mode selection etc: Message Details Procedure “Select 4WD” Indicates that the trans- Shift front-wheel...
Page 320 (When pressing Select has been dis- “ON/OFF” switch) abled. Indicates that Multi-ter- “Multi-terrain select not rain Select cannot be available” operated because the Contact your Toyota (When pressing VSC and/or 4WD sys- dealer. “ON/OFF” switch) tem may be malfunc- tioning.
Page 321 ● One of the vehicle systems related to Multi-terrain Select may be malfunc- tioning. Have your vehicle inspected by your Toyota dealer. ● The brake actuator may be at risk of overheating. A buzzer will sound, the “A-TRAC” indicator will go off and the “TRAC OFF”...
Page 322: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 323 4-5. Using the driving support systems ◆ Hill-start assist control Helps to reduce the backward movement of the vehicle when start- ing on an uphill ◆ LSD (Limited Slip Differential) (if equipped) Transfers drive power to the rear tires when front tires spin, and vice versa, in order to improve traction ◆...
Page 324 4-5. Using the driving support systems Disabling the TRAC system (2WD models) If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels. Pressing to turn the system off may make it easier for you to rock the vehicle in order to free it.
Page 325 4-5. Using the driving support systems Turning off TRAC, VSC and Trailer Sway Control systems ■ To turn the TRAC, VSC and Trailer Sway Control systems off, press and hold more than 3 seconds while the vehicle is stopped. The “TRAC OFF” indicator light and the VSC OFF indicator light will come on.
Page 326 4-5. Using the driving support systems Turning off the TRAC system ■ To turn the TRAC system off, quickly press release The “TRAC OFF” indicator light will come on. Press again to turn the system back on. Turning off TRAC, VSC and Trailer Sway Control systems ■...
Page 327 TRAC, hill-start assist control, downhill assist control and crawl control are temporary deactivated. If the indicator light continues to remain on, contact your Toyota dealer. ■ When the VSC or TRAC system is turned off by pressing the VSC off...
Page 328 4-5. Using the driving support systems ■ Sounds and vibrations caused by the ABS, Multi Terrain ABS (if equipped), brake assist, VSC, Trailer Sway Control, TRAC and hill-start assist control systems ● A sound may be heard from the engine compartment when the brake pedal is depressed repeatedly, when the engine is started or just after the vehicle begins to move.
Page 329 4-5. Using the driving support systems WARNING ■ The ABS and Multi Terrain ABS do not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads.
Page 330 The ABS, Multi Terrain ABS, TRAC, VSC and Trailer Sway Control will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 331: Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 332 : The shift lever will be locked if it is attempted to be shifted from P to any other position without depressing the brake pedal. If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately.
Page 333 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain (0.20 in. [5 mm] in diameter) Cross chain (0.20 in. [5 mm] in diameter) Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road.
Page 334 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 335: Off-Road Precautions
4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle feature ●...
Page 336 4-6. Driving tips WARNING ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 337 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 338 4-6. Driving tips WARNING ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 339 4-6. Driving tips NOTICE ■ To prevent water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 340 4-6. Driving tips...
Page 341: Interior Features
Interior features 5-1. Using the air conditioning system and defogger Manual air conditioning system ......340 Automatic air conditioning system ..347 Seat heaters/ seat ventilators....355 5-2. Using the interior lights Interior lights list ....357 • Interior lights ....358 •...
Page 342: System
5-1. Using the air conditioning system and defogger  Manual air conditioning system Air conditioning controls Adjusting the temperature setting ■ To adjust the temperature setting, turn clockwise (warm) or counterclockwise (cool). is not pressed, the system will blow ambient temperature air or heated air.
Page 343 5-1. Using the air conditioning system and defogger Fan speed setting ■ To adjust the fan speed, turn clockwise (increase) or counterclockwise (decrease). Turning the knob to “OFF” turns off the fan. Change the airflow mode ■ To select the air outlets, set to the desired position.
Page 344 5-1. Using the air conditioning system and defogger Defogging the windshield ■ Defoggers are used to defog the windshield and front side win- dows. Set the air outlet selector dial to position. If the recirculated air mode is used, it will automatically switch to outside air mode.
Page 345 5-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected airflow mode. Adjusting the position of and opening and closing the air out- ■ lets Front center outlets Front side outlets ...
Page 346 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer.
Page 347 5-1. Using the air conditioning system and defogger ■ When the outside temperature falls to nearly 32F (0C) The dehumidification function may not operate even when is pressed. ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ●...
Page 348 ■ When repairing/replacing parts of the air conditioning system Have repair/replacement performed by your Toyota dealer. When a part of the air conditioning system, such as the evaporator, is to be replaced, it must be replaced with a new one.
Page 349: Automatic Air Conditioning System
5-1. Using the air conditioning system and defogger  Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Adjusting the temperature setting ■ To adjust the temperature setting, turn clockwise to increases the temperature and turn counterclockwise to...
Page 350 5-1. Using the air conditioning system and defogger Change the airflow mode ■ To change the air outlets, press Other functions ■ ● Switching between outside air and recirculated air modes (P. 349) ● Defogging the windshield (P. 349) ● Defogging the rear window and outside rear view mirrors (P.
Page 351 5-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (the indicator is off) and recirculated air mode (the indicator is on) each time the button is pressed.
Page 352 5-1. Using the air conditioning system and defogger Windshield wiper de-icer (if equipped) ■ This feature is used to prevent ice from building up on the wind- shield and wiper blades. Turns the windshield wiper de- icer on/off The windshield wiper de-icer will automatically turn after...
Page 353 5-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air out- ■ lets Front center outlets Front side outlets   Rear outlets  Direct air flow to the left or right, up or down. Turn the knob to open or close the vent.
Page 354 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer.
Page 355 5-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 356 ■ When repairing/replacing parts of the air conditioning system Have repair/replacement performed by your Toyota dealer. When a part of the air conditioning system, such as the evaporator, is to be replaced, it must be replaced with a new one.
Page 357: Seat Heaters/ Seat Ventilators
5-1. Using the air conditioning system and defogger   Seat heaters /seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: •...
Page 358 5-1. Using the air conditioning system and defogger Seat heaters/ventilators Vehicles with ventilator  Press the knob to release it, and turn the knob to the desired temperature setting. Press the knob to lock it when not in use. Ventilation Heat Vehicles without ventilator ...
Page 359: Using The Interior Lights
5-2. Using the interior lights Interior lights list Rear interior light (P. 358) Front interior light/front personal lights (P. 358) Shift lever light (when the engine switch is in the “ACC” or “ON” position [without a smart key system] or the engine switch is in ACCESSORY or IGNITION ON mode [with a smart key system]) Inside door handle lights (if equipped) Outer foot lights (if equipped)
Page 360: Interior Lights
5-2. Using the interior lights Interior lights Front ■ Turns the lights off Turns the door position on Rear ■ Turns the door position on Turns the light off Turns the light on Personal lights Turns the lights on/off...
Page 361 5-2. Using the interior lights ■ Illuminated entry system Vehicles without a smart key system  The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed. Vehicles with a smart key system ...
Page 362: 5-3. Using The Storage Features
5-3. Using the storage features List of storage features Auxiliary box (P. 364) Cup holders (P. 362) Glove box (P. 361) Pen holder (P. 365) Bottle holders (P. 366) Console box (P. 361) Tissue pocket (P. 365) Coin holder (P. 365) WARNING ●...
Page 363: Glove Box
5-3. Using the storage features Glove box The glove box can be opened by pressing the lock release button and can be locked and unlocked by using the master key (vehicles without a smart key system) or the mechanical key (vehicles with a smart key system).
Page 364: Cup Holders
5-3. Using the storage features Cup holders Front seats Rear seats (without third row   seats) Pull down the rear seat center armrest. Second row seats (with third Third row seats (if equipped)   row seats) Pull down the second row seat center armrest and press down the button on the armrest.
Page 365 5-3. Using the storage features ■ Adjusting the size of the cup holders Front seats  Remove the adapter. Rear seats (without third row seats)  Remove the adapter. WARNING ■ Items unsuitable for the cup holders Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 366: Auxiliary Box
5-3. Using the storage features Auxiliary box (if equipped) Push the lid. WARNING ■ Items unsuitable for storing Do not store items heavier than 0.4 lb. (0.2 kg). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident.
Page 367: Coin Holder/Tissue Pocket/Pen Holder
5-3. Using the storage features Coin holder/tissue pocket/pen holder Lift the lid while pulling up the knob to release the lock. Coin holder Tissue pocket Pen holder...
Page 368: Bottle Holders
5-3. Using the storage features Bottle holders Front seats Rear seats (without third row   seats)/second row seats (with third row seats) ■ When using the bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. WARNING ■...
Page 369: Luggage Compartment Features
5-3. Using the storage features Luggage compartment features Cargo hooks ■ Vehicles with third seats  Fold down the third seats. (P. 145) Raise the hook to use. The cargo hooks are provided for securing loose items. Vehicles without third seats ...
Page 370 5-3. Using the storage features Cargo net hooks ■ The cargo net itself is not included as original equipment. Vehicles with third seats (pattern 1)  Raise the rear cargo hook to use. Vehicles with third seats (pattern 2)  Fold down the third seats.
Page 371 5-3. Using the storage features Vehicles without third seats (pattern 2)  Raise the cargo hook to use. Storage compartment ■ Type A (if equipped) Type B (if equipped)   Open the storage compartment as shown.
Page 372 5-3. Using the storage features Slide deck (if equipped) ■ Slide the deck while turning the lock release lever, and then release the lever after sliding the deck to the lock position. Half-slide locked position Full-slide locked position Grocery bag hooks ■...
Page 373 5-3. Using the storage features WARNING ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. ■ Slide deck operating precaution (if equipped) ● Be careful not to get hands or feet pinched by the slide deck. ●...
Page 374: 5-4. Other Interior Features
5-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 375: Clock
5-4. Other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours Adjusts the minutes ■ The clock is displayed when Vehicles without a smart key system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system ...
Page 376: Power Outlets (120 V Ac)
5-4. Other interior features Power outlets (120 V AC) (if equipped) The power outlet can be used for electrical appliances. Main switch  To use the power outlet, turn on the main switch. The power supply starts a few sec- onds after the main switch is pressed.
Page 377 When the cabin temperature is high, open the windows to cool the tempera- ture down. Once it reaches the normal temperature, turn the power outlet main switch on again. If the power supply does not resume even after the above procedure has been performed, have the vehicle inspected by your Toyota dealer.
Page 378 Do not modify, disassemble or repair the power outlet or its inverter in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact your Toyota dealer for any necessary repairs. ■...
Page 379 5-4. Other interior features NOTICE ■ To avoid damaging the power outlet and the plug ● Close the power outlet lid when not in use. ● Do not allow foreign objects or liquids to enter the power outlet, as this may cause a short circuit.
Page 380: Power Outlets
■ If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact your Toyota dealer for any necessary replace- ments. ■ If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
Page 381 5-4. Other interior features Console box (inside)  Lift the lid while pulling up the knob to release the lock. Open the lid. Luggage compartment (vehi- Luggage compartment (vehi-   cles without the 120 V AC) cles with the 120 V AC) Open the lid.
Page 382 5-4. Other interior features ■ The power outlets can be used when Vehicles without a smart key system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system  The engine switch is in ACCESSORY or IGNITION ON mode. ■...
Page 383: Usb Charging Ports
5-4. Other interior features USB charging ports The USB charging ports are used to supply 2.1 A of electricity at 5 V to external devices (power consumption of 10.5 W). The USB charging ports are for charging only. They are not designed for data transfer or other purposes.
Page 384 5-4. Other interior features NOTICE ■ To prevent damage to the USB charging ports ● Do not insert foreign objects into the ports. ● Do not spill water or other liquids into the ports. ● When the USB charging ports are not in use, close the lids. If a foreign object or liquid enters a port may cause a short circuit.
Page 385: Armrest
5-4. Other interior features Armrest Pull down the armrest for use. NOTICE Do not apply too much load on the armrest. Assist grips An assist grip (type A) installed on the ceiling can be used to support your body while sitting on the seat.
Page 386: Garage Door Opener
5-4. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manu- ®...
Page 387 5-4. Other interior features ® Programming HomeLink ■ Steps through must be performed within 60 seconds, other- wise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 388 5-4. Other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● If the indicator light is solid/continuous, programming has been completed and your device should activate when the ® HomeLink button is pressed and released.
Page 389 5-4. Other interior features Press and hold the pro- ® grammed HomeLink button (located inside the vehicle) for 2 seconds and release it. Repeat this sequence (press/ hold/release) up to 3 times to complete programming. If the garage door opener motor activates when the ®...
Page 390 5-4. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should turn on. Garage door operation indicators The status of the opening and closing of a garage door is shown by the indicators. Opening Closing This function is only available if the...
Page 391 5-4. Other interior features ® Erasing the entire HomeLink memory (all three programs) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit (orange) rapidly flashing (green). If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 392 ■ For additional programming assistance with your HomeLink Universal Transceiver Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. WARNING ■ When programming a garage door or other remote control device The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm.
Page 393: Maintenance And Care
Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..392 Cleaning and protecting the vehicle interior... 395 6-2. Maintenance Maintenance requirements ....398 General maintenance..400 Emission inspection and maintenance (I/M) programs......403 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 394: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 395 6-1. Maintenance and care ■ Wheels and wheel ornaments ● Remove any dirt immediately by using a neutral detergent. ● Wash detergent off with water immediately after use. ● To protect the paint from damage, make sure to observe the following pre- cautions.
Page 396 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 397: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 398 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 399 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 400: Maintenance Maintenance Requirements
■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war-...
Page 401 Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 402: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 403 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmis- • When parked on a slope and the shift lever is in P, sion “Park” mecha- is the vehicle securely stopped? nism •...
Page 404 6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? Engine hood • Does the engine hood lock system work properly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 405: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 406: 6-3. Do-It-Yourself Maintenance
(P. 414) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non-amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology For the U.S.A.:...
Page 407 6-3. Do-it-yourself maintenance Items Parts and tools Fuses (P. 446) • Fuse with same amperage rating as original • Bulb with same number and wattage rating as original Light bulbs (P. 449) • Phillips-head screwdriver • Flathead screwdriver • Wrench ®...
Page 408 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 409: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Push the auxiliary catch lever to the left and lift the hood. WARNING ■...
Page 410: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (P. 420) Brake fluid reservoir (P. 414) Power steering fluid reservoir (P. 416) Fuse box (P. 446) Engine oil level dipstick Battery (P. 417) (P. 410) Condenser (P. 414) Engine coolant reservoir Radiator (P.
Page 411 6-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure that the cover is securely installed in its original position.
Page 412 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 413 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 414 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 415 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 416 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 417 6-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the brake fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. WARNING ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 418 6-3. Do-it-yourself maintenance Power steering fluid Fluid level ■ The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
Page 419 6-3. Do-it-yourself maintenance WARNING ■ When checking the reservoir Take care as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 420 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. WARNING ■...
Page 421 6-3. Do-it-yourself maintenance WARNING ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5 A or less).
Page 422 6-3. Do-it-yourself maintenance Washer fluid Type A  If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. Type B  If the washer fluid level is at “LOW”, add washer fluid.
Page 423 6-3. Do-it-yourself maintenance WARNING ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 424: Tires
6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 425 Vehicles without P245/60R20 tires  Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. Vehicles with P245/60R20 tires ...
Page 426 6-3. Do-it-yourself maintenance Tire pressure warning system Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning valve and transmitters to detect low tire inflation pressure before serious problems arise. ● The tire pressure detected by the tire pressure warning sys- tem can be displayed on the multi-information display.
Page 427 6-3. Do-it-yourself maintenance ◆ Installing tire pressure warning valve and transmitters When replacing the tires or wheels, the tire pressure warning valve and transmitters must be installed to the wheels which will be installed to the vehicle. When new tire pressure warning valve and transmitters are installed, new ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized.
Page 428 6-3. Do-it-yourself maintenance Select “Set Pressure” then press and hold until the tire pressure warning light blinks 3 times. Then a message will be dis- played on the multi-information display. “---” will be displayed on the multi-information display for the inflation pressure of each tire while initialization is being performed.
Page 429 6-3. Do-it-yourself maintenance How to register the ID codes ■ Select on the multi-information display using the meter con- trol switches on the steering wheel. (P. 96) Select “Vehicle Settings” and then press and hold Select “TPWS” and then press Select “Change Wheel Set”...
Page 430 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 431 6-3. Do-it-yourself maintenance ■ Tire types ● Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 432 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 433 (40 km/h) or more for approximately 10 to 30 minutes. • If initialization is still not complete, have the vehicle inspected by your Toyota dealer. : Except when making a left/right turn ● In the following situations, the tire inflation pressure will not be recorded and the system will not operate properly.
Page 434 (25 mph) or more for approximately 10 to 30 minutes. If registration is still not complete, have the vehicle inspected by your Toyota dealer. : Except when making a left/right turn ● When the tire pressure warning light does not blink slowly 3 times, the ID code will not be registered and the system will not operate properly.
Page 435 6-3. Do-it-yourself maintenance ■ Tire pressure warning system certification For vehicles sold in the U.S.A.  For vehicles sold in Canada ...
Page 436 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 437 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 438: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 533)
Page 439 ● Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer.
Page 440 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 441: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 442 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 443: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open glove remove the cover. Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one.
Page 444 6-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Schedule maintenance guide”...
Page 445: Wireless Remote Control/Electronic Key Battery
6-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2016 (vehicles without a smart key system), or CR1632 (vehicles with a smart key system) Replacing the battery (vehicles without a smart key system) Remove the cover.
Page 446 Use a CR2016 (vehicles without a smart key system) or CR1632 (vehicles with a smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 447 If the cover cannot be firmly closed, stop using the wireless remote con- trol/electronic key and stow the key in the place where children cannot reach, and then contact your Toyota dealer. ● If you accidentally swallow a battery or put a battery into a part of your body, get emergency medical attention immediately.
Page 448: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. Open the Fuse box cover. Engine compartment ...
Page 449 Type A, B, C, D, E: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type F: Contact your Toyota dealer. Type A Type B ...
Page 450 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 449) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 451: Light Bulbs
If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 529)
Page 452 6-3. Do-it-yourself maintenance Bulb locations Front ■ Headlight high beam (if Front side marker light equipped)/daytime running light Front turn signal/parking light Rear ■ Rear turn signal light Back-up light License plate light...
Page 453 6-3. Do-it-yourself maintenance Replacing light bulbs Headlight high beam (if equipped)/daytime running lights ■ Turn bulb base counterclockwise. Pull the bulb out while press- ing the lock release of the connector. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert.
Page 454 6-3. Do-it-yourself maintenance Front turn signal/parking light ■ Turn the steering wheel in the opposite direction of the front turn signal light and parking light that you wish to replace. For example, if you wish to replace the front turn signal light and parking light on the right side, turn the steering wheel to the left.
Page 455 6-3. Do-it-yourself maintenance Turn bulb base counterclockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 456 6-3. Do-it-yourself maintenance Front side marker lights ■ Turn the steering wheel in the opposite direction of the front side marker light that you wish to replace. For example, if you wish to replace the front side marker light on the right side, turn the steering wheel to the left.
Page 457 6-3. Do-it-yourself maintenance Turn bulb base counterclockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 458 6-3. Do-it-yourself maintenance Rear turn signal lights ■ Open the back door and remove the cover. To prevent damage to the vehi- cle, cover the tip of the screw- driver with a rag. Turn bulb base counterclockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 459 6-3. Do-it-yourself maintenance Back-up lights ■ Open the back door and remove the cover. To prevent damage to the vehi- cle, cover the tip of the screw- driver with a rag. Turn bulb base counterclockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 460 6-3. Do-it-yourself maintenance License plate lights ■ Remove the screws and lens. Remove the light bulb. When installing, reverse the steps listed.
Page 461 LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 462 6-3. Do-it-yourself maintenance...
Page 463: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..462 If your vehicle has to be stopped in an emergency ...... 463 If the vehicle is trapped in rising water ..... 465 7-2. Steps to take in an emergency If your vehicle needs to be towed ......
Page 464: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 465: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 466 7-1. Essential information WARNING ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 467: If The Vehicle Is Trapped In Rising Water
However, an emergency hammer can not shatter the windshield as it is lam- inated glass. : Contact your Toyota dealer or aftermarket accessory manufacturer for further information about an emergency hammer. ■ Escaping the vehicle from the window There are cases where escaping the vehicle from the window is not possi- ble due to seating position, passenger body type, etc.
Page 468: 7-2. Steps To Take In An Emergency
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 469 7-2. Steps to take in an emergency WARNING ■ While towing ● When towing using cables or chains, avoid sudden starts, etc. which place excessive stress on the towing eyelets, cables or chains. The towing eye- lets, cables or chains may become damaged, broken debris may hit peo- ple, and cause serious damage.
Page 470 Situations when it is necessary to contact dealers before towing The following may indicate a problem with your transmission. Contact your Toyota dealer or commercial towing service before towing. ● The engine is running but the vehicle does not move.
Page 471 7-2. Steps to take in an emergency NOTICE ■ Towing with a sling-type truck Do not tow with a sling-type truck to pre- vent body damage. Using a flatbed truck When using a flat-bed truck to transport the vehicle, use tire strapping belts.
Page 472 7-2. Steps to take in an emergency Emergency towing procedure Vehicles with front covers only: Before using the front emer- gency towing eyelet(s), remove the cover(s). Removing the clips Installing the clips Securely attach cables chains to the towing hook. Take care not to damage the vehi- cle body.
Page 473 7-2. Steps to take in an emergency Part-time 4WD models: Type A  Shift the front-wheel drive control lever to H2. Type B  Push the “UNLOCK” button and turn the front-wheel drive control switch to H2. Full-time 4WD models: Push the “UNLOCK” button and turn the four-wheel drive control switch to H4F.
Page 474: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 475: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 476: If A Warning Light Turns On Or A Warning Buzzer Sounds
If the light turns off after the parking brake is fully released the system is operating normally.  Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive (Canada) the vehicle may be dangerous.
Page 477 • The emission control system; • The electronic engine control system; (U.S.A.) • The electronic throttle control system; or • The electronic automatic transmission control sys-  Have the vehicle inspected by your Toyota dealer (Canada) immediately. SRS warning light Indicates a malfunction in: •...
Page 478 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Four-wheel drive indicator light (if equipped) Indicates a malfunction in the four-wheel drive system  Have the vehicle inspected by your Toyota dealer (Flashes rapidly) immediately. Low speed four-wheel drive indicator light (if equipped) Indicates a malfunction in the four-wheel drive system ...
Page 479 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Low fuel level warning light Indicates remaining fuel is approximately 3.5 gal. (13.1 L, 2.9 Imp. gal.) or less  Refuel the vehicle. Seat belt reminder light (warning buzzer) Warns the driver and/or front passenger to fasten their seat belts ...
Page 480 PCS warning light When a buzzer sounds simultaneously: Indicates a malfunction has occurred in the PCS (Pre- Collision System).  Have the vehicle inspected by your Toyota dealer immediately. When a buzzer does not sound: The PCS (Pre-Collision System) has become tempo- rarily unavailable, corrective action may be necessary.
Page 481 7-2. Steps to take in an emergency : Parking brake engaged warning buzzer: A buzzer will sound if the vehicle is driven at a speed of approximately 3 mph (5 km/h) or more. : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]).
Page 482 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 483 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 484 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 485 7-2. Steps to take in an emergency WARNING Your vehicle has also been equipped with a TPMS (tire pressure warn- ing system) malfunction indicator to indicate when the system is not operating properly. The TPMS (tire pressure warning system) malfunc- tion indicator is combined with the low tire pressure telltale (tire pressure warning light).
Page 486: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the mes- sage on the multi-information dis- play. If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer.
Page 487 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 488 ● If the following message is shown, there may be a malfunction. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. • “Braking Power Low Stop in a Safe Place See Owner’s Manual”...
Page 489 ■ When “Headlight System Malfunction Visit Your Dealer” is displayed on the multi-information display The following system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. ● Automatic High Beam ■ If a message that indicates the malfunction of front camera is displayed The following systems may be suspended until the problem shown in the message is resolved.
Page 490 ■ If “Visit Your Dealer” is shown The system or part shown on the multi-information display is malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 491: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 422 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 492 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Spare tire Jack Tool bag...
Page 493 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 494 7-2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover. Unhook and take out the tool bag. Take out the jack. For loosening For tightening...
Page 495 7-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. Remove the jack handle and the jack handle extension bar from the tool bag and assembly by following these steps. Loosen the bolt and the screw using either the jack handle or a screwdriver.
Page 496 7-2. Steps to take in an emergency Insert the end of the jack han- dle extension into the lowering screw turn counterclockwise. Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket.
Page 497 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 498 7-2. Steps to take in an emergency Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack handle bar from the tool bag and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 499 7-2. Steps to take in an emergency Position the jack at the jack points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. When positioning the jack under the rear axle housing, make sure the groove on the top of the jack...
Page 500 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the...
Page 501 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 502 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque Steel wheels: 83 ft•lbf (112 N•m, 11.4 kgf•m) Aluminum wheels: 76 ft•lbf (103 N•m, 10.5 kgf•m)
Page 503 7-2. Steps to take in an emergency WARNING ■ Stowing the flat tire Failure to follow steps listed under stowing the tire may result in damage to the spare tire carrier and lose of the tire, which could result in death or serious injury.
Page 504 7-2. Steps to take in an emergency Confirm that the tire is not loose after tightening: Push and pull the tire Try rotating Vishually check to ensure the tire is not hung on surrounding parts. If looseness or misassembly exists, repeat step and step Repeat step any time the tire is lowered or disturbed.
Page 505 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 506: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 209, 212), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
Page 507 ● There may be a malfunction in the steering lock system (vehicles with a smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart key system)
Page 508: If You Cannot Operate Back Door Opener
If the back door opener does not operate, there may be a prob- lem with the back door opener system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the back door can be opened from the inside.
Page 509: If The Electronic Key Does Not Operate Properly (Vehicles With A Smart Key System)
Unlocks all the doors Turning the key rearward unlocks the driver’s door. Turning the key once again unlocks the other doors. Opens the windows and moon roof (turn and hold) (P. 164, 172) : This setting must be customized at your Toyota dealer.
Page 510 Firmly depress the brake pedal and check that is displayed on the multi-information display. Press the engine switch shortly and firmly. In the event that the engine still cannot be started, contact your Toyota dealer. ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.
Page 511 7-2. Steps to take in an emergency WARNING ■ When using the mechanical key and operating the power windows, power back window or moon roof Operate the power windows, power back window or moon roof after check- ing to make sure that there is no possibility of any passenger having any of their body parts caught in the window or moon roof.
Page 512: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 513 IGNITION ON mode (vehicles with a smart key system). Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible.
Page 514 7-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. ●...
Page 515 7-2. Steps to take in an emergency WARNING ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 516: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 517 Start the engine to check that the radiator cooling fan operate and to check for coolant leaks from the radiator or hoses. If the fan are not operating: Stop the engine immediately and contact your Toyota dealer. If the fan are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 518 7-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■...
Page 519: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the stuck tire.
Page 520 7-2. Steps to take in an emergency...
Page 521: Vehicle Specifications
Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..520 Fuel information ....530 Tire information ....533 8-2. Customization Customizable features ..545 8-3. Items to initialize Items to initialize ....558...
Page 522: Specifications Maintenance Data
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 189.8 in. (4820 mm) Overall width 75.8 in. (1925 mm) Overall height 70.1 in. (1780 mm) Wheelbase 109.8 in. (2790 mm) Front 63.2 in. (1605 mm) Tread Rear 63.2 in.
Page 523 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 524 8-1. Specifications Engine Model 1GR-FE Type 6-cylinder V type, 4-cycle, gasoline 3.70  3.74 in. (94.0  95.0 mm) Bore and stroke Displacement 241.4 cu.in. (3956 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only 87 (Research octane number 91) or Octane rating...
Page 525 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 526 Cooling system Capacity 11.1 qt. (10.5 L, 9.2 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol- based non-silicate, non-amine, non- Coolant type nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 527 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please...
Page 528 Oil type and viscosity 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 529 8-1. Specifications Automatic transmission Fluid capacity 11.3 qt. (10.7 L, 9.4 Imp. qt.) Fluid type Toyota Genuine ATF WS : The fluid capacity is a reference quantity. If replacement is necessary, con- tact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than the above type may cause abnormal noise or vibration, or damage the transmission of your vehicle.
Page 530 8-1. Specifications Chassis lubrication Spider Lithium base chassis grease, NLGI No.2 Molybdenum-disulfide lithium base chas- Propeller shafts Slide yoke sis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 1.2 in. (30 mm) ® Automatic transmission fluid DEXRON Power steering fluid type or III...
Page 531 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlight high beam equipped) /daytime running 9005 lights Front turn signal and parking 7444NA 28/8 lights Exterior  Front side marker lights  Rear turn signal lights  Back-up lights  License plate lights Front personal/ front interior ...
Page 532: Fuel Information
Gasoline quality In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer.
Page 533 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA's lowest additives concen- tration program.
Page 534 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 535: Tire Information
8-1. Specifications Tire information Typical tire symbols Tire size (P. 535) Summer tires or all season tires (P. 429) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
Page 536 8-1. Specifications Load limit at maximum cold tire inflation pressure (P. 539) Maximum cold tire inflation pressure (P. 539) This means the pressure to which a tire may be inflated. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a tube inside the tire and the tube maintains the air pressure.
Page 537 8-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 538 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer...
Page 539 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 540 8-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 541 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 542 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 543 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 544 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 545 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 546 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 547: Customization
The settings of these fea- tures can be changed by using the steering wheel switches, nav- igation system, multimedia system or at your Toyota dealer. It is also possible to customize certain vehicle features yourself using the multi-information display.
Page 548 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using the meter control switches Settings that can be changed using the navigation system or the...
Page 549 8-2. Customization Smart key system and wireless remote control ■  P. 110, 118, 131) Customized Function Default setting setting Operation signal (buzzer) Level 5 – Level 1 to 7 Operation signal (Emer- – gency flashers) Time elapsed before the automatic door lock func- tion is activated if a door is 60 seconds...
Page 550 8-2. Customization  Wireless remote control ( P. 102, 110, 131) ■ Customized Function Default setting setting Wireless remote control – – Panic function – – Driver’s door unlocked doors one step, all Unlocking operation unlocked – doors one step unlocked two steps ...
Page 551 8-2. Customization  Interior lights ( P. 357) ■ Customized Function Default setting setting Time elapsed before the 15 seconds 7.5 seconds – interior lights turn off 30 seconds Operation after the engine switch is turned to the “LOCK” position (without a smart key system) or the –...
Page 552 8-2. Customization Exterior lights (P. 225, 255) ■ Customized Function Default setting setting Daytime running light sys- – Time elapsed before the 15 seconds 7.5 seconds – exterior lights turn off 30 seconds Operation of the outer foot lights when approach the vehicle with –...
Page 553 8-2. Customization Meters (P. 88) ■ Customized Function Default setting setting Sensitivity of the ambient light sensor used for dim- Standard -2 to 2 – – ming the meter lights etc. Sensitivity of the ambient light sensor used Standard -2 to 2 –...
Page 554 8-2. Customization  Power windows ( P. 162) ■ Customized Function Default setting setting Mechanical linked – – operation (close) Mechanical linked – – operation (open) Wireless remote control – – linked operation (open) Wireless remote control – – linked operation (buzzer) Moon roof (P.
Page 555 8-2. Customization Rear window wiper and washer (P. 236) ■ Customized Function Default setting setting Wiper operates automati- cally when washer is oper- – – ated Drip prevention function – – 2 seconds Wiper operation interval 3 seconds 4 seconds –...
Page 556 8-2. Customization  Toyota parking assist-sensor P. 285) ■ Customized Function Default setting setting Detection distance of the Near – rear center sensor Buzzer volume Level 2 Level 1 to 3 – : If equipped Seat belt reminder (P. 474) ■...
Page 557 8-2. Customization Multi-information display (P. 90) ■ Customized Function Default setting setting French Language English – Spanish Units miles (MPG) km (L/100km) – Eco Driving Indicator Light – Desired status switch settings After start – screen Pop-up display – : The default setting varies according to countries. : Some status screens cannot be registered (indicated on multi-information display).
Page 558 8-2. Customization LDA (Lane Departure Alert) (P. 264) ■ Default Customized Function setting setting Alert sensitivity Standard High – Vehicle sway warning – function Vehicle sway warning Standard – sensitivity High PCS (Pre-Collision System) (P. 254) ■ Default Customized Function setting setting PCS (Pre-Collision Sys-...
Page 559 8-2. Customization ■ In the following situations, customize mode will automatically be turned off. ● A warning message appears after the customize mode screen is displayed. ● The engine switch is turned to the “LOCK” position (without a smart key sys- tem) or the engine switch is turned to OFF (with a smart key system).
Page 560: 8-3. Items To Initialize
8-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- After the maintenance is per- P.
Page 561: For Owners
For owners Reporting safety defects for U.S. owners......560 Seat belt instructions for Canadian owners (in French) ....... 561 SRS airbag instructions for Canadian owners (in French) ....... 563...
Page 562: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 563: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 564 WARNING ■ Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité périodiquement. Contrôlez qu’elles ne sont pas entaillées, effilochées et que leurs ancrages ne sont pas desser- rés. N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée.
Page 565: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 566 ◆ Coussins gonflables latéraux et rideaux SRS Coussins gonflables latéraux SRS Participent à la protection du torse des passagers du siège avant Coussins gonflables rideaux SRS ● Participent principalement à la protection de la tête des occu- pants assis aux places extérieures ●...
Page 567 Composition du système de coussins gonflables SRS Coussins gonflables latéraux Commutateur de boucle de ceinture de sécurité du siège Témoins indicateurs “AIR du passager avant BAG ON” et “AIR BAG OFF” Système de classification de Coussins gonflables rideaux l’occupant du siège passager Coussin gonflable passager avant (ECU et capteurs) avant...
Page 568 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des coussins gonflables régule le déploiement de ces derniers sur la base des informations qu’il reçoit des capteurs, etc., indiqués ci-des- sus dans le schéma illustrant les composants du système.
Page 569 WARNING ■ Précautions avec le coussin gonflable SRS Respectez les précautions suivantes avec les coussins gonflables SRS. Autrement, des blessures graves, voire mortelles, pourraient s’ensuivre. ● Le conducteur et les passagers du véhicule doivent porter correctement leur ceinture de sécurité. Les coussins gonflables SRS sont des dispositifs supplémentaires à...
Page 570 être grièvement blessés ou tués par le déploiement d’un coussin gonflable. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recom- mande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 571 WARNING ■ Précautions avec le coussin gonflable SRS ● Ne laissez pas un enfant se tenir debout devant le coussin gonflable pas- sager avant SRS ou bien s’asseoir sur les genoux du passager avant. ● Ne laissez pas les occupants des sièges avant voyager avec un objet sur les genoux.
Page 572 Essuyez tout résidu dès que possible afin d’éviter d’éventuelles irritations de la peau. ● Si les parties renfermant les coussins gonflables SRS, telles que la garni- ture du volant et les garnitures de montants avant et arrière, sont abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
Page 573 Modification et mise au rebut des éléments du système de coussins gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d’intervenir sur votre véhicule ou de procéder à l’une des modifica- tions suivantes. Les coussins gonflables SRS peuvent être défaillants ou se déployer (se gonfler) accidentellement, provoquant la mort ou de graves...
Page 575 Index What to do if... (Troubleshooting) ....574 Alphabetical index ..... 579 For details of equipment related to the audio/navigation system, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
Page 576 You lose your keys ● If you lose your keys or mechanical keys, new genuine mechanical keys can be made by your Toyota dealer. (P. 105) ● If you lose your keys or electronic keys, the risk of vehicle theft increases significantly.
Page 577 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without a smart key system) ● Is the shift lever in P? (P. 209) ● Is the steering wheel unlocked? (P. 209) ● Is the battery discharged? (P.
Page 578 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without a smart key system: It is locked to prevent theft of the vehicle if the key is pulled from the engine switch.
Page 579 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 477) ● The brake system warning light is on Is the parking brake released? (P.
Page 580 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 489) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 581 Alphabetical index Alphabetical index Alarm .......... 79 A/C ........340, 347 Alarm ........79 Air conditioning filter ..... 441 Warning buzzer ....474 Anchor brackets ......57 (Anti-lock Brake System)..320 Antennas Function ........ 320 (smart key system) ....118 Warning light......
Page 582 Alphabetical index Back door Care ........392, 395 Back door......131 Exterior ......... 392 Back window......166 Interior ........395 Smart key system ....118 Seat belts......396 Wireless remote control ..110 Wheels and wheel Back window......166 ornaments ......393 Back-up lights Cargo capacity......
Page 583 Alphabetical index Child safety ........ 52 Airbag precautions....37 Daytime running light Back door precautions ..133 system........228 Battery precautions..418, 513 Defogger Child restraint system ..... 53 Front windshield ....349 How your child should Outside rear view wear the seat belt ....
Page 584 Alphabetical index Driving ........176 Emergency flashers ....462 Break-in tips......178 Engine Correct driving posture ... 28 ACCESSORY mode ..... 213 Driving assist systems ..320 Compartment......408 Off-road precautions ..... 333 Engine switch ....209, 212 Procedures ......176 Hood ........
Page 585 Alphabetical index Front passenger occupant classification system ....46 Head restraints ......153 Front personal lights....358 Headlights ........ 225 Front seats ....... 136 Automatic High Beam Adjustment......136 system........ 230 Cleaning........ 395 Light switch......225 Correct driving posture ... 28 Replacing light bulbs ..
Page 586 Alphabetical index I/M test ........403 Jack Identification Vehicle-equipped jack ..489 Engine........521 Jack handle......493 Vehicle ........521 Jam protection function Ignition switch Moon roof ......171 (engine switch) ....209, 212 Power back window....168 Illuminated entry system ..359 Power windows.....
Page 587 Alphabetical index LATCH anchors ......59 Maintenance Lever Do-it-yourself maintenance... 404 Auxiliary catch lever....407 General maintenance ... 400 Hood lock release lever ..407 Maintenance data ....520 Shift lever......218 Maintenance requirements ... 398 Turn signal lever ....223 Resetting the message Wiper lever....
Page 588 Alphabetical index Multi Terrain ABS ....320 Multi-information display..90 Parking brake......224 Driving information....93 Operation......224 Dynamic radar cruise Parking brake engaged control......... 272 warning buzzer....474 Language......555 (Pre-Collision System)..254 (Lane Departure Alert)..264 Warning light......214 Outside temperature ....
Page 589 Alphabetical index Radiator ........414 Safety Connect ......70 Rear differential lock Seat belt reminder light ..477 system........304 Seat belts ........30 Rear seats Adjusting the seat belt .... 30 Adjustment......139 Automatic Locking Folding down ..141, 143, 145 Retractor (ALR) ....
Page 590 Alphabetical index Seats ......... 136, 139 Shift lock system..... 220 Adjustment....136, 139 Side airbags ....... 35 Adjustment Side marker lights ....225 precautions....138, 148 Light switch......225 Child seats/child restraint Replacing light bulbs .... 454 system installation ....57 Wattage ........
Page 591 Alphabetical index Switches Automatic High Beam Tachometer ........ 88 switch ......... 230 Tail lights........225 Cruise control switch..... 272 Light switch......225 Door lock switches....113 Telephone switches Driving position memory Theft deterrent system switches......149 Alarm ........79 Emergency flashers switch ... 462 Engine immobilizer system..
Page 592 Dinghy towing ....... 208 Vehicle data recordings....9 Emergency towing ....469 Vehicle identification Trailer towing ......192 number........521 Toyota Safety Sense P .... 245 Vehicle Stability Control Automatic High Beam ... 230 (VSC) ........320 Dynamic radar cruise Ventilators control.........
Page 593 Alphabetical index Slip indicator ......475 Warning buzzers SRS ........475 Brake system ......474 Tire pressure ......478 Downshifting ......221 Unengaged “Park” ....476 Intuitive parking assist ..285 Warning messages....484 Key reminder ....210, 479 Washer ........236 Lane departure alert Checking.......
Page 594 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 407 P. 244 Tire inflation Hood lock release lever pressure P. 528 P. 407 Fuel tank capacity 23.0 gal. (87.0 L, 19.1 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P.

This manual is also suitable for:

4runner 20204runner 2021

Toyota 4Runner 2021 Owner's Manual

1 For Safety and Security

1-1. for Safe Use

Emergency Assistance Safety Connect

1-3. Theft Deterrent System

2 Instrument Cluster

Instrument Cluster Warning Lights and

Operation of each Component

3-1. Key Information

3-3. Adjusting the Seats

4 Driving

4-1. before Driving

Operating the Lights

4-4. Refueling

Driving Tips

5 Interior Features

5-1. Using the Air

Using the Interior Lights

5-3. Using the Storage Features

5-4. Other Interior Features

6 Maintenance and Care

Maintenance and Care Cleaning and Protecting

Maintenance Maintenance Requirements

6-3. Do-It-Yourself Maintenance

7 When Trouble Arises

7-1. Essential Information

7-2. Steps to Take in an Emergency

8 Vehicle Specifications

Specifications Maintenance Data

Customization

8-3. Items to Initialize

9 For Owners

Quick Links

Related Manuals for Toyota 4Runner 2021

Summary of Contents for Toyota 4Runner 2021
