DeviceNet Objects
EX260 SI unit supports the following DeviceNet
∗: xxh means hexadecimal number.
Class code
01h Identity
02h Message Router
03h DeviceNet
04h Assembly
05h DeviceNet
09h Discrete Output Point
0Fh Parameter
64h SMC SI (SMC Specific)
1. Identity Object (Class ID: 01h)
1-1. Class attribute
ID Access rule
- -
1-2. Class common service
Service code
-
1-3. Instance attribute
ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
∗1: The table below shows the product codes and product names corresponding to the SI unit type.
SI unit
EX260-SDN1
EX260-SDN2
EX260-SDN3
EX260-SDN4
1-4. Instance common service
Service code
05h Reset
0Eh Get_Attribute_Single
1-5. Specific service
None.
TM
Object class
TM
TM
Connection
Description Value
-
Service name
-
Description
Vender ID
Device Type
Product Code
Revision
Status
Serial Number
Product Name
Product Code Product Name (ASCII)
92h EX260-SDN1
98h EX260-SDN2
96h EX260-SDN3
99h EX260-SDN4
Description
object classes and device type is Pneumatic Valves.
-
Value
07h
1Bh
∗ 1
Per unit
-
Per unit
∗ 1
