LED Indication and Settings

○LED indication
LED
NS
MS
PWR
PWR(V)
NS status
Green ON
OFF
Green flashing
OFF
OFF
Red ON
Red flashing
OFF
Network status. (See the table below for details)
SI unit status. (See the table below for details)
Turns ON in green when network power is supplied.
Turns ON in green when load voltage for the valve is supplied.
Turns OFF when load voltage for the valve is not supplied or outside tolerance range.
(19 V or less)
MS status
On-line status, The device has connections in the established
Green ON
state.
Off-line status, The device has not completed the Dup_MAC ID
Green ON
test yet.
On-line status, The device has no connections in the established
Green ON
state.
Red ON
Off-line status, Watchdog timer error.
Red flashing
Wrong switch setting, Parameter writing error.
Green ON
Bus-off status, Duplicate MAC ID.
Green ON
I/O Connection is in the Timed-Out state.
OFF
No network power present.
Description
Description
