Samsung NX5 User Manual

Table of Contents

Quick Links

Download this manual

User Manual

NX5

This user manual includes detailed usage

instructions for your camera. Please read

this manual thoroughly.

Click a topic

Quick reference

Contents

Basic functions

Basic shooting

Extended shooting functions

Playback/Editing

Camera settings menu

Appendixes

Table of Contents

Summary of Contents for Samsung NX5

Page 1 User Manual This user manual includes detailed usage instructions for your camera. Please read this manual thoroughly. Click a topic Quick reference Contents Basic functions Basic shooting Extended shooting functions Playback/Editing Camera settings menu Appendixes...
Page 2: Health And Safety Information
Handle and dispose of batteries and chargers with care • Use only Samsung-approved batteries and chargers. Incompatible batteries and chargers can cause serious injuries or damage to your camera. • Never dispose of batteries in a ﬁre. Follow all local regulations when disposing of used batteries.
Page 3 Reformat the memory card with your camera. • Never use a damaged charger, battery, or memory card. Use only Samsung-approved accessories Using incompatible accessories may damage your camera, cause injury, or void your warranty. Protect your camera’s lens •...
Page 4 charging is ﬁnished, disconnect the cable from your camera. • Over time, unused batteries will discharge and must be recharged before use. • Disconnect chargers from power sources when not in use. • Use batteries only for their intended purpose. Exercise caution when using the camera in humid environments When transferring the camera from a cold environment...
Page 5: Indications Used In This Manual
Indications used in this manual Shooting mode Smart Auto Program Aperture Priority Shutter Speed Priority Manual Night Portrait Landscape Scene Movie Shooting mode explanation shown next to the title This shows that the functions explained can only be selected from within the shooting mode. In the case of the mode, this corresponds to only part of the scene.
Page 6 Menu display used in this manual Menu display of the photo shooting mode Shooting 1( Shooting 3( Shooting 2( Menu display of the movie shooting mode Shooting 1( Shooting 3( Shooting 2( Ex) Setting the image quality of movie ﬁle Set the mode dial to Press [MENU].
Page 7 Expressions used in this manual Pressing the shutter • Half-press [Shutter]: press the shutter halfway down • Press [Shutter]: press the shutter all the way down Half-press [Shutter] Subject, background, and composition • Subject: the main object of a scene, such as a person, animal, or still life •...
Page 8: Table Of Contents
Quick reference Taking photos of people • mode → Beauty Shot • Red-eye reduction • Face Detection AF Taking photos at night or in the dark • mode • Flash setting options • ISO speed setting Taking action photos • mode •...
Page 9 Contents Basic functions ... 12 Unpacking ... 13 Title and role of each part ... 14 Diopter adjustment dial/eye-cup/Status lamp ... 16 Description for each part of the lens ... 17 Preparations before shooting ... 18 Charging the battery ... 18 Installing the battery ...
Page 10 Contents Extended shooting functions ... 50 Setting the resolution and quality ... 51 Setting a resolution ... 51 Setting the image quality of the picture ... 52 Setting the quality of movie... 52 Noise reduction ... 53 Using the timer function ... 54 Setting the timer function ...
Page 11 For Mac users ... 96 Using Intelli-studio ... 97 Transferring ﬁles using Intelli-studio ... 98 Using the Samsung RAW Converter ... 99 Correcting the exposure ... 100 Handling the JPEG/TIFF ﬁles as you edit RAW ﬁles ... 101 Saving the RAW ﬁles into JPEG or TIFF format ... 101 Printing photos with a photo printer (PictBridge) ...
Page 12: Basic Functions
Basic functions Learn about your camera’s layout, icons, and basic functions for shooting. Unpacking …………………………………………………13 Title and role of each part ………………………………14 Preparations before shooting ……………………………18 Turning on the power and initialization …………………23 Option/menu selection method …………………………26 Setting the display and sound ……………………………28 Simple picture-taking method ……………………………31 Tips for getting a clearer photo …………………………32...
Page 13: Unpacking
Unpacking Check your product box for the following items. Camera (Body cap, eye-cup, Hot-shoe cover included) Quick Start Manual The actual components or optional parts may differ from the illustrations above. For information about optional items, see “Accessories (optional items).” (p. 123) USB cable Battery Charger/AC power...
Page 14: Title And Role Of Each Part
Title and role of each part Mode dial (p. 5) Drive mode button (p. 73) Green button* Dial (p. 26) Shutter button (p. 7) Power switch (p. 23) AF-assist light /timer lamp (p. 61) Lens mount index (p. 21) Depth preview button (p.
Page 15 Title and role of each part Eye-cup (p. 16) Viewfinder MENU button (p. 26) Eye sensor* Display Status lamp (p. 16) Tripod mount * Use of eye sensor This product will automatically convert to EVF when the users try to use the view-finder (EVF) by operating the eye sensor in Auto Select mode and all the information will be shown on the view- finder.
Page 16: Diopter Adjustment Dial/Eye-Cup/Status Lamp
Title and role of each part Diopter adjustment dial/Eye-cup/ Status lamp Eyesight adjustment dial Eye-cup Use of Diopter adjustment dial It is possible to adjust the viewfinder appropriate for the eyesight of user. If the image is not shown clearly through the viewfinder, move the eyesight adjustment dial in Status lamp...
Page 17: Description For Each Part Of The Lens
When purchasing the lens separately, please contact a Samsung service center to verify the compatibility of the camera an lens. • This information in this user manual is based on the SAMSUNG 18-55mm F3.5-5.6 OIS lens. Please refer to the lens user manual for more information about the lens.
Page 18: Preparations Before Shooting
To remove the battery from the charger, lift slightly in the direction of the arrow. • Please use designated charger or batteries for proper use. SAMSUNG is not responsible for any accident that may occur from using a product other than designated. Charger...
Page 19: Installing The Battery
Preparations before shooting Installing the battery Open by pushing in the direction of the arrow When taking out the battery, pull down slightly on the lock lever. You can then remove the battery. Lock lever Close by pushing down in the direction of the arrow.
Page 20: Installing The Memory Card
Preparations before shooting Installing the memory card After checking the direction of • To remove the memory card, push the card slightly in the direction of insertion. metal terminal, • Please do not remove the memory card or battery you can insert while the status indicator lamp is blinking.
Page 21: Mounting/Dismounting The Lens
Mounting or dismounting the lens while the camera is powered off is desirable to ensure the stable operation of the lens. • SAMSUNG is not responsible for any accident, damage, or trouble caused by using other company's lens. • The body cap protects the product from scratches or dust when you transport it.
Page 22: Connecting The Strap
Preparations before shooting Connecting the strap Connecting the strap to the camera body so you can carry the camera easily.
Page 23: Turning On The Power And Initialization
Turning on the power and initialization When turning the power on/off, please set the power switch to ON/OFF. When you turn on the camera for the ﬁ rst time, the camera may ask you to set the language and date. Date &...
Page 24 Turning on the power and initialization Press [ ] to select Time Zone and then press [ ]. Select a desired world time zone by pressing [ / ]. Time Zone London [GMT +00:00] MENU Back To set daylight saving time, press [ ]. Press [ ] again to disable.
Page 25: Icons
Turning on the power and initialization All the details shown on the view ﬁnder will appear identically on the display. By using the live view function, the user can take a picture conveniently without having to look through the viewﬁnder. The icons shown on the screen are for when the OIS and AF/MF switches on the lens are in use.
Page 26: Option/Menu Selection Method
Option/menu selection method After pressing [MENU], you can select an option or menu by pressing [ / ] or [ ]. Press [MENU] in the Shooting mode. You can select a desired option or menu by pressing [ / / / ] or [ ]. OK button, Setting Selection AF Metering...
Page 27: Using [Fn]
Option/menu selection method Using [Fn] By pressing the [Fn] function button, you can easily access major functions such as Quality, Size, AF area, Flash, Color Space, Smart Range, and OIS. Example. Flash setting in the P mode Set the Mode dial to P. Press the [Fn] button on the body of camera.
Page 28: Setting The Display And Sound
Setting the display and sound Learn how to change basic display and sound settings according to your preferences. Changing the display type You can select the icons and options the camera displays in the Shooting and Play modes by selecting a Display Type.
Page 29: Setting User Display
Setting the display and sound Setting user display You can add or remove shooting information from the display. Press [MENU] in the shooting mode. Select User setup ( → an option. F F F S S S S S S F F F S S S S 20 F3.7 20 F3.7 About histogram...
Page 30: Setting The Screen Display
Setting the display and sound Setting the screen display The screen display can be set according to the user’s convenience. In Shooting or Playback mode, press [MENU]. Select Setting3 ( Select a desired option. Display Select Video Out Anynet+ (HDMI-CEC) HDMI Size Firmware Update MENU...
Page 31: Simple Picture-Taking Method
Simple picture-taking method Using the Smart Auto mode, you can take a picture easily with minimum setup. Rotate the mode dial to Align your subject in the frame. All the details shown on the view ﬁnder will appear identically on the display. 0001 WHITE Half-press [Shutter] to focus.
Page 32: Tips For Getting A Clearer Photo
Tips for getting a clearer photo Holding your camera correctly Image stabilization Please make sure that your hand, hair, and strap do not interfere with the lens or ﬂash. • To avoid the blurring effect of camera shake, set the optical Image Stabilization (OIS) function.
Page 33: Getting Your Subject In Focus
Getting your subject in focus Under the following circumstances, it may be difﬁcult to get your subject in focus: • When the color contrast is not clear (When someone is wearing clothes similar in color to the background) • When the subject is in front of a strong backlight •...
Page 34: Setting The Automatic/Manual Focus Function
Setting the automatic/manual focus function You can set the camera to adjust focus automatically or manually by using the AF/MF switch on the side of the lens. Using automatic focus Set the AF/MF switch of the lens to AF. The focus adjusts automatically when you press the shutter button half way down.
Page 35: Optical Image Stabilization (Ois)
Optical Image Stabilization (OIS) Use the optical image stabilization (OIS) function when taking pictures to minimize camera shake and improve focus. ▲ Before applying OIS Using the OIS switch of lens The OIS function can be used only in the case that the lens in use has the OIS function.
Page 36: Using The Ois In The Menu Option
Using the OIS in the menu option After setting the OIS switch, select the OIS function in the menu option In Shooting mode, press [MENU]. Select Shooting3 ( an option. The OIS function is applied only when Mode 1 pressing the shutter in full or half. The OIS function is always applied.
Page 37: Depth Preview
Depth preview When you are not using the depth preview function, you can only see the subject through the camera in the condition of the maximum aperture (minimum f-number) in the shooting mode. Use the Depth of Field Preview function before taking a picture to view the depth of ﬁeld of the scene as it looks with the lens set to its current f-stop number.
Page 38: Basic Shooting
Basic shooting Learn how to take a photo by selecting a mode and how to record a video. Using the Smart Auto mode ………………………… 39 Using the Program mode …………………………… 40 Using the Aperture Priority, Shutter Priority, or Manual mode ……………………………………… 41 Using the Night/Portrait/Landscapee mode ………...
Page 39: Using The Smart Auto Mode
Using the Smart Auto mode The smart auto mode allows taking pictures under an optimized condition since the camera recognizes various photographing conditions automatically. Therefore, even a beginner can use the camera easily. Rotate the mode dial to Align your subject in the frame. •...
Page 40: Using The Program Mode
Using the Program mode In the program mode, the camera automatically adjusts the shutter speed and aperture value to maintain the correct exposure. Rotate the mode dial to P. Set options. • For a list of options, refer to “Extended shooting functions.”(p.
Page 41: Using The Aperture Priority, Shutter Priority, Or Manual Mode
Using the Aperture Priority, Shutter Priority, or Manual mode By using the aperture value of adjusting light volume and shutter speed, you can take pictures of desired exposure. As for the shooting modes that allows adjusting the aperture value and shutter speed, there are the aperture priority mode, shutter speed priority mode, and manual mode.
Page 42: Using The Shutter Priority Mode
Using the Aperture Priority, Shutter Priority, or Manual mode Using the Shutter Priority mode The Shutter Priority mode lets you set the shutter speed manually while the camera automatically selects an appropriate aperture value. Rotate the Mode dial to S. Rotate the dial to adjust the shutter speed.
Page 43: Using The Manual Mode
Using the Aperture Priority, Shutter Priority, or Manual mode Using the Manual mode In the manual mode, you can take pictures by setting various shot options directly including the shutter speed and aperture value. Rotate the Mode dial to M. Rotate the dial to adjust the shutter speed.
Page 44 Using the Aperture Priority, Shutter Priority, or Manual mode Using the bulb exposure By using the bulb exposure, you can set the shutter speed as long as you want. Rotate the Mode dial to M. Rotate the dial and set the shutter speed to Bulb.
Page 45: Using The Night/Portrait/Landscape Mode
Using the Night/Portrait/Landscape mode Using the night mode Night mode provides the optimal exposure settings for dark or night time environments. Rotate the Mode dial to Align your subject in the frame and half- press [Shutter] to focus. Press [Shutter] to take a photo. When you use Night mode, we recommended you also use a tripod, shutter release, or Timer function (purchased separately) to minimize camera shake.
Page 46: Using The Scene Mode
Using the Scene mode Since an appropriate option is set in advance by the scene, the shot can be taken conveniently by selecting a scene appropriate for the situation. Rotate the Mode dial to Select a scene. Press [MENU] to select a scene. You can select a desired scene.
Page 47: Using The Beauty Shot Mode
Using the Scene mode Using the Beauty Shot mode In the beauty shot mode, you can take pictures with options that make faces appear smooth and blemish- free. Rotate the Mode dial to Press [MENU]. Select Shooting1 ( Beauty Shot. Select Shooting3 ( Set options.
Page 48: Recording A Movie
Recording a Movie In the movie shooting mode, you can shoot videos in High Deﬁnition quality (1280x720). You can continue recording movies up to 25 minutes. The recorded video is saved as an H.264 (MPEG-4.AVC) ﬁle. Rotate the Mode dial to Press [MENU].
Page 49: Using The Wind Cut
Recording a Movie • When you use the Fader function, it may takes longer to save images. Using the Wind Cut Use the wind noise removal function to remove some surrounding noise in addition to the wind noise. In the Shooting mode, press [MENU]. Select Shooting3 ( an option.
Page 50: Extended Shooting Functions
Extended shooting functions Learn about the options you can set in shooting mode. By using the shooting options, you can enjoy more customized pictures and movies. Setting the resolution and quality …………………… 51 Using the timer function ……………………………… 54 Taking a picture in the dark place …………………… 55 Focusing methods ……………………………………...
Page 51: Setting The Resolution And Quality
Setting the resolution and quality You can also set the Resolution function by pressing [Fn] in the shooting mode. Setting a resolution To capture the high level of detail and excellent image quality in your picture or video, it is a good idea to set the resolution to the highest setting.
Page 52: Setting The Image Quality Of The Picture
If you want to save the RAW data into an image ﬁ le format such as JPEG or TIFF, use the provided software (SAMSUNG RAW Converter). RAW ﬁ les have an "SRW" extension. (For example: “SAM_9999.SRW”) ) → Quality →...
Page 53: Noise Reduction
Setting the resolution and quality Noise reduction This function can be set to reduce the noise in pictures. In the Shooting mode, press [MENU]. Select User setup ( Reduction → an option. High ISO NR Long Term When the Noise reduction function is disabled, there might be a noise in the recorded picture.
Page 54: Using The Timer Function
Using the timer function The function can be set directly by pressing [ Setting the timer function In the Shooting mode, press [MENU]. Select Shooting 2 ( Press [Fn] after selecting Timer. Select the operation time by rotating the dial or pressing [ •...
Page 55: Taking A Picture In A Dark Place
Taking a picture in a dark place The function can be set directly by pressing [Fn] in the shooting mode. Using the ﬂash popup button The ﬂash operates when you pop-up the built-in ﬂash by pressing the ﬂash button. When the ﬂash is closed, it will not burst out the light and the modes support automatic popup and ﬂash light.
Page 56: Using The Red-Eye Fix Function
Taking a picture in a dark place Using the red-eye ﬁx function When you take a portrait using the ﬂash, the bright burst of light can cause the red-eye effect. To prevent the red eye effect, set the ﬂash option to Auto+Red or Fill-in Red.
Page 57: Adjusting The Amount Of Flash Light
Taking a picture in a dark place Adjusting the amount of ﬂash light When setting a ﬂ ash option, you can adjust the brightness of the ﬂash. In the Shooting mode, press [MENU]. Select Shooting 2 ( Press the [Fn] button after selecting a desired item.
Page 58: Using An External Flash Unit (Purchased Separately)
Taking a picture in a dark place Using an external ﬂash unit (purchased separately) You can use the A-TTL auto ﬂ ash mode when you attach an external ﬂ ash unit (SEF20A or SEF42A) to the camera. This section of the user manual was prepared based on the model SEF20A ﬂash.
Page 59: Adjusting The Iso Sensitivity
Taking a picture in a dark place Adjusting the ISO sensitivity The ISO sensitivity, as the ﬁlm sensitivity established by the international standards organization (ISO), represents the degree of reaction when camera receives light. Since it reacts more sensitively with greater ISO value, a natural shot can be obtained in a dark place by raising the ISO value.
Page 60: Focusing Methods
Focusing methods Changing the Focusing methods You can select a focusing method appropriate to the subject you are photographing. In the Shooting mode, press [MENU]. Select Shooting 2 ( → an option. When you press [shutter] half way Single AF down, the focus ﬁxes in one position.
Page 61: Using The Af Assist Light
Focusing methods Using the AF assist light The auto focus functions more accurately in dark places when the AF assist light is on. In the Shooting mode, press [MENU]. Select User setup ( ) → AF Lamp. AF assist light not used AF assist light turns on when light is not sufﬁcient.
Page 62: Setting The Focus Of The Selected Area
Focusing methods Setting the focus of the selected area In the shooting composition, a shot may be taken by setting the focus to the area desired by user. In the Shooting mode, press [MENU]. Select Shooting 2 ( Selection AF. AF Mode AF Area AF Priority...
Page 63: Setting The Mf Assist
Focusing methods Setting the MF Assist When the lens’ focus method is set to Manual Focus (MF), this function helps focus the subject by expending the screen automatically. Set the focus method to Manual Focus. Select Shooting 2 ( Select a desired option. AF Mode AF Area AF Priority...
Page 64: Face Detection Af
Face detection When you use the Face Detection AF function, you can set the focus around a person's face when taking a portrait shot. This function can also be useful when shooting a self-portrait. Normal face detection When you use the Face Detection AF option, the camera sets the auto focus based on the faces in the frame.
Page 65: Self-Portrait Face Detection
Face detection Self-portrait face detection With Self-Portrait AF on, the camera chirps rapidly when your face is in focus. In the Shooting mode, press [MENU]. Select Shooting 2 ( Self-Portrait AF. Press [Shutter] if having an info sound of shooting. Check the focus of the subject in Shooting mode ) →...
Page 66: Brightness And Color Adjustment Of Picture
Brightness and color adjustment of picture Adjusting the exposure (brightness) The images can be taken bright or dark according to the amount of light. In this case, appropriate adjustment can be made by controlling the amount of light entered into the lens.
Page 67: Metering
Brightness and color adjustment of picture Changing the brightness measurement method If the composition of image is set, the camera measures the amount of light. At this time, the brightness and overall mood of the picture may vary depending on how the measurement is made.
Page 68: Setting The White Balance
Brightness and color adjustment of picture Setting the white balance Different light sources will affect the resulting color of your picture. To take a picture with colors close to what is seen with our own eyes, please select the white balance appropriate for the light source or manually adjust the color temperature desired.
Page 69 Brightness and color adjustment of picture Fine adjustment of the white balance In the Shooting mode, press [MENU]. Select Shooting 1 ( Balance. Select a White Balance option, and then press [Fn]. WB Adjust MENU Back Adjust a desired white balance by using the dial or [ / / / ].
Page 70 Brightness and color adjustment of picture Adjusting the color temperature You can change the white balance by adjusting the color temperature. In the Shooting mode, press [MENU]. Select Shooting 1 ( Balance. Select the Color Temp. option, and then press [Fn]. Set the color temperature by rotating the dial or pressing [ / ].
Page 71: Color Space
Brightness and color adjustment of picture Color space You can set the color space the camera uses. Press [MENU] in the shooting mode. Select Shooting 1 ( → an option. sRGB Adobe RGB • When you set the color space to Adobe RGB, the camera saves picture ﬁles in the "_SAMXXXX.JPG"...
Page 72: Smart Range
Brightness and color adjustment of picture Smart range Smart Range automatically corrects for the loss of bright detail that can occur due to shading differences in the picture. ▲ Canceling smart range ▲ Use of smart range In the Shooting mode, press [MENU]. Select Shooting 3 ( →...
Page 73: Changing The Shooting Method
Changing the shooting method It can be difﬁcult to take a picture of a fast moving object, a quick facial expression, or the rapid motion of a person. In this case, please select the successive shooting option appropriate for the situation. Successive shooting method and timer setup You can select the successive shooting option...
Page 74: Detailed Bracket Setup
Changing the shooting method Detailed bracket setup The details for the exposure, white balance and picture wizard of bracket shot can be set. Press [MENU] in the shooting mode. Select Shooting 3 ( an option. BKT Set AE BKT Set WB BKT Set P Wiz BKT Set Exit...
Page 75: Special Effect/Photo Retouching
Special effect/photo retouching Picture wizard The Picture Wizard function lets you select various looks and emotional moods for your pictures. Example Standard Landscape Cool Vivid Portrait Forest Retro Calm Classic In the Shooting mode, press [MENU]. ) → Picture Select Shooting 1 ( Wizard →...
Page 76 Special effect/photo retouching Custom picture wizard setup You can choose the customize options and then save images in 3 different ways. In the Shooting mode, press [MENU]. Select Shooting 1 ( Wizard → Custom → an option. ■ Exit MENU Adjust the Picture Wizard value by using [ / / / ] •...
Page 77: Key Mapping
Key Mapping Setting Key Mapping The function of camera button can be changed. In the Shooting mode, press [MENU]. Select User setup ( → an option. Preview • While shooting a movie, push the [Depth Preview] button once to activate the AF function and once again to cancel the function.
Page 78: Playback/Editing
TV, or HDTV. Play (picture/movie) …………………………………… 79 Picture editing ………………………………………… 87 Viewing ﬁles on a TV or HDTV ………………………… 91 Transferring ﬁles to your computer ………………… 93 Using the Samsung RAW Converter ………………… 99 Printing photos with a photo printer (PictBridge) ………...
Page 79: Play (Picture/Movie)
Play (picture/movie) Viewing pictures in the play mode You can view saved pictures and movies. Press [ • Shows most recently saved ﬁle. View the pictures sequentially using [ / ]. • When the playback screen is selected more than once, the last shown picture or movie is selected to be shown during playback.
Page 80 Play (picture/movie) 1/40 Shot image RGB histogram Shooting mode, metering, ﬂash, white balance, picture wizard, focal length Shutter speed, aperture value, ISO, selected ﬁle/total number of ﬁles/ battery information 18mm 4592 X 3056 2010.01.01 F3.5 00004/00009 Movie playback information screen 100-0001 Video size 1280 X 720...
Page 81: Smart Album
Play (picture/movie) View ﬁles in the smart album by category The ﬁles can be classiﬁed and shown by the ﬁle, date (day), date (week), and type. In Playback mode, press [ Press [MENU]. Select a desired playback method. Filter MENU Type Date Week...
Page 82: File Protection
Play (picture/movie) File protection You can protect ﬁles from accidental deletion. Press [AEL] in the play mode. appears on the display. Press [AEL] to cancel. Deleting a ﬁle Files can be selected and deleted in the play mode. The function can be set by pressing [MENU] in the playback mode.
Page 83 Play (picture/movie) Deleting all ﬁles All the ﬁles saved in the memory card can be deleted at once. In Playback mode, press [MENU]. Select Playback [ From the popup window, select Yes. Auto rotate Show the pictures taken in the vertical frame by rotating them automatically while in playing.
Page 84: Enlargement/Reduction
Play (picture/movie) Enlargement/reduction A picture can be enlarged when searching in play mode. Enlargement x1.7 Full Image Move enlargement on screen Trim the enlarged image Press [ ] to enlarge. (Press [ ] to reduce) Magniﬁed part Magniﬁcation (The maximum magniﬁcation may differ by resolution) Trim...
Page 85: View A Movie
Play (picture/movie) Set to a desired option. Select Slide Show → Play. • To play the slide show repeatedly, please select the repeat option. Watch the slide show • To stop slide show, press [ ] and then press [ / ]. Pause/Play Press the [ ] button.
Page 86 Play (picture/movie) Capturing a picture You can capture a frame of the movie as a picture while playing back the movie. Press [ ] in the play mode. Press [ ] while playing a movie. Press [ ] in the pause state. •...
Page 87: Picture Editing
Picture editing Pictures can be edited in various ways by using the edit menu. The function can be set directly by pressing [Fn] in the shooting mode. Changing the resolution After selecting a desired picture in the play mode, press [MENU]. Select Image Edit →...
Page 88: Photo Style
Picture editing Red-eye ﬁx After selecting a desired picture in the play mode, press [MENU]. Select Playback [ Red-eye Fix. Adjusting the backlight After selecting a desired picture in the play mode, press [MENU]. Select Playback [ Backlight. Picture style Selecting picture style allows you to express various moods of emotion in your picture.
Page 89: Setting The Print Info (Dpof)
Picture editing Setting the print info (DPOF) The size and number of copies to be printed can be designated for the picture. Since the designated information is saved in the MISC folder of memory card, it is convenient to print the designated size and number of copies while using the pictures of designated info simply by taking the memory card to a digital printing shop.
Page 90 Picture editing Select [MENU] → DPOF → SIZE in the playback mode. Select an option Select desired print size according to the Select picture. Select the print size of all the pictures saved in the memory card. Initializing the print size option Reset When having selected the select option, select the picture to be printed and press...
Page 91: Viewing Files On A Tv Or Hdtv
Viewing files on a TV or HDTV Play back photos or videos by connecting your camera to a TV using the provided A/ V cable. Viewing ﬁles on a regular TV Select a video signal output according to your country or region. (p. 108) Connect the TV and the camera using the A/V cable.
Page 92: Viewing Files On A Tv Or Hdtv
Viewing ﬁles on a TV or HDTV Viewing ﬁles on an HDTV Select a video signal output according to your country or region. (p. 108) In Shooting or Playback mode, select [MENU] → Setting 3 ( → an option. Connect the HDTV and the camera using the HDMI cable.
Page 93: Transferring Files To Your Computer
• The programs may not work properly on 64-bit Edition of Windows XP, Vista and 7. Programs contained on the CD Program Purpose Intelli-studio Edit photos and videos. Samsung RAW Convert RAW ﬁles into the Converter desired ﬁle format.
Page 94 Transferring ﬁles to your computer Insert the installation CD in a compatible CD- ROM drive. When the setup screen is displayed, click Samsung Digital Camera Installer to start installation. Select programs to install, and follow the onscreen instructions. Click Exit to complete the installation, and then restart your computer.
Page 95 Transferring ﬁles to your computer Turn on the camera. • In the popup window, select Computer. On your PC, select My Computer Removable Disk select "XXX_MMDD" folder. Select the ﬁles you want, and then drag or save them to your PC. •...
Page 96: For Mac Users
If the cable is reversed, it may damage your ﬁles. The manufacturer is not responsible for any loss of data. • Please use only the accessories that SAMSUNG provides. The manufacturer takes no responsibility for any loss of ﬁles or damage that may result from the use of other manufacturer’s product.
Page 97: Using Intelli-Studio
Transferring ﬁles to your computer Using Intelli-studio Once you have installed the Intelli-studio on your PC, the Intelli-studio starts automatically when a camera is connected with your PC. If the Intelli-studio does not start after you have connected the camera to your PC, double-click the Intelli-studio icon on your Windows desktop.
Page 98: Transferring Files Using Intelli-Studio
Transferring ﬁles to your computer Icon Open menus Display ﬁles in the selected folder Change to the Photo edit mode Change to the Video edit mode Change to the Sharing mode (You can send ﬁles by email or upload ﬁles to websites, such as Flickr or YouTube.) Enlarge or reduce the thumbnails in the list...
Page 99: Using The Samsung Raw Converter
Displays the color layers of the selected image. ⑤ Ð Preview window Displays the selected image. • Refer to the [Help] menu in the Samsung RAW Converter for further information. • You can download the Samsung RAW Converter program for Macintosh from the Samsung website. value.
Page 100: Correcting The Exposure
Using the Samsung RAW Converter Correcting the exposure The main feature of the Samsung RAW Converter is that you can keep the best quality of the images as you make changes to the RAW ﬁles while editing. After making changes to the brightness or contrast, you can still obtain the same result no matter which you change ﬁrst.
Page 101: Handling The Jpeg/Tiff Files As You Edit Raw Files
Using the Samsung RAW Converter Handling the JPEG/TIFF ﬁles as you edit RAW ﬁles Using the Samsung RAW Converter, you can edit JPEG/TIFF ﬁles in the same way you edit RAW ﬁles. You can adjust the white balance, sharpness, and reducing the noise is also available.
Page 102: Printing Photos With A Photo Printer (Pictbridge)
Printing photos with a photo printer (PictBridge) Print photos with a PictBridge-compatible printer by connecting your camera directly to the printer. With the printer on, connect your camera to the printer with a USB cable. Turn on your camera. • Select Printer in the popup window.
Page 103: Camera Settings Menu
Camera settings menu You can set the camera use environment using the setup menu. Camera settings menu ……………………………… 104...
Page 104: Camera Settings Menu
Camera settings menu You can set the camera use environment using the setup menu. Press [MENU] in the shooting or play mode. Select a desired setup menu Quickview Display Adjust Display Save Power Save Date&Time Sound Exit MENU Select a desired item Sound System Volume AF Sound...
Page 105: Sound
Camera settings menu Sound System Volume AF Sound Button Sound Display Language Display Adjust Display Save Quickview You can set the camera use environment using the setup menu. (Off, Low, Medium*, High) Sets the sound the camera makes in AF mode on or off. (Off, On*) Sets the sound the camera makes when you press buttons on or off.
Page 106: Normal Setup 1
Camera settings menu Normal setup 1( This formats the memory card (deleting all the ﬁles including protected ﬁles). (Yes, No*) Format This resets the setup menu and shooting options. (The date, time, language, and video output value Reset are kept.) (Yes, No*) This sets the method of designating ﬁlename.
Page 107: Normal Setup 2
Camera settings menu Normal setup 2( This sets the power turned off automatically if not being used for a while. (0.5 min, 1min*, 3min, 5min, 10min, 30min) Power Save This sets the date and time. (Type, Date, Time Zone, Time, Imprint) Date &...
Page 108: Normal Setup 3
• You can download ﬁrmware upgrades from www.samsungimaging.co.kr or www.samsung.com. • You can upgrade the ﬁrmware by downloading it from www.samsung.com. • You can not run a ﬁrmware upgrade without a fully charged the battery. Recharge the battery fully before •...
Page 109: Appendixes
Appendixes Refer to error messages, speciﬁcations, and maintenance tips. Error messages ……………………………………… 110 Camera maintenance ………………………………… 111 Before contacting a service center …………………… 115 Camera speciﬁcations ………………………………… 118 Lens speciﬁcations …………………………………… 122 Accessories (optional items) ………………………… 123 Index …………………………………………………… 125...
Page 110: Error Messages
Error messages When the following error messages appear, try these remedies. Error message Suggested remedies Card Error • • • Card Locked Unlock the memory card. DCF Full Error File names do not match the DCF standard. Transfer the ﬁles on the memory card to your computer and format the card.
Page 111: Camera Maintenance
Camera maintenance Cleaning your camera Camera lens and display Use a blower brush to remove dust and wipe the lens gently with a soft cloth. If any dust remains, apply lens cleaning liquid to a piece of lens cleaning paper and wipe gently.
Page 112: About Memory Cards
Camera maintenance About memory cards Memory cards you can use You can use SD (Secure Digital) and SDHC (Secure Digital High Capacity) memory cards. Terminal Write-protect switch Label (front) You can prevent ﬁles from being deleted by using the write-protect switch on the SD or SDHC card. Slide the switch down to lock or slide it up to unlock.
Page 113: About The Battery
Shooting mode Photos BP1310 Videos Lithium-ion battery • The ﬁgures above are measured by Samsung’s standards and 1300 mAh may differ depending on actual usage. • The shooting time may change depending on the shooting 7.4 V environment and shot intervals.
Page 114 When using the battery, please keep the following guidelines. Failure to follow these guidleline may cause excessive heat, ﬁre, or explosion. If the battery is bulging or distorted, contact a Samsung service center. It may present a physical danger. It may present physical dangers.
Page 115: Troubleshooting
If you are having trouble with your camera, try these troubleshooting procedures before contacting a service center. If you have attempted the troubleshooting solution and are still having problems with your device, contact your local dealer or authorized Samsung service center. Situation...
Page 116 Before contacting a service center Situation The date and time are incorrect The display or buttons do not work The memory card has an error The memory card has not been reset. Format the card. (p. 106) Cannot play back ﬁles The photo is blurry The colors in the photo do not match the actual scene...
Page 117 Before contacting a service center Situation The TV does not display your photos Your computer does not recognize your camera Your computer disconnects the camera while transferring ﬁles Suggested remedies • Make sure that the camera is correctly connected to the TV with the A/V and HDMI cable.
Page 118: Camera Specifications
Diopter Adjustment Specification CMOS Focusing 23.4×15.6mm Approx. 14.6 Mega-pixels Approx. 15.1 Mega-pixels RGB primary color filter Samsung NX Mount Samsung Lenses Lens Shift (depends on Lens) Shutter 3.0” QVGA (320x240). Approx. 230K dots Field of view : Approx. 98% QVGA Class (300X220).
Page 119: Red-Eye Reduction
28mm wide-angle Coverage (Equivalent to 35mm) Sync. Speed Less than 1/180sec. Flash -2 - +2EV (0.5EV step) Compensation External Flash Samsung External Flash available (SEF42A, SEF20A) (optional) Synchro Hot Shoe (Flash attachment) Modes Auto, Daylight, Cloudy, Fluorescent (W, N, D),...
Page 120 Camera speciﬁcations Shooting Modes Scene Mode Image Size Quality RAW Format Color Space Speciﬁcation Smart Auto, Program, Movie Shutter Priority AE, Aperture Priority AE, Manual, Night, Portrait, Landscape, Scene, Movie Beauty shot, Children, Close Up, Text, Sunset, Dawn, Backlight, Fireworks, Beach &...
Page 121 * Included battery may vary depending on sales region 123×87×39.8mm Dimensions (excluding the projecting (WxHxD) parts of the camera) 345g (without batteries and Weight card) Operating 0 ~ 40 °C Temperature Operating 5 ~ 85% Humidity Intelli-studio, Samsung RAW Application Converter...
Page 122: Lens Speciﬁcations
Max. Diameter x Length Weight Operating Temperature Operating Humidity The lens provided may differ by the model. SAMSUNG 18-55mm SAMSUNG 30mm F2 F3.5-5.6 OIS 18 - 55mm (equivalent to 30mm (equivalent to 27.7-84.7mm in 35mm 46.2mm in 35mm format) format)
Page 123: Accessories (Optional Items)
Accessories (optional items) Lens Make better pictures with a 30mm, 18-55mm, or 50-200mm lens made exclusively for the Samsung NX-series camera. Memory card In this camera, the memory cards such as SD (Secure Digital) and SDHC (Secure Digital High Capacity) may be used.
Page 124 Accessories(optional items) Strap Straps can be purchased separately. Camera bag Camera bag can be purchased separately. Filter Optional ﬁlters can be purchased and attached to the lens. Flash Optional ﬂash(SEF20A or SEF42A) can be purchased for your various shooting experience. HDMI Cable You can view high-quality and uncompressed photos or videos on an HDMI (High Deﬁnition Multimedia Interface) using the optional HDMI cable.
Page 125: Adjusting Exposure
Index Adjusting exposure 5 Automatic focus 34 Aperture priority mode 41 Aperture value 41 AF Priority 60 AF assist light 61 AE BKT 73 AEL function 77 AF Sound 105 Anynet+ 108 Appendixes 109 Accessories (optional items) 123 Background 7 Bulb exposure 44 Bracket setup 74 Backlight adjustment 88...
Page 126 Print info 89 Photo printer 102 PictBridge 102 Power save 107 Quality 52 Quickview 105 Samsung Raw Converter 99 System volume 105 Recording a movie 48 Resolution 51 Red-eye reduction 56 Title and role of each part 14 Rotating 87 Turning on the power 23 Red-eye ﬁx 88...
Page 127 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Planet First Planet First represents Samsung Electronics' commitment to the sustainable development and social responsibility through eco-driven business and management activities.
Page 128 Please refer to the warranty that came with your product or visit our website http://www.samsungimaging.com for after-sales service or inquiries.

Samsung NX5 User Manual

Quick Links

Related Manuals for Samsung NX5

Summary of Contents for Samsung NX5

Table of Contents
