Summary of Contents for Samsung SyncMaster 961GW

  • Page 1 SyncMaster 961GW...
  • Page 2 Notation Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment. Prohibited Do not disassemble Do not touch Power When not used for extended period of time, set your computer to DPMS. If using a screen saver, set it to active screen mode.
  • Page 3 This may cause electric shock or fire. Do not pull the plug out by the wire nor touch the plug with wet hands. This may cause electric shock or fire. Use only a properly grounded plug and receptacle. An improper ground may cause electric shock or equipment damage. (Class l Equipment only.) Insert the power plug firmly so that it does not come loose.
  • Page 4 This may cause electric shock or fire. Installation Be sure to contact location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24 hours such as at airports, train stations etc. Failure to do so may cause serious damage to your monitor.
  • Page 5 Keep any heating devices away from the power cable. A melted coating may cause electric shock or fire. Do not install the product in places with poor ventilation, for instance, a bookshelf, closet, etc. Any increase in the internal temperature may cause fire. Put down the monitor carefully.

  • Page 6: Cleaning And Using

    Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. Contact the SAMSUNG customer care center or Customer Center cleaning once a year. Keep the product's interior clean. Dust which has accumulated in the interior over an extended period of time may cause a malfunction or fire.
  • Page 7 Others Do not remove the cover (or back). This may cause electric shock or fire. Refer to a qualified servicing company. If your monitor does not operate normally - in particular, if there is any unusual sound or smell coming from the monitor - unplug it immediately and This may cause electric shock or fire.
  • Page 8 Do not place water containers, chemical products or small metal objects on the monitor. This may cause a malfunction, electric shock or fire. If a foreign substance enters the monitor, unplug the power cord and contact Service Center. Keep the product away from combustible chemical sprays or inflammable substances.
  • Page 9 Do not install the product on an unstable, uneven surface or a location prone to vibrations. Dropping the product may cause damage to the product or the person carrying it. Using the product in a location prone to vibrations may shorten the lifetime of the product or may cause the product to catch fire.
  • Page 10 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.

  • Page 11: Product Information (Image Retention Free)

    PRODUCT INFORMATION (Image Retention Free) LCD Monitors and TVs may have an image retention when switching from one image to another especially after displaying a stationary image for a long time. This guide is to demonstrate a correct usage of LCD products in order to protect them from Image retention.
  • Page 12 The best way to protect your monitor from Image retention is to set your PC or System to operate a Screen Saver program when you are not using it. Image retention may not occur when a LCD panel is operated under normal conditions. Normal conditions are defined as continuously changing video patterns.

  • Page 13: Package Contents

    Features RTA Monitor RTA (Response Time Accelerator) A function that accelerates the response speed of the panel so as to provide a sharper and more natural video display. RTA On Activates the RTA function so that the panel operates at a higher response speed than its original speed.

  • Page 14: Your Monitor

    Warranty Card User's Guide, Monitor Driver, Quick Setup Guide (Not available in all Natural Color software, locations) MagicTune™ software Cable Power Cord D-sub Cable Sold separately DVI Cable This is an accessory that can be added depending on the model. Your Monitor Front...
  • Page 15 MENU button [ Opens the on-screen menu and exits from the menu. MagicBright™ button MagicBright™ is a new feature providing optimum viewing environment depending on the contents of the image you are watching. Currently seven different modes are available: Custom, Text, Internet, Game, Sport and Movie, Dynamic Contrast.
  • Page 16 Not available in MagicBright mode of Dynamic Contrast. Adjust buttons [ Adjust items in the menu. Enter button [ Activates a highlighted menu item. / Push the 'SOURCE', then selects the video signal while the OSD is SOURCE button off. (When the SOURCE button is pressed to change the input mode, a message appears in the upper left of the screen displaying the current mode -- analog or digital input signal.) If you select the digital mode, you must connect your monitor to the...

  • Page 17: Connecting Cables

    Connecting Cables Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. Use a connection appropriate to the computer you are using. Using the D-sub (Analog) connector on the video card.

  • Page 18: Using The Stand

    Using the Stand Folding the base When tilting the screen backwards, do not tilt it more than 60 degrees.
  • Page 19 If you tilt the monitor so far upwards that the base is closer to you than the top, it may fall over backwards. Swivel stand Using ( ),You can swivel the monitor left and right at an angle of 340 ° to set the monitor lengthwise. The rubber under the stand is to avoid the monitor slide.

  • Page 20: Monitor Driver

    Choose your monitor model in the model list, then click the "OK" button. If you can see following message window, then click the "Continue Anyway" button. Then click the ® "OK" button (Microsoft Windows :http://www.samsung.com/ (Worldwide) http://www.samsung.com/monitor (U.S.A) http://www.sec.co.kr/monitor (Korea) http://www.samsungmonitor.com.cn/...
  • Page 21 This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Monitor driver installation is completed. Installing the Monitor Driver (Manual) Windows Vista Windows XP Windows 2000 ®...
  • Page 22 This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Click "Update Driver…" in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
  • Page 23 Click "Close"→ "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System Insert the CD into the CD-ROM drive. Click "Start" → "Control Panel" then click the "Appearance and Themes" icon. Click "Display"...
  • Page 24 Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver." and select "Install from a list or." then click the "Next" button. Select "Don't search ,I will." then click "Next" and then click "Have disk". Click the "Browse"...
  • Page 25 "OK" button. This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Click the "Close" button then click the "OK" button continually. Monitor driver installation is completed.
  • Page 26 How to install Click "Start," "Setting," and then "Control Panel." Double click the "Display" icon. Select the "Settings" tab and click the "Advanced Properties" button. Choose "Monitor." Case1 : If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation Case2 : If the "Properties"...

  • Page 27: Natural Color

    Samsung Electronics in association with Korea Electronics & Telecommunications Research Institute (ETRI). This is only available for Samsung monitors and ensures that the color of the images on the monitor are the same as the printed or scanned images.
  • Page 28 5. Select "I agree to the terms of the license agreement" to accept the terms of use. 6. Choose a folder to install the MagicTune™ program. 7. Click "Install." 8. The "Installation Status" window appears. 9. Click "Finish." 10. When the installation is complete, the MagicTune™ executable icon appears on your desktop. Double-click the icon to start the program.
  • Page 29 6. Wait until the "Uninstall Complete" dialog box appears. Visit the MagicTune™ website for technical support for MagicTune™, FAQs (questions and answers) and software upgrades.

  • Page 30: Control Buttons

    Control Buttons ] Opens the OSD menu. Also use to exit the OSD menu or return to the previous menu. ] These buttons allow you to adjust items in the menu. ] Press this button to activate a highlighted menu item. [AUTO] When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center.
  • Page 31 Menu When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center. Auto adjustment allows the monitor to self-adjust to the incoming Analog signal. The values of fine, coarse and position are adjusted automatically. (Available in Analog mode only) To make the automatic adjustment function sharper, execute the 'AUTO' function AUTO...
  • Page 32 In case of pushing MENU button after locking OSD Menu This is the function that locks the OSD in order to keep the current states of settings or prevent others from adjusting the current settings. Locked : Hold down the menu button for more than five seconds to activate the OSD adjustment lock function.
  • Page 33 Menu Push the MagicBright™ button to circle through available preconfigured modes. MagicBright™ - seven different modes (Custom/Text/Internet/Game/Sport/Movie/Dynamic Contrast) Brightness Menu Brightness When OSD is not on the screen, push the button to adjust brightness. Description Description...

  • Page 34: Osd Function

    SOURCE Menu SOURCE Selects the Video signal while the OSD is off. (Analog/Digital) OSD Function Brightness Picture Color MagicColor Coarse Image Language Setup Auto Source Information Picture : Not available in MagicBright mode of Dynamic Contrast. Description Contrast Color Tone Color Control Gamma Fine...
  • Page 35 Menu You can use the on-screen menus to change the brightness according to personal preference. Brightness MENU → → You can use the on-screen menus to change the contrast according to personal preference. Not available in MagicColor mode of Full and Intelligent. Contrast MENU →...
  • Page 36 MagicColor is a new technology that Samsung has exclusively developed to improve digital image and to display natural color more clearly without disturbing image quality. Returns to the original mode. Demo The screen before applying MagicColor appears MagicColor on the right and the screen after applying MagicColor appears on the left.
  • Page 37 menu. MENU → → Removes noise such as horizontal stripes. If the noise persists even after fine tuning, repeat it after Fine adjusting the frequency (clock speed). MENU → → Changes the clearance of image. Not available in MagicColor mode of Full and Sharpness Intelligent.
  • Page 38 You can change the vertical position where the OSD menu appears on your monitor. V-Position MENU → → Change the transparency of the background of the OSD. Transparency MENU → → The menu will be automatically turned off if no adjustments are made for a certain time period.
  • Page 39 MENU → → → → → → MENU Information Menu Description Shows a video source, display mode on the OSD screen. Information MENU →...
  • Page 40 Menu Description Shows a video source, display mode on the OSD screen. Information MENU →...

  • Page 41: Check List

    Check List Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your Symptom Check List No images on the Is the power cord screen.
  • Page 42 Is the power indicator on the monitor blinking at 1 second intervals? Connected using the DVI cable? I cannot see the Have you locked On Screen the On Screen Display. Display (OSD) Menu to prevent changes? The screen shows Is the screen strange colors or displaying only one just black and...
  • Page 43 Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.com/monitor/magictune Download the latest program. The program can be downloaded http://www.samsung.com/monitor/magictune Reboot the computer after installing the program for the first time.
  • Page 44 How can I set the Power Saving function? How can I clean the outer case/LCD Panel? Self-Test Self-Test Feature Check Warning Messages Your monitor provides a self test feature that allows you to check whether your monitor is functioning properly. Self-Test Feature Check Turn off both your computer and the monitor.
  • Page 45 If there is something wrong with the input signal, a message appears on the screen or the screen goes blank although the power indicator LED is still on. The message may indicate that the monitor is out of scan range or that you need to check the signal cable. Environment The location and the position of the monitor may influence the quality and other features of the monitor.

  • Page 46: Specifications

    Specifications General Model Name SyncMaster 961GW LCD Panel Size 19 " Wide Diagonal (48 cm) Display area 408.24 mm (H) x 255.15 mm (V) Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V) Synchronization Horizontal 30 ~ 81 kHz Vertical 56 ~ 75 Hz Display Color 16.7M...
  • Page 47 Humidity : 5 % ~ 95 %, non-condensing Power saving mode Blue Blue, Blinking Less than 1 W ® compliant and ENERGY2000 ® Partner, SAMSUNG has determined that this ® guidelines for energy efficiency. Power off EPA/ENERGY 2000 Less than 1 W...

  • Page 48: Preset Timing Modes

    Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Horizontal Display Mode Frequency...
  • Page 49 repetition is called the Vertical Frequency or Refresh Rate. Unit : Hz...
  • Page 50 Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. North America U.S.A 1-800-SAMSUNG (7267864) CANADA 1-800-SAMSUNG (7267864) MEXICO 01-800-SAMSUNG (7267864) Latin America ARGENTINE 0800-333-3733 BRAZIL 4004-0000 CHILE 800-726-7864 (SAMSUNG)
  • Page 51 BELGIUM 02 201 2418 CZECH REPUBLIC 844 000 844 DENMARK 70 70 19 70 FINLAND 030-6227 515 3260 SAMSUNG(7267864) (€ FRANCE 0,15/min) GERMANY 01805 - 121213 (€ 0,14/Min) HUNGARY 06-80-SAMSUNG (7267864) ITALIA 800 SAMSUNG (7267864) LUXEMBURG 0032 (0)2 201 24 18 NETHERLANDS 0900 20 200 88 (€...
  • Page 52 TAIWAN 0800-329-999 VIETNAM 1 800 588 889 Middle East & Africa SOUTH AFRICA 0860 7267864 (SAMSUNG) 800SAMSUNG (7267864) U.A.E 8000-4726 Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution.

  • Page 53: For Better Display

    Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 54 MÉXICO IMPORTADO POR: SAMSUNG ELECTRONICS MÉXICO. S.A. de C.V. Vía Lopez Portillo No. 6, Col. San Fco. Chilpan Tultitlán, Estado de México, C.P. 54940 Tel: 01-55-5747-5100 / 01-800-726-7864 EXPORTADO POR: Samsung Electronics CO.,LTD. 416, Mae tan-3dong, Yeongtong - gu, Suwon City, Gyeonggi-do Korea...
