DANGER!
DANGER
IF YOU SMELL GAS:
•
•
•
WARNING!
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
N415-0390 MAY 09.18
CARBON MONOXIDE HAZARD
Wolf Steel Ltd.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
grills@napoleonproducts.com
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
PATIOFLAME
OUTDOOR GAS FIREPIT
VICT1 (GPFR40)
VICT2 (GPFS40)
VICT3 (GPFC40)
WARNING
www.napoleongrills.com
EN
FR
PG.41
Advertisement
Related Manuals for Napoleon PATIOFLAME VICT1
Summary of Contents for Napoleon PATIOFLAME VICT1
- Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. PG.41 DO NOT DISCARD PATIOFLAME OUTDOOR GAS FIREPIT VICT1 (GPFR40) VICT2 (GPFS40) VICT3 (GPFC40) DANGER! CARBON MONOXIDE HAZARD DANGER WARNING IF YOU SMELL GAS: • • • WARNING! INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
- Page 2 NAPOLEON. NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and workmanship from the date of purchase, for the following period: Aluminum table top and pedestal ............
- Page 3 WARNING! WARNING! • THIS APPLIANCE IS HOT WHEN OPERATING AND CAN CAUSE SEVERE BURNS IF CONTACTED. • • • • • • Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot surfaces. • • Keep the packaging material out of reach of children and dispose of the material in a safe manner. As •...
- Page 4 • • 1/2 psig (3.5kPa). • Always keep the appliance area clear and free • Do not locate appliance where it can get excessively wet. • Do not use this appliance if any part has been service technician to inspect the unit and to replace any part of the control system and any gas control, which has been underwater.
- Page 5 DIMENSIONS VICT1 52” (132 cm) 25” (64 cm) 32” (82 cm) VICT2 42” (107 cm) 25” (64 cm) 42” (107 cm) VICT3 42” (107 cm) 25” (64 cm) N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 6 INPUT MINIMUM CLEARANCE TO COMBUSTIBLES MODEL FUEL MAX. INPUT Btu/Hr INCHES VICT1 Natural Gas 40, 000 Side Walls VICT2 Top of unit to ceiling 1830 VICT1 Propane Gas 40, 000 VICT2 VICT3 Natural Gas 40, 000 GAS INLET PRESSURES NATURAL PROPANE VICT3 Propane Gas...
- Page 7 recommended that this appliance be installed in a sheltered area (following the guidelines outlined undesirable. moisture or running water may be a problem. Any enclosure (shelter) in which the appliance is used must comply with one of the following: With walls on all sides, but at least one permanent opening at ground level and no overhead cover. sidewalls may be parallel, as in a breezeway, or at right angles to each other.
- Page 8 WARNING! A dented or rusty cylinder may be hazardous and should be checked by your propane supplier. Never use a cylinder with a damaged valve. The LP-gas supply cylinder must be constructed and marked in accordance (not supplied). space of the cylinder. The cylinder supply system must be arranged for vapor withdrawal and the cylinder shall include a collar to protect the cylinder valve.
- Page 9 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 10 WARNING! WARNING! WARNING! 1. Remove the glass embers from the burner. 2. Remove the burner from the enclosure. Take care not to damage or kink the thermocouple wire. www.napoleongrills.com N415-0390 MAY 09.18...
- Page 11 Place the burner back into the enclosure. panel access door. the appliance is the responsibility of the installer. Connect the inlet valve to rigid pipe, copper tube or an must be installed upstream of, and as close to, the quick disconnect as is feasible. WARNING! •...
- Page 12 WARNING! WARNING! WARNING! 1. Carefully pour the glass embers onto the appliance ember tray as shown. ENSURE NO GLASS IS BLOCKING ANY OF THE OPEN PORTS ON THE IGNITION www.napoleongrills.com N415-0390 MAY 09.18...
- Page 13 WARNING! WARNING! hose, manifolds and valves. STOP If the leak cannot be stopped, disconnect it, and have the grill DO NOT USE AN OPEN FLAME. DO NOT USE AN OPEN FLAME. N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 14 WARNING! WARNING! 5. If the burner will not light with the electronic igniter, hold a lit long match or lit WARNING! WARNING! www.napoleongrills.com N415-0390 MAY 09.18...
- Page 15 • • Never use the appliance if the burner is damaged. Inspect the burner before each use. Ensure that your Napoleon dealer. • Inspect the hose assembly before each use. If there is evidence of excessive abrasion or wear, or...
- Page 16 : The control panel text is printed directly on the stainless steel and with proper maintenance will remain dark and legible. To clean the panel, use only warm soapy water or stainless steel cleaner available from your Napoleon dealer. Never apply abrasive cleaners on any stainless surfaces, WARNING!
- Page 17 : Reverse the procedure to reinstall the burner. Check that the valve enters the burner when NORMAL ABNORMAL : Do not use abrasive cleaners or steel wool on any painted, or be cleaned with warm soapy water. To clean stainless surfaces, use a stainless steel or a non-abrasive appliance WARNING! N415-0390 MAY 09.18...
- Page 18 valve turned to high. procedure. turned on. Turn tank on slowly to line. Burners burn with yellow Possible spider web or other debris. Thoroughly clean burner venturi. See general smell of gas. Burner will not light with the igniter, but will light with a match.
-
Page 19: Ordering Replacement Parts
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts MODEL: DATE OF PURCHASE: SERIAL NUMBER: For replacement parts and warranty claims, contact the Napoleon dealer where the product was purchased. www.napoleongrills.com. • • • •... - Page 20 VICT1 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 21 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 22 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 23 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 24 ENSURE NO GLASS IS BLOCKING ANY OF THE OPEN PORTS LIGHTING MAY RESULT. WARNING! www.napoleongrills.com N415-0390 MAY 09.18...
- Page 25 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 26 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 27 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 28 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 29 ENSURE NO GLASS IS BLOCKING ANY OF THE OPEN PORTS LIGHTING MAY RESULT. WARNING! N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 30 VICT3 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 31 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 32 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 33 N415-0390 MAY 09.18 www.napoleongrills.com...
- Page 34 ENSURE NO GLASS IS BLOCKING ANY OF THE OPEN PORTS ON THE IGNITION DIFFICULTIES IN LIGHTING MAY RESULT. WARNING! www.napoleongrills.com N415-0390 MAY 09.18...
- Page 35 M8 N010-0910 electrode assembly table top rear panel frame assembly right panel door napoleon logo handle door leveling foot tank bracket tank support fastener kit N300-0002 glass embers topaz (2per) windscreen mega glass embers - amber 1lb...
- Page 36 PARTS DIAGRAM VICT1 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 37 M8 N010-0910 electrode assembly table top rear panel frame assembly right panel door napoleon logo handle door leveling foot tank bracket tank support fastener kit N300-0002 glass embers topaz (2per) windscreen mega glass embers - amber 1lb...
- Page 38 PARTS DIAGRAM VICT2 www.napoleongrills.com N415-0390 MAY 09.18...
- Page 39 N240-0039 electrode thermocouple washer M8 N010-0910 electrode assembly table top rear panel frame assembly right panel door napoleon logo handle door leveling foot tank bracket tank support tank bracket brace fastener kit N300-0002 glass embers topaz (2per) windscreen mega glass embers - amber 1lb...
- Page 40 PARTS DIAGRAM VICT3 www.napoleongrills.com N415-0390 MAY 09.18...
