Page 1: Quick Start Guide
P-870MH-C1 VDSL Modem Over POTS Quick Start Guide Version 3.50 12/2006 Edition 1 Copyright © 2006. All rights reserved. -
Page 2: Hardware Connections
P-870MH-C1 Quick Start Guide Introduction The P-870MH-C1 is a VDSL modem with a four-port switch. VDSL offers high-speed Internet access. The four-port switch lets you connect up to four computers to the P-870MH-C1. Refer to the User’s Guide for detailed information. -
Page 3: Test Your Internet Connection
P-870MH-C1 Quick Start Guide 1.1 Check the LEDs (Lights) • The POWER LED blinks and turns steady on. • The VDSL and/or ETHERNET LEDs turn on and sometimes blink if the corresponding ports are properly connected. If none of the LEDs are on, unplug the device and check your hardware connections again. - Page 4 • The ALARM light blinks once during system startup. If the ALARM light stays on, the system startup test has failed on your P-870MH-C1. Contact your local vendor. 3 The POWER light is on, and the ALARM light is off, but the VDSL light is blinking slowly.
- Page 5 P-870MH-C1 Quick Start Guide • There might be problems with your VDSL settings or phone line. Contact your Internet Service Provider (ISP) and/or telephone company. Procedure to View a Product’s Certification(s) 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
