Panasonic ES2056 Service Manual

Hide thumbs Also See for ES2056:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Please file and use this manual together with the service manual for Model No. ES2054/ES2057, Order No.
PCD0704E32CE.
TABLE OF CONTENTS
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Troubleshooting Guide ----------------------------------------- 3
Model No.
Europe
PAGE
© 2008 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
Order Number PCD0804E32AE
ES2056
ES2058
Epilator
PAGE

Advertisement

loading

Related Manuals for Panasonic ES2056

Summary of Contents for Panasonic ES2056

  • Page 1 Order Number PCD0804E32AE Epilator ES2056 Model No. ES2058 Europe Please file and use this manual together with the service manual for Model No. ES2054/ES2057, Order No. PCD0704E32CE. TABLE OF CONTENTS PAGE PAGE 1 Warning -------------------------------------------------------------- 2 2 Specifications ----------------------------------------------------- 2...

  • Page 2: Warning

    1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder- ing iron, please be careful not to heat too long.

  • Page 3: Troubleshooting Guide

    3 Troubleshooting Guide...

  • Page 4: Exploded View And Replacement Parts List

    4 Exploded View and Replacement Parts List Model No. : ES2056 Exploded View for ES2056...
  • Page 5 Model No. : ES2056 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ES2056 WES2054A7158 PROTECTIVE CAP 2 [BG] WES2054A3108 LEGS/ARMS FRAME WITH FOAM KEEPER 1 [BG] WES2051W1068 EPILATION HEAD FOR LEGS/ARMS 1 [BG] WES331B9257 TAPPING SCREW...
  • Page 6 Model No. : ES2058 Exploded View for ES2058...
  • Page 7 Model No. : ES2058 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ES2058 WES2057P7158 PROTECTIVE CAP 2 [BG] WES2057P3108 LEGS/ARMS FRAME WITH FOAM KEEPER 1 [BG] WES2051W1068 EPILATION HEAD FOR LEGS/ARMS 1 [BG] WES331B9257 TAPPING SCREW 2 (K2-8), [BG] WES2047L3387 BUTTON MOUNTING BASE B...

This manual is also suitable for:

Es2058
