Connecting to Your ISDN Line

The omni comes with a choice of two types of ISDN line interfaces:
S/T interface - This can only connect to your NT-1 (Network
Termination) device.
Warning: Do not under any circumstances connect directly to the ISDN
wall jack.
U interface - This allows you to connect directly to your ISDN
wall jack.
Warning: The ISDN jack is for ISDN line connection only. Connection of a
phone line may result in damage to your Terminal Adapter.
Attention:
sur une ligne RNIS. La connexion sur une ligne téléphonique
peut endommager votre adaptateur de terminal.

U Interface Model

If you have purchased the U-interface model, you can connect the
U-Interface directly to the wall jack.
In most cases, the ISDN jack installed by the phone company is a
RJ-11 jack (except in Canada, where RJ-45 jack will be installed),
and the U-Interface jack on the back of the omni is a RJ-45 jack. A
RJ-45 to RJ-45 (or RJ-11 to RJ-45, depends on your regional
distributor's request) phone cable is included with your TA.
To connect your U-interface omni to your ISDN line complete the
steps below:
Connect the RJ-45 connector to the "ISDN U" jack on the back
of the omni.
Connect the other end of the RJ-45 cable (or RJ-11) to your wall
jack.
12 Installing omni External Models
La fiche ISDN est destinée uniquement pour la connexion
