ZyAIR B-300 11Mbps
Wireless LAN PCI Card
Quick Installation Guide
Install the ZyAIR B-300 WLAN
PCI Card
Version : 1.0
Package Contents
Please ensure that the following
items are included in your
package. If any items are missing
contact your dealer.
• One ZyAIR B-300 Wireless
802.11b PCI Card
• One CD-ROM (includes
device drivers, utility and
user's manual)
• This quick installation guide
• One external antenna
Advertisement
Related Manuals for ZyXEL Communications Wireless LAN PCI Card B-300
Summary of Contents for ZyXEL Communications Wireless LAN PCI Card B-300
- Page 1 ZyAIR B-300 11Mbps Wireless LAN PCI Card Quick Installation Guide Version : 1.0 Install the ZyAIR B-300 WLAN PCI Card Package Contents Please ensure that the following items are included in your package. If any items are missing contact your dealer. •...
-
Page 2: Status Leds
ZyAIR B-300 Quick Installation Guide Status LEDs POWER LINK Side view of the PCI Card from bracket MEANING POWER Indicates that the B-300 is powered on (solid green). Indicates link status. The LED lights up (solid green) while LINK the wireless connection is linked. The LED is blinking green while wireless data is transmitting / receiving. -
Page 3: Driver Installation For Windows Xp
ZyAIR B-300 Quick Installation Guide Driver installation for Windows XP Insert the B-300 PCI Card into an available PCI slot on the desktop After Windows XP detects the card, the Found New Hardware Wizard window appears. Select Install the software automatically [Recommended] and insert the driver CD-ROM into the CD- ROM drive and click Next to... - Page 4 ZyAIR B-300 Quick Installation Guide The next screen is the common Windows Logo testing warning screen. This testing is not necessary for the operation of the ZyAIR B-300. Simply click Continue Anyway to continue the installation. — 4 —...
- Page 5 ZyAIR B-300 Quick Installation Guide Windows has finished installing software for the B-300. Click Finish to complete the installation. The system will automatically start to install the Wireless LAN Utility. Please refer to procedures in Chapter 4 of the User’s Manual on the CD-ROM.
-
Page 6: Driver Installation For Windows 2000
ZyAIR B-300 Quick Installation Guide Driver installation for Windows 2000 Insert the B-300 PCI Card into an available PCI slot on the desktop PC. After Windows 2000 detects the card, the Found New Hardware Wizard window appears. Click Next to start the installation. - Page 7 ZyAIR B-300 Quick Installation Guide A screen appears prompting the user to select an installation method. Select Search for a suitable driver for my device [Recommended] and click Next to continue. — 7 —...
- Page 8 ZyAIR B-300 Quick Installation Guide Ensure that the CD-ROM driver is selected and insert the driver CD-ROM into the CD- ROM drive and click Next to continue. — 8 —...
- Page 9 ZyAIR B-300 Quick Installation Guide The following screen appears showing the driver search results. Click Next to continue the installation. The following screen appears. Click Yes to continue. — 9 —...
- Page 10 ZyAIR B-300 Quick Installation Guide Windows has finished installing the B-300 software. Click Finish to complete the installation. The system will automatically start to install the Wireless LAN Utility. Please refer to procedures in Chapter 4 of the User’s Manual on the CD-ROM. —...
-
Page 11: Driver Installation For Windows Me
ZyAIR B-300 Quick Installation Guide Driver installation for Windows ME Insert the B-300 PCI Card into an available PCI slot on the desktop After Windows ME detects the card, the Add New Hardware Wizard window appears. Select Automatic search for a better driver [Recommended] and insert the driver CD-ROM into CD- ROM drive and click Next to... - Page 12 ZyAIR B-300 Quick Installation Guide Click Finish to finish the installation. — 12 —...
- Page 13 ZyAIR B-300 Quick Installation Guide Click Yes to reboot the computer. After the system reboot, the Wireless LAN Utility will be installed automatically. The system will then automatically start to install the Wireless LAN Utility. Please refer to procedures in Chapter 4 of the User’s Manual on the CD-ROM —...
