- Page 1 HB2302 HBZ2601 OWNER’S MANUAL BLOWERS HB2302 / HBZ2601 848L0B93A1 (411) GB-1...
- Page 2 HB2302 / HBZ2601 EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MAY INVOLVE A DAILY LEVEL OF PERSONAL EXPOSURE TO NOISE FOR THE OPERATOR EQUAL TO OR GREATER THAN MODEL HB2302 22.5cm HBZ2601 25.4cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION (2002/88/EC) GB-2 WARNING!!! RISK OF DAMAGING HEARING...
-
Page 3: Table Of Contents
SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 4: Specifications
HB2302 / HBZ2601 2. Specification Model Dimensions (LxWxH) Dry weight (w/o tube and nozzle) kg Fuel tank capacity Engine Type Displacement Carburetor Ignition system Spark plug Muffler Operating Engine Speed Idle speed Average Air Volume Max. Air Velocity Noise Level at 50 feet Specifications are subject to change without notice. -
Page 5: For Safe Operation
5. For safe operation 1. Read this manual carefully until you completely understand and follow all safety and operating instructions. 2. Keep this manual handy so that you may refer to it later when- ever any questions arise. Also note, if you have any questions which cannot be answered herein, contact the dealer from whom you purchased the prod-... - Page 6 HB2302 / HBZ2601 5. For safe operation morning or late at night when people might be disturbed. Com- ply with times listed in local ordi- nances. 2. To reduce sound levels, limit the number of pieces of equipment used at any one time. 3.
- Page 7 5. When replacing the any other part, or any lubricant, always be sure to use only Komatsu Zenoah products or products which have been cer tified by Komatsu Zenoah for use with the Komatsu Zenoah product.
-
Page 8: Set Up
HB2302 / HBZ2601 6. Set up BLOWER PIPE • Align groove in blower pipe with projection on blower housing (or another blower pipe) and slide the pipe onto the blower housing (or another blower pipe). Rotate the pipe clockwise to lock it into place. GB-8... -
Page 9: Fuel
3 m (10 ft) away from the fueling point before starting the engine. • The Komatsu Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Komatsu Zenoah oil is not available,... -
Page 10: Operation
HB2302 / HBZ2601 8. Operation STARTING ENGINE 1. Rest the unit on a flat, firm place. 2. Pump the primer until fuel flows out in the clear tube. 3. Move the choke lever upward to close the choke. 4. Holding the blower handle, pull the starter rope with your right hand. -
Page 11: Maintenance
9. Maintenance Maintenance, replacement, or repair of the emission control device and systems may be per- formed by any non-road engine repair establishment or individual. System / Compronent Air Filter Prefilter Air Filter Paper Filter Fuel Leaks Fuel Filter Fuel Line Spark Plug Muffler Muffler Spark Arrester... - Page 12 HB2302 / HBZ2601 9. Maintenance FUEL FILTER • A clogged fuel filter may cause poor acceleration of the engine. Check periodically to see if the filter is clogged with dirt. The filter can be taken out of the fueling port using a small wire hook. Disconnect the filter assembly from the fuel pipe and unhook the re- tainer to disassemble it.
-
Page 13: Storage
9. Maintenance AIR INTAKE SCREEN (AIR INLET NET) IMPORTANT • Blowing air is taken in from the air inlet net. When air flow has dropped down during operation, stop the engine and inspect the air inlet net for blocking by obstacles. -
Page 14: Optional Vacuum Kit Usage
HB2302 / HBZ2601 11. Optional vacuum kit usage Attach the adequate accessories, respectively for blower operation and dust-collecting op- eration. NOTE • Use the gloves during operation. • In adjustment of the blower/dust collector or in other types of operation, be sure to stop the engine and detach the spark plug cap. - Page 15 11. Optional vacuum kit usage 3. Fit the elbow groove with discharge port projection, turn the elbow and mount the dust bag to the main unit. DUST COLLECTING OPERATION • Put the dust bag belt on the shoulder, and adjust the length of the belt so as to permit easy operation.
-
Page 16: Troubleshooting Guide
(exhaust port) air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our KOMATSU ZENOAH Limited warranty Should any failure occur on the product under normal oper- ating conditions within the applicable warranty period, the...
