- Page 1 Microflex Complete ® Update & Feature License User guide for the Shure Microflex Complete Conference System Version: MXC-FUU guide RevC.docx...
-
Page 2: Table Of Contents
Shure Incorporated Table of Contents 1 Introduction 2 Buttons and windows in the FUU 3 Firmware update of MXC 3.1 Before you start 3.2 General guidelines 3.3 Compatibility 3.4 Locked units 3.5 MXC Firmware Update Utility (FUU) 4 3.6 Connecting the FUU – Firmware Update Utility 3.7 Checking the ‘Error Status’... -
Page 3: Introduction
Shure Incorporated 1 Introduction This manual describes the procedure for updating/downgrading the firmware in the various units in the MXC/DCS 6000 system. The manual does also describe how to upload a MXC/DCS 6000 Feature License into the CCU Central Units. -
Page 4: Firmware Update Of Mxc
If for some reason the update fails for one or more units but power has not been removed it is usually possible to do the update again and units that did not correctly update the first time will continue where they stopped the second time around. Shure.com has information about compatibility and updateability. If you are in doubt please consult Shure Conferencing Support by e- mail: conferencingsupport@shure.dk... - Page 5 Shure Incorporated Unzip the zip file containing the Firmware Update Library folder and a FUU folder to the desktop or another convenient location on the Connect the PC to the CCU using a LAN cable and switch on power. Browse to the folder ‘MXC_Firmware_Update_Utility_xxx’...
-
Page 6: Checking The 'Error Status' Window
Shure Incorporated Before any update is performed the ‘Error Status’ has to be checked. The error in the communication from the units to the CCU can be checked clicking ‘View/View Error status Window’ Basically this window shall show no errors in the system. -
Page 7: System Update
Shure Incorporated Select the Firmware Release in the ‘Selected Release Id’ drop-down list and press ‘Update System’. 10. A’ System Update Status’ window will appear and show the progress of the firmware update. The update utility will update on unit type at a... - Page 8 Shure Incorporated If one or more specific units have to be downgraded for service purpose or for adding some units to an old installation the FUU has to be changed to show the advanced layout. Please notice that this option is only recommended for experienced users.
-
Page 9: Changing Of Start Image In Mxc640
Shure Incorporated 4 Changing of start image in MXC640 The start image on the MXC640 can be changed individually on all MXC640 units to customize the look of the units. Change the FUU to the Advanced FUU Layout in Setup -> Advanced FUU Layout. - Page 10 Shure Incorporated A file browser window opens up. Browse for the image to upload, select it and press ‘Open’. Please notice the image format must be .png with a resolution of 480x272 pixels. If the selected image does not have the specified resolution an error...
-
Page 11: Delete A Start Image
• More Interpreter Channels The file with the License key is delivered as a zipped file from your local Shure Partner. Upload License File using the Browser. Please refer to the ‘MXC User Guide’. Alternatively the license can be uploaded by selecting the ‘License/Import new CCU License key’ in the License dropdown menu in the... -
Page 12: Dcs-Lan Communication
Shure Incorporated 6 DCS-LAN communication Errors in the communication from/to the units to the CCU can be checked clicking ‘View/View Error status Window’. Basically this window shall show no errors in the system. However in large systems, there might be generated some errors during start- up. - Page 13 Shure Incorporated When clicking ‘View/View Communication Window’ a window showing all communication to the CCU opens. The following list summarizes some useful commands in case communication problems with the cables occur: Command Description Automatic In Bus Test Automatic Version Request...
