126.2936.42…ZWF10070-12070-14070.qxd 14/7/08 12:59 Página 1 Por Susana Ruiz Moreno fecha 13:26 , 14/07/2008 User manual Washing Machine ZWF 10070W1 ZWF 12070W1 ZWF 14070W1... -
Page 2: Table Of Contents
126.2936.42…ZWF10070-12070-14070.qxd Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document. -
Page 3: Safety Information
126.2936.42…ZWF10070-12070-14070.qxd Safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. -
Page 4: Child Safety
126.2936.42…ZWF10070-12070-14070.qxd This appliance is designed for domestic use. ● It must not be used for purposes other than those for which it was designed. Only wash fabrics which are designed to be ● machine washed. Follow the instructions on each garment label. Do not overload the appliance. -
Page 5: Description Of The Appliance
126.2936.42…ZWF10070-12070-14070.qxd Description of the appliance Detergent dispenser drawer Control panel Door opening handle Drain pump Adjustable feet Detergent dispenser drawer 14/7/08 12:59 Página 5 Prewash Wash Fabric Softener... -
Page 6: Control Panel And Functions
126.2936.42…ZWF10070-12070-14070.qxd Control panel and functions Programme selector dial and On/Off switch Spin reduction button Options button Auto half load button Start/Pause button Programme progress display Delay Start button 14/7/08 12:59 Página 6 The programme selector dial allows you to select a ●... -
Page 7: Programme Table
126.2936.42…ZWF10070-12070-14070.qxd Programme table Programme/ Type of laundry Temperature White cotton (heavily Cottons soiled cotton items): e.g. sheets, tablecloths, 90º C household linen, towels. White and fast coloured cotton Cottons (normally soiled cotton 60° items): sheets, household linen, underwear, Coloured cotton lightly Cottons soiled, shirts, blouses, 60°... - Page 8 126.2936.42…ZWF10070-12070-14070.qxd Programme table Programme/ Type of laundry Temperature Programme for wool Wool «Pure new wool, non- 40° shrink, machine washable» label. Handwash Special programme for 30° - Cold hand washing fabrics Mini 30’ Short cycle for lightly soiled fabrics 30° Silk Silk items to be gently washed and spun.
-
Page 9: Programme Information
126.2936.42…ZWF10070-12070-14070.qxd Programme information Wool and Handwash Easy Iron Rinse Drain Spin Sport shoes 40° Sport 40° Off = Cancelling 14/7/08 12:59 Página 9 Washing programme for machine washable wool as well as for hand washable woollens and delicate fabrics with the «hand washing» care symbol Selecting this programme the laundry is gently washed and spun to avoid any creasing. -
Page 10: Washing Hints
126.2936.42…ZWF10070-12070-14070.qxd Washing hints Sorting the laundry Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. Temperatures for normally soiled white cottons 90° and linen (e.g. tea cloths, towels, tablecloths, sheets...) for normally soiled, colour fast garments (e.g. -
Page 11: Detergents And Additives
126.2936.42…ZWF10070-12070-14070.qxd Oil based paint: moisten with benzine stain remover, lay the garment on a soft cloth and dab the stain; treat several times. Dried grease stains: moisten with turpentine, lay the garment on a soft surface and dab the stain with the fingertips and a cotton cloth. Rust: oxalic acid dissolved in hot water or a rust removing product used cold. -
Page 12: Before The First Use
126.2936.42…ZWF10070-12070-14070.qxd Quantity of detergent to be used The type and quantity of detergent will depend on the type of fabric, load size, degree of soiling and hardness of the water used. Water hardness is classified in so-called «degrees» of hardness. Information on hardness of the water in your area can be obtained from the relevant water supply company. -
Page 13: Operating Sequence
126.2936.42…ZWF10070-12070-14070.qxd Operating sequence 1. Load the laundry Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. 2. Measure out the detergent and the fabric softener Pull out the dispenser drawer until it stops. - Page 14 126.2936.42…ZWF10070-12070-14070.qxd Operating sequence Cotton, Synthetic, Delicates, Silk, Sport Shoes 40°, and Sport 40° programmes the rinses will be performed with more water. When the programme has finished the «Door» and «End» pilot lights are lit,, the Start/Pause and «Wash» lights are off and the door is locked to indicate that the water must be emptied out.
- Page 15 126.2936.42…ZWF10070-12070-14070.qxd Operating sequence The «Wash» and «Door» lights are lit to indicate that the appliance starts operating and the door is locked. To interrupt a programme which is running, depress the Start/Pause button: the corresponding green pilot light starts to flash. To restart the programme from the point at which it was interrupted, press the Start/Pause button again.
- Page 16 126.2936.42…ZWF10070-12070-14070.qxd Altering an option or a running programme It is possible to change any option before the programme carries it out. Before you make any change, you must pause the washing machine by pressing the Start/Pause button. Changing a running programme is possible only by resetting it.
-
Page 17: Care And Cleaning
126.2936.42…ZWF10070-12070-14070.qxd Care and cleaning IMPORTANT! You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. - Page 18 126.2936.42…ZWF10070-12070-14070.qxd Screw the pump cover fully in. ● Close the pump door. ● IMPORTANT! When the appliance is in use and depending on the programme selected there can be hot water in the pump. Never remove the pump cover during a wash cycle, always wait until the appliance has finished the cycle, and is empty.
-
Page 19: Something Not Working
126.2936.42…ZWF10070-12070-14070.qxd Something not working IMPORTANT! Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During machine operation it is possible that the red Start/Pause pilot light flashes to indicate that the machine is not working. - Page 20 126.2936.42…ZWF10070-12070-14070.qxd Malfunction The machine fills then empties immediately: The machine does not empty and/or does not spin: There is water on the floor: Unsatisfactory washing results: 14/7/08 12:59 Página 20 Possible Cause / Solution The end of the drain hose is too low. •...
- Page 21 126.2936.42…ZWF10070-12070-14070.qxd Malfunction The door will not open: The machine vibrates or is noisy: Spinning starts late or the machine does not spin: The machine makes an unusual noise No water is visible in the drum If you are unable to identify or solve the problem, contact our service centre.
-
Page 22: Technical Data
126.2936.42…ZWF10070-12070-14070.qxd Technical data Dimensions Electrical connection Voltage - Overall power - Fuse Water supply pressure Maximum Load Spin Speed 14/7/08 12:59 Página 22 Width Height Depth (including the porthole) Information on the electrical connection is given on the rating plate on the inner edge of the appliance door Minimum Maximum Cotton... -
Page 23: Consumption Values
126.2936.42…ZWF10070-12070-14070.qxd Consumption values Programme Cottons 95°C Cottons 60° Eco( Cottons 60°C - 40°C Cottons 40°C Eco Synthetics 50°C - 40°C Synthetics Easy Iron 40°C Delicates 40°C - 30°C Wool 40°C Handwash 40° Mini 30’ Silk 30°C Sport Shoes 40°C Sport 40°C Rinse Drain Spin... -
Page 24: Installation Instruction
126.2936.42…ZWF10070-12070-14070.qxd Installation instruction Transit security bars Before using the appliance, all transit bolts and spacers must be removed. You are advised to keep all transit devices in case the appliance has to be transported again. Proceed as follows: 1. Unscrew and remove the three rear screws using a suitable spanner. - Page 25 126.2936.42…ZWF10070-12070-14070.qxd Water inlet There should be a COLD WATER tap near the washing machine with a screwing on connection pipe of 3/4" for the water supply, a sink, a wash basin or a drainage system in the wall. Previously check if: - it is not a hot water tap.
- Page 26 126.2936.42…ZWF10070-12070-14070.qxd The drain hose may be extended to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Force Centre. The joining piece must have an internal diameter of 18mm. If your drain hose looks like this (see below) you do not require the «U»...
- Page 27 126.2936.42…ZWF10070-12070-14070.qxd If you require any further advice please contact your local water authority. Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING! This appliance must be earthed. The manufacturer declines any liability should this safety measure not be observed.
-
Page 28: Environmental Concerns
126.2936.42…ZWF10070-12070-14070.qxd Environmental concerns Packaging materials The materials marked with the symbol recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Old machine Use authorised disposal sites for your old appliance. -
Page 29: Guarantee Conditions
Addington Way, Luton, Bedfordshire, LU4 9QQ Electrolux ...Tel: 08705 950 950 (*) AEG-Electrolux ...Tel: 08705 350 350 (*) Zanussi-Electrolux ...Tel: 08705 727 727 (*) (*) Calls may be recorded for training purposes For Customer Service in The Republic of Ireland please contact us at the address... -
Page 30: European Guarantee
126.2936.42…ZWF10070-12070-14070.qxd European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications:... - Page 31 126.2936.42…ZWF10070-12070-14070.qxd 14/7/08 12:59 Página 31 www.electrolux.com...
