External cleaning Periodic cleaning Changing the light bulb When the appliance is not in use Something Not Working? Service and Spare Parts Customer Care Department Zanussi Service Force Guarantee Conditions Instructions for the Installer Technical Specifications Installation Positioning The Electrical Connection...
IMPORTANT SAFETY INSTRUCTIONS These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to Installation Check the appliance for transport damage.
DESCRIPTION OF THE APPLIANCE - Dairy compartment B - Movable shelf C - Bottle storage shelf D - Airduct exit E - Air inlet filter F - Salad bins G - Storage shelves with cool check temperature guide H - Thermostat control...
OPERATION Before use Remove all securing tapes. Wash inside the appli- ance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or deter- gent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and...
Normal Operating Sounds You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils below, to the cooling evaporator. When the compressor is on, the refrigerant is being pumped round, and you will hear a whirring sound or pulsating noise from the compressor.
COOL CHECK GUIDE The guide consists of a temperature sensitive strip sealed in a shelf trim. When the fridge is operating at the safe temperature to store food the guide will appear black. If the tem- perature rises above this level the guide will show the words TOO WARM.
DEFROSTING The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Important To avoid defrost water overflowing and drip- ping onto the food in the fridge, periodically clean the water discharge hole (F) situated under the vegetable drawers.
Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Zanussi Service Force centre). 2. Replace the light cover by sliding it into its original position and replacing the screw.
The addresses are listed on the following pages. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, you are invited to contact our Customer Care Department by letter or telephone or visit our website at www.zanussi.co.uk...
Standard guarantee conditions We, Zanussi, undertake that if within 24 months of the date of purchase this Zanussi appliance or any part there- of is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY (*) GROSS CAPACITY NET CAPACITY (*)This figure is based on standard test results in accordance with European Standard EN153. Actual con- sumption will depend on how the appliance is used and where it is located. INSTALLATION Positioning For this appliance to work efficiently, it should be...
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression.
BUILDING-IN INSTRUCTIONS Before carrying out any work, remove the plug from the power socket. Grid preparation Remove the grid from the appliance pulling it towards you with hands. Right door opening: Remove the left side (A) of the grid cutting it from the rear (see figure, a).
Building the appliance in under a worktop The dimensions of the recessed installation area must correspond with those indicated in the figure. The appliance could be inserted between two units (a) or as an end unit (b). The plug socket necessary for connection of the appli- ance to the electricity supply should be positioned, so that the plug is not placed in the recess.
Page 18
The appliance is equipped with adjustable support feet. To adapt the appliance to the height of the instal- lation area (max 870 mm), screw in, or screw out the feet situated to the four bottom corners. S.I.006 Separate parts A, B, C, D as shown in the figure. PR266 Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark...
Should the lining up of the furniture door be neces- sary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly. Fix cover (D) on guide (B) until it clips into place. Fitting the plinth Important For the efficient operation of the appliance, it is...
