- Page 1 REFRIGERATOR FRIGORÍFICO ZKC 49/3 INSTRUCTION BOOKLET MANUAL DE INSTRUÇÕES 2222 257-06/2...
-
Page 2: General Safety
This product should be serviced by an authorised ZANUSSI Service Centre, and only genuine spare parts should be used. Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. - Page 3 Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. Avoid damaging the cooling unit, especially at the rear near the heat exchanger.
-
Page 4: Table Of Contents
Description of the appliance Installation Positioning Before using Location Door reversibility Changing the opening direction of the door (freezer compartment) Fitting a decorative door panel The electrical connections Technical specification Operation Setting the temperature Storing deep-frozen foods Ice cubes Health and safety guidelines Fresh food refrigeration Cool check temperature guide Starting the appliance... -
Page 5: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A - Dairy compartment B - Shelf with egg tray C - Bottle storage shelf D - Salad drawers E - Glass shelf (for storing meat) F - Cool check temperature guide G - Storage shelves H - Thermostat control freezer compartment... -
Page 6: Installation
Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Positioning This appliance is designed to operate in ambient temperatures between 16 C (60 F) and 32 C (90 F). -
Page 7: Location
Location This appliance is designed to be built-in to a space having the dimensions given in Fig. 1. The height of the appliance can be altered if required by means of adjustable feet situated at its base (Fig. 2). 100-170 D506 D507 Fig. -
Page 8: Door Reversibility
Door reversibility Remove the two screws which fix the upper hinge to the door. Carefully lean the appliance on its back and remove the plastic insert (Fig. 3). Remove the two screws which fix the lower hinge to the door. Remove the four screws which fix the lower hinge to the base of the appliance and remove the hinge itself;... -
Page 9: Changing The Opening Direction Of The Door
Changing the opening direction of the door (freezer compartment) Having changed the opening direction of the appliance door, it is advisable to also change the opening direction of the freezer compartment door. To do this, proceed as follows: Unscrew the two fixing screws to remove the lower hinge from the door (Fig. -
Page 10: Fitting A Decorative Door Panel
Fitting a decorative door panel Important: The components needed to fit the decorative panel have been pre-fitted on the appliance. The brackets are secured to the panel by means of the 7 Ø 3.5x13 screws supplied. Before starting to fit the panel, remove the large top bracket by unscrewing the screws and adjusting pins pre-fitted on the appliance door. - Page 11 Insert the adjusting pins (B-Fig. 10) into their locations in the door and screw them in. Hook the decorative panel onto the top part of the door, inserting the pins (B) (on the door) into the elongated holes (1) (in the top bracket fitted to the panel) (Fig.
- Page 12 Once the door has ben correctly aligned, tighten the holding nuts on the fixing brackets and attach the appliance to the adjacent units and the bottom of the work surface (Fig. 14). If the appliance has been fitted into a space 820 mm high and the maximum height of the base plate is 100 mm, fit the front cover plate by pushing the two vertical lugs into the rectangular holes on the bottom...
-
Page 13: The Electrical Connections
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which accompanies your instruction manual. -
Page 14: Technical Specification
TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY* GROSS CAPACITY NET CAPACITY * This figure is based on standard test results in accordance with European Standard EN153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 110 W 1.00 kWh... -
Page 15: Operation
Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and one «OFF» ( O ) position. Position 1 = minimum coldness Position 6 = maximum coldness Turn the thermostat dial to the required position; the intermediate position is usually the most suitable (3- The thermostat setting can vary as the temperature inside the refrigerator compartment depends on the... -
Page 16: Health And Safety Guidelines
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible. -
Page 17: Fresh Food Refrigeration
Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them. -
Page 18: Cool Check Temperature Guide
During everyday use a fridge door is opened many times and as a result temperature fluctuation may occur. A Zanussi fridge is designed to cope with any changes in temperature but under certain conditions the temperature guide in the appliance may show TOO WARM. -
Page 19: Defrosting
Defrosting The refrigerator compartment evaporator is automatically defrosted every time the compressor stops. The water drains out through a channel (Fig. 20) into a bowl located at the base of the back of the appliance, where it evaporates. In the compartment, the frost must be removed using the plastic scraper provided whenever a thick layer accumulates (approx. -
Page 20: Maintenance And Cleaning
Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Zanussi Service Centre). Replace the light cover by sliding it into its original position and replacing the screw. -
Page 21: What Happens If Something Goes Wrong
Other points to check... If, after the above checks, there is still a fault, call your local Zanussi Service Centre, whose address can be found in the accompanying Customer Care Booklet, and can also be found in your local telephone directory under «Z». -
Page 22: Guarantee Conditions
We, Zanussi Ltd., undertake that if, within twentyfour months of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials,...
