- Page 1 REFRIGERATOR- FREEZER ZKR 60/30 R INSTRUCTION BOOKLET 2222 003-93...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 3: Table Of Contents
CONTENTS Instructions for the User Important Safety Information Description of the appliance Operation Before use Control panel Starting your appliance Setting the temperature Ambient Temperature Switch The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes Cold accumulators Fresh food refrigeration Movable shelves Positioning the door shelves... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Control panel B- Interior light C- Dairy compartment D- Can storage shelves E- Bottle storage shelf F - Freezer calendar G- Frozen food storage compartment H - Freezing fresh food compartment I- Salad crispers J- Glass shelf with CrispÕn fresh filter K- Cool Check Temperature Guide L- Storage shelves FA ST FR EE ZE... -
Page 5: Operation
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Control panel A. -
Page 6: Frozen Food Storage
In any 24 hours you can freeze up to 10 kg. of fresh food. Place food to be frozen in the upper drawer of the freezer as this is the coldest part. Frozen food storage When first starting-up or after a period of non use, before putting the food in the compartment let the appliance run for at least two hours on the coldest setting, then turn the thermostat knob to the normal... -
Page 7: Movable Shelves
Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. For better use of space, the front half-shelves can lie over the rear ones. Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. -
Page 8: Cool Check Guide
Cool Check Guide The guide consists of a temperature sensitive strip sealed in a shelf trim. When the fridge is operating at the safe temperature to store food the guide will appear black. If the temperature rises above this level the guide will show the words TOO WARM. -
Page 9: Hints And Tips
HINTS AND TIPS Normal Operating Sounds ¥ You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or tubing at the rear, and to the cooling plate/evaporator. ¥ When the compressor is on, the refrigerant is being pumped round, and you will hear a whirring sound or pulsating noise from the compressor. -
Page 10: Maintenance And Cleaning
The filter and the glass cover can be washed gently in warm soapy water, they should not be put in the dishwasher. Replacement filters can be purchased as a spare part from your local Zanussi Service Centre. D711... -
Page 11: Defrosting
Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via a pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the salad... -
Page 12: Something Not Working
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom No power to the appliance The light does not come on... -
Page 13: Service And Spare Parts
The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk... -
Page 16: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 17: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. Height Width 59.5 cm... -
Page 18: Installation
INSTALLATION Important IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 19: Electrical Connection
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression. -
Page 20: Door Reversal
Door reversal directions 1. Disconnect from the electricity supply. 2. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inches) of packing; 3. Remove the ventilation grill (D). 4. Remove the plug (F) from the ventilation grill (D) and replace it on the opposite side. - Page 21 © Electrolux Household Appliances Limited 2000...
