Central Pneumatic 93657 Owner's Manual & Safety Instructions

Oilless airbrush compressor
Hide thumbs Also See for 93657:

Advertisement

Quick Links

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
oilless airbrush
compressor
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2013 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20i
93657

Advertisement

loading

Related Manuals for Central Pneumatic 93657

Summary of Contents for Central Pneumatic 93657

  • Page 1 Keep this manual and the receipt in a safe and dry place for future reference. oilless airbrush compressor Visit our website at: http://www.harborfreight.com 93657 Email our technical support at: productsupport@harborfreight.com When unpacking, make sure that the product is intact and undamaged. If any parts are missing or broken, please call 1-888-866-5797 as soon as possible.

  • Page 2: Table Of Contents

    It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. Page 2 For technical questions, please call 1-888-866-5797. Item 93657...

  • Page 3: Safety

    Such preventive safety lubricating. Keep dry, clean and free measures reduce the risk of starting from oil and grease. Many accidents are the compressor accidentally. caused by a poorly maintained compressor. Item 93657 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4 Electromagnetic fields in close proximity to may result in a risk of injury to persons. heart pacemaker could cause pacemaker interference or pacemaker failure. SaVE tHESE inStructiOnS. Page 4 For technical questions, please call 1-888-866-5797. Item 93657...
  • Page 5 Cubic Feet per Minute flow ScFM WARNING marking concerning at standard conditions Risk of Respiratory Injury. Wear NIOSH-approved respirator. National pipe thread, tapered WARNING marking concerning Risk of Explosion. Item 93657 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6 14 gauge cord can carry a higher suffix “W-A” (“W” in Canada) to indicate current than a 16 gauge cord. (See table a.) it is acceptable for outdoor use. Page 6 For technical questions, please call 1-888-866-5797. Item 93657...

  • Page 7: Specifications

    Specifications Electrical Rating 120VAC / 2A Motor Speed 1,750 RPM Power Cord Maximum Air Pressure 58 PSI Air Outlet 1/8" - 27 NPS Air Output 0.5 CFM @ 20 PSI Item 93657 For technical questions, please call 1-888-866-5797. Page 7...

  • Page 8: Setup

    For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram near the end of this manual. Functions pressure regulator Handle pressure Gauge Outlet power Switch Water trap Drain Valve Hose Figure a Page 8 For technical questions, please call 1-888-866-5797. Item 93657...
  • Page 9 Inlet of Airbrush (not included). Compressor to allow for air circulation. 8. Turn on Power Switch and inspect air connections for leaks. 9. Turn off and unplug Compressor, then repair any leaks found. Item 93657 For technical questions, please call 1-888-866-5797. Page 9...

  • Page 10: Operation

    Use this Compressor only with 8. Perform maintenance on the Airbrushes; do not use this Compressor with Airbrush according to Airbrush any other type of painting equipment. manufacturer’s instructions. Page 10 For technical questions, please call 1-888-866-5797. Item 93657...

  • Page 11: Maintenance

    2. aFtEr EacH uSE: qualified service technician. a. Drain Water Trap: Storage Store Compressor in a dry, secure area out of reach of children. Item 93657 For technical questions, please call 1-888-866-5797. Page 11...
  • Page 12 2. Have a qualified service technician after excessive use replace the retainer ring. at high pressure. Follow all safety precautions whenever diagnosing or servicing the compressor. Disconnect power supply before service. Page 12 For technical questions, please call 1-888-866-5797. Item 93657...
  • Page 13 If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 193175319562 when ordering parts. Item 93657 For technical questions, please call 1-888-866-5797. Page 13...

  • Page 14: Parts List And Diagram

    Screw Nipple Piston Plate Water Trap/Pressure Regulator Piston Ring Pressure Gauge Piston Rod Foot Bearing Pressing Wire Hat Crankshaft Snap Ring Front Body Grommet Paper Pad Air Hose (not shown) Page 14 For technical questions, please call 1-888-866-5797. Item 93657...
  • Page 15 Diagram Item 93657 For technical questions, please call 1-888-866-5797. Page 15...

  • Page 16: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
