Component Bolted connections
Sealed Shell (square-head)
cartridge Shell (Shimano Hollowtech II, 35 - 50
bearing SRAM Giga X Pipe)
Shimano Octalink
Pedal Pedal axle
Shoe Cleat
Spike
Brake Cable clamp
(V-brake) Brake shoe mount
Brake pad fixing
Brake boss frame/fork
www.shimano.com www.sram.com
1 2
These values are reference values of the above-mentioned component manu-
facturers. Be sure to observe the values in the manuals of the component manu-
facturers. These values do not apply to the components of other manufacturers.
WARNING
Some components have the maximum permissible torque values printed on
them. Use a torque wrench and never exceed the maximum torque value! If
you are in doubt or if you have any questions, contact your SCOTT dealer.
NOTICE
Due to the unmanageable number of components on the market, SCOTT is
not in a position to foresee every product that will be replaced or newly as-
sembled by third parties. Therefore SCOTT denies any liability for such kind
of additions or modifications with regard to compatibility, torque values etc.
Whoever assembles or modifies the SCOTT bike shall ensure that the SCOTT
bike is assembled according to the state of the art in science and technolo-
gy.
ROAD BIKE | OWNER'S MANUAL 2021
Shimano
1
(Nm)
49 - 69
50 - 70
35
5 - 6
4
6 - 8
6 - 8
1 - 2
www.tektro.com www.trpbrakes.com
3 4
SRAM/Avid Tektro
2 3
(Nm) (Nm)
34 - 41
6 - 8 6 - 8
6 - 8 6 - 8
8 - 10
www.campagnolo.com
5
TRP Campagnolo
4 5
(Nm) (Nm)
70
35
(Ultra Torque)
40
6 - 8 5
6 - 8 8
