  • Page 1 REF 542plus Installation Manual for Web Interface Installation manual...

  • Page 3: Table Of Contents

    5.7. Language file generation........... 26 5.8. Web pages language selection......... 26 6. Communication requirements and network installation................. 29 6.1. REF 542plus Ethernet physical interface ......29 6.1.1. Assignment of the RJ-45 female connector..29 6.1.2.
  • Page 4 6.3. Network topology..............33 6.3.1. Bus topology............33 6.3.2. Star topology............33 6.3.3. Example of star topology with REF 542plus..34 6.3.4. Ring topology............35 6.3.5. Example of redundant ring topology with REF 542plus..............36 6.3.6.

  • Page 5: Copyrights

    Copyrights The information in this document is subject to change without notice and should not be construed as a commitment by ABB Oy. ABB Oy assumes no responsibility for any errors that may appear in this document. In no event shall ABB Oy be liable for direct, indirect, special, incidental or...

  • Page 7: Introduction

    Before attempting any operation with the REF 542plus, read carefully this manual first. This manual describes how to install the WebREF function of the REF 542plus. Please note that Web Page views and pictures are to be considered exemplary. This manual is addressed to engineering and commissioning personnel and to anyone who needs to administrate the WebREF with REF 542plus via the Ethernet network and the Web Browser interface.

  • Page 8: Product Documentation

    Release 1.0 1VTA100264 14.05.2004 Update Release 1.1 28.02.2006 Document updated language layout 30.9.2006 Updated to software version V4E03x. Applicability This manual is applicable to REF 542plus Release 2.5, software version V4E03x. Please consider also the Users Manual WebREF 1VTA 100180.

  • Page 9: Safety Information

    To setup switches and gateways with the IPSec feature is mandatory as described in this manual. Do not make any changes to the REF 542plus configuration unless you are familiar with the REF 542plus and its configuration tool. This might result in disoperation and loss of...

  • Page 11: Supported Browsers

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual Supported browsers The WebREF supports Microsoft Internet Explorer 5.x, 5.5 and 6.x for Windows. To parse the xml-files and requests, the browser needs the MSXML 3.0 parser, which comes with IE 5.5 and higher.
  • Page 12 Multifunctional Protection and Switchbay REF 542plus 1MRS755865 Control Unit Installation Manual for Web Interface Installation manual A051090 Fig. 3.2.-1 Trusted sites selection in the Internet browser A further setting required for user authentication services is the enable setting for proxy connections, See Fig. 3.2.-2. It can be found in the Internet Options;...
  • Page 13 1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual A051093 Fig. 3.2.-2 Enable the setting for proxy connections...

  • Page 15: Web Access And Security Requirements

    Installation manual Web access and security requirements Web access to REF 542plus has to be protected with IPSec authentication (IP level), if the substation is connected to a company’s intranet. In this case, a gateway which provides the IPSec feature to be installed is recommended, as shown in Fig.

  • Page 16: User Authentication

    Therefore, digest authentication algorithms are used in the configuration tool and REF 542plus core unit. This way passwords are not communicated as plain text through the communication line because they are already converted on the PC level with an AES algorithm encryption key and converted back on the device level.

  • Page 17: Attack From Remote

    An attack from remote, meaning from outside the local REF network, should be prevented. Therefore, unauthorized users should not be able to get access to REF 542plus. A remote attack is only possible when the devices are connected to company intranet or Internet. Installing the IPSec function is recommended.

  • Page 19: Webref Configuration

    Installation manual WebREF Configuration With the Configuration Tool of REF 542plus the WebREF function can be enabled and configured. To have the single line diagrams correctly displayed on the Web page, some requirements in the graphical design of SLD are needed.

  • Page 20: Switchgear Overview

    Multifunctional Protection and Switchbay REF 542plus 1MRS755865 Control Unit Installation Manual for Web Interface Installation manual A051094 Fig. 5.1.-1 SLD design constraints 5.2. Switchgear overview The switchgear overview is generated automatically. No configuration to get the page is necessary. To get the overview on the right shape, some rules have to be respected: The overview is oriented according to the IP addresses.

  • Page 21: Web Communication Configuration

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual 5.3. Web communication configuration Select Configuration > Communication to open the configuration possibility. The property sheet as shown in Fig. 5.3.-1 will be opened.

  • Page 22: Set Web Server Properties

    Fig. 5.4.-1 Parameter setting for the Ethernet network In the TCP/IP configuration these 3 options can be set for each REF 542plus. In case there is no router in place, the default gateway address can be left open. The subnet mask is set to a default value of 255.255.252.0.

  • Page 23: Gsm Sms Properties

    Fig. 5.6.-1 Gateway configuration for SMS messages to a GSM modem REF 542plus can be either configured to function as a gateway for SMS messages to the GSM modem, or as a normal SMS message source. As the gateway function is configured, REF 542plus will receive all SMS messages from the Ethernet network and forward them to the GSM modem for transmitting into the GSM network.

  • Page 24: Ref As Sms Gateway

    SMS gateway setting A REF 542plus, with the GSM physically connected via the serial interface, is the SMS gateway. Only a REF 542plus which has a GSM physically connected can be a SMS gateway. Therefore, a REF 542plus used for gateway has to be configured as REF is SMS gateway and the MODEM has to be configured.

  • Page 25: Ip Address Of Sms Gateway

    Fig. 5.6.3.-1 IP address for the SMS gateway When REF 542plus has no GSM physically connected, the IP address of SMS gateway button has to be selected. Also, the IP address of the gateway has to be typed. Verify that the address is correctly typed because this can...

  • Page 26: Language File Generation

    This shows that the connection to the embedded Web server of the REF 542plus is lost. A060416 Fig. 5.8.-2 Lost connection to the embedded Web server in REF 542plus The English language is always present and cannot be unselected by the Configuration or Operating Tool of REF 542plus.
  • Page 27 Installation Manual for Web Interface Installation manual Web-enabled REF 542plus Web pages can be displayed in two different languages, in English and in a second local language. This means that independently of device configuration and firmware, the user can set a...

  • Page 29: Communication Requirements And Network Installation

    RJ-45 female connector pin assignment 6.1.2. Connecting REF 542plus To connect the Ethernet cable to REF 542plus, plug the RJ-45 male connector into the female connector (port X70 of REF 542plus core unit) according to the keying until it snaps into place.

  • Page 30: Using Media Converter

    Fig. 6.2.1.-1 shows the pin assignment in case: Cross Over connection cable: the cable connects REF 542plus directly to a PC in a point-to-point fashion and REF 542plus is not connected in a network. The same cable is needed to connect two hubs between them.

  • Page 31: Hubs

    Installation manual Although transient suppression circuitry is present on Ethernet RJ-45 port of REF 542plus, the high amplitude transients can potentially damage the port and its link partners. It is recommended to use RJ-45 ports only inside the switchgears or inside environments sufficiently protected.

  • Page 32: Switches

    Section 6.3. Network topology . ABB recommends for switches: For small plants, ABB recommends Phoenix Contact FL SWITCH 8TX, Ethernet switch, 8 front Ethernet ports in RJ-45 format, automatic detection of data transmission rate of 10/100 Mbps, coupling network segments with different transmission rates, auto-crossing function, DIN rail mountable.

  • Page 33: Network Topology

    Installation manual For connections directly from the substation and installation in the switch gear, ABB recommends Westermo ED-20. It is an industrialized DIN Rail mounted serial to Ethernet router. The device will allow access to a remote Ethernet network via a PSTN, ISDN or radio modem.

  • Page 34: Example Of Star Topology With Ref 542Plus

    In case a GSM Modem is connected, one device per total network is sufficient. 6.3.3. Example of star topology with REF 542plus WebREF is particularly suitable for low-end solutions. The Fig. 6.3.3.-1 shows a typical architecture for low-end systems based on a single network in star-topology.

  • Page 35: Ring Topology

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual A051111 Fig. 6.3.3.-1 Example of star topology 6.3.4. Ring topology A typical ring topology is illustrated in Fig. 6.3.4.-1. It is very similar to the bus topology except that the loop is closed from the switch N back to switch 1.

  • Page 36: Example Of Redundant Ring Topology With Ref 542Plus

    Installation Manual for Web Interface Installation manual A051112 Fig. 6.3.4.-1 Ring topology 6.3.5. Example of redundant ring topology with REF 542plus Considering the Fig. 6.3.5.-1, the structure is made connecting backbone ports of switches (generally provided in industrial Ethernet switches).

  • Page 37: Integration Within The Switchgear

    A051113 Fig. 6.3.5.-1 Example of redundant ring structure Each REF 542plus is connected by means of a single electrical connection to the switch of its subsystem. The fibre optics cables are recommended for the loop. By means of the ring structure, it is possible to build a redundant communication system at station level, see Fig.

  • Page 38: Example Of Complex Topology

    Multifunctional Protection and Switchbay REF 542plus 1MRS755865 Control Unit Installation Manual for Web Interface Installation manual To connect the switch externally by means of an optical cable, Plastic Fibre Optic or Glass Fibre Optic depending on the distance and the environment.

  • Page 39: Network Address Configuration

    For more information regarding IP Address, Subnet mask and Default Gateway address, see Section 7. Terminology. The IP address is stored in the configuration file (.ref) downloaded by the REF 542plus engineering tool. The tools runs on a PC connected point-to- point with the serial port of RHMI.

  • Page 40: Ip Address

    Installation Manual for Web Interface Installation manual The REF 542plus has a default IP address. To configure the new IP address the operator has to configure the IP address before to connect the REF 542plus to the network. This in order to avoid address conflicts between the default IP address and IP addresses already configured in the Ethernet network.

  • Page 41: Default Gateway Configuration

    It means that a maximum of 254 different sub networks can be configured in REF. The REF is only building a switchgear overview for the matching subnet part. The identification of the subnet part and IP part is REF 542plus specific, but is not in conflict with any standard.

  • Page 42: Examples Of Communication System Addressing

    Communication system addressing should be based on the following network design rules: The router and REF 542plus devices belonging to the LAN plant have to have the same subnet mask address. The default gateway address configured in each REF 542plus has to be equal to the IP address of the router.
  • Page 43 ISDN, is needed, a router has to be connected to Ethernet network 2 and not directly to 1. Note the DHCP configuration for the server in the example. This is necessary to have a “transparent” access to REF 542plus from the Corporate WAN side.

  • Page 44: Communication System Security

    Multifunctional Protection and Switchbay REF 542plus 1MRS755865 Control Unit Installation Manual for Web Interface Installation manual A051119 Fig. 6.4.7.-2 Example of network addressing with PC server 6.5. Communication system security Required for customers connecting to intranet or Internet only.

  • Page 45: Access Through Standard Ethernet Router

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual 6.5.1. Access through standard Ethernet router It is mandatory to connect the LAN plant to the Internet or to intranet by means of a router offering at least the basic security functions, such as IPSec, password protection and so on.
  • Page 46 Multifunctional Protection and Switchbay REF 542plus 1MRS755865 Control Unit Installation Manual for Web Interface Installation manual IPSec major benefits are: IPSec is below the transport layer and therefore transparent to applications. The software on user or end system does not need to be adapted, if IPSec is implemented in a firewall or router.

  • Page 47: Terminology

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual Terminology Term Description Default Gateway The default gateway address is your router or switch IP address that does the address forwarding in case the IP address of the receiver in not the subnet of the sender.

  • Page 49: Abbreviations

    1MRS755865 Multifunctional Protection and Switchbay REF 542plus Control Unit Installation Manual for Web Interface Installation manual Abbreviations Abbreviation Description Advanced Encryption Standard Internet Protocol Local Area Network Low Voltage RHMI Remote Human-Machine Interface as control unit Substation Configuration Language (defined by IEC...
  • Page 52 ABB Oy Distribution Automation P.O. Box 699 FI-65101 Vaasa FINLAND +358 10 2211 +358 10 224 1080 www.abb.com/substationautomation...
