Summary of Contents for Carrier Performance 50VR
Page 1
50VR Performance™15 SEER Single and Three Phase 2-Stage Packaged Heat Pump System with Puron® (R-410A) Refrigerant 2-5 Nominal Tons (Sizes 24-60) Owner’s Information Manual A09033 Fig. 1 – Unit 50VR NOTE TO EQUIPMENT OWNER: For your convience, please record the model and serial numbers of your new equipment in the spaces provided.
50VR: Owner’s Information Manual Safety Considerations CAUTION Improper installation adjustment, alteration, service, maintenance, or use can cause explosion, fire, electrical shock, or other conditions which CUT HAZARD may cause death, personal injury, or property damage. Consult a Failure to follow this caution may result in personal injury. qualified installer, service agency, or your distributor or branch for information or assistance.
Page 3
50VR: Owner’s Information Manual Defrost Mode Air Filters When your unit is providing heat to your home or office and the outdoor The air filter(s) should be checked every 3 or 4 weeks and changed or temperature drops below 45°F (7.2°C), moisture may begin to freeze on cleaned whenever it becomes dirty.
Page 4
50VR: Owner’s Information Manual Fans and Fan Motors 5. Inspection of the unit base to ensure that no cracks, gaps, etc., exist which may cause a hazardous condition. Periodically check the condition of fan wheels and housings and 6. Inspection of the unit casing for signs of deterioration. fan-motor shaft bearings.
Page 5
50VR: Owner’s Information Manual Table 2 – Maintenance Checklist Monthly maintenance items and outdoor unit rinsing may be performed by the consumer. All other maintenance items and all service work must be performed by a qualified service technician. Read all Warning labels. Description of Maintenance Recommended Interval Consumer specific:...
