Connections

Caution: Plug the power cables for the sub-
woofer and other audio/video components into
an AC outlet only after you complete all other
connections.

Basic connection example

Connect a subwoofer cable to the output jack of
your AV amplifier and to the INPUT jack of the
subwoofer.
Amplifier (The rear panel of various
amplifiers may differ in appearance.)
Subwoofer rear panel
INPUT
VOLUME
POWER
INPUT
ON
OFF
To AC outlet
Connecting components and the
subwoofer to AC power
After you complete a subwoofer connection, plug
the amplifier, other audio/video component, and
the subwoofer into an AC outlet of appropriate
voltage.
