Summary of Contents for Viessmann 5054
Page 1
Gebrauchsanleitung Manual Liebespaar, bewegt mit Bett Lovers in Bed 5054 Wichtige Hinweise....2 Einbau und Anschluss....2 Important Notice.....3 Installing and wiring....3 Fig. 1 - 2.........3 Fig. 3 - 4.........4...
Page 2
Sie an die beiden Wechsel- Verwenden Sie nur nach VDE / EN strom-Anschlüsse Ihres Lichttransfor- gefertigte Modellbahn-Trafos. mators (z. B. Viessmann 5200, siehe Fig. 1) an. Bei einem Gleichstromtrafo Fassen Sie das Modell nur am muss das braune Kabel an den Pluspol...
Page 3
– exclusively in to the output terminals of your lighting dry areas. The power supply should transformer (e.g.: Viessmann 5200, see be between 14 and 16 V AC or DC. fig. 1). If you have a DC power pack...
Page 4
Fig.3 Fig. 4 90° Technische Daten: Betriebsspannung 14 - 16 V =/~ Höhe über Grundplatte 24 mm Stromaufnahme ca.100 mA Länge Antriebszylinder 42 mm Technical Data: Voltage 14 – 16 V =/~ Height above baseboard 24 mm Current draw appr. 100 mA Length of drive 24 mm Dieses Produkt ist kein Spielzeug.
