Page 1
Combiners Installation Sheet Introduction GE Security Multi-Channel VPD Combiners combine video, PTZ data, and camera power over a single 4-pair UTP cable to simplify CCTV installations in a structured wiring environment. They support up to 16 cameras. The GEC-8VPDCHUB and the GEC-16VPDCHUB models come with built-in AC power supplies.
Page 2
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. 8) Install in accordance with the manufacturer’s instructions.
To reduce the risk of fire or electrical shock, do not expose these products to rain, moisture, dripping or splashing. • No objects filled with liquids, such as vases, shall be placed on GE equipment. • DO NOT block ventilation openings to let sufficient airflow to the UTP devices.
Page 4
We recommend using short 18 AWG solid wires for ground connections. • GE VPD products follow the EIA/TIA 568 standard. There are two wire color- code standards: EIA/TIA 568A and EIA/TIA 568B. Either standard can be used for making connections as long as the RJ-45 jacks at both ends of each cable follow the same standard.
240 ft. / 73 m 1 AMP Camera Dual 23 AWG 58 ft. / 18 m 114 ft. / 35 m 300 ft. / 92 m Application Drawings GEC-4VDPC GEC-16VDPC P/N 1069680 • REV 1.0 • ISS 14APR10 5 of 12...
Page 6
GEC-8VPDCHUB GEC-16VDPCHUB Mid-Span Installation GEC-4VDPC and GEC-16VDPC Turn off external power supply. Video: Connect each RJ-45 video connector to a Cat-5 cable carrying 4 video signals to the control room. Data: Connect each RJ-45 data connector to a Cat-5 cable carrying 4 data signals to the control room.
Power: Connect the power input connectors to the external class II power supply. Make sure that the power requirement is within the recommended range. Turn on the external power supply. GEC-8VPDCHUB and GEC-16VPDCHUB Turn off external power supply. Video: Connect each RJ-45 video connector to a Cat-5 cable carrying 4 video signals to the control room.
Page 8
OFF: Fuse is blown or not installed ON: Fuse is OK, power is available at RJ45 connector EIA/TIA 568A, B Color Codes Midspan/Control Room Video Connections GEC-4VDPC, GEC-16VDPC, GEC-8VPDCHUB, and GEC-16VPDCHUB (Camera 1-8) GEC-16VDPC and GEC-16VPDCHUB (Camera 9-16) 8 of 12...
Midspan/Control Room Data Connections GEC-4VDPC, GEC-16VDPC, GEC-8VPDCHUB, and GEC-16VPDCHUB (Camera 1-8) GEC-16VDPC and GEC-16VPDCHUB (Camera 9-16) Technical Specifications* Electrical Video Format NTSC, PAL, SECAM Frequency DC to 10 MHZ Coax 75 Ohm Twisted Pair 100 Ohms +/- 20%, 24 AWG min., unshielded Category 2-7 up to 750 ft.
GEC-8VPDCHUB: Extruded Aluminum and sheet metal GEC-16VPDCHUB: Extruded Aluminum and sheet metal Dimensions (W x H x D) GEC-4VDPC: 4.97 x 1.74 x 177 in. (12.6 x 4.4 x 4.5 cm) GEC-16VDPC: 18 x 1.74 x 1.77 in. (46 x 4.4 x 4.5 cm) GEC-8VPDCHUB: 17 x 1.74 x 10.5 in.
EU authorized manufacturing representative: GE Security B.V., Kelvinstraat 7, 6003 DH Weert, The Netherlands Regulatory N4131 information Note: C-Tick mark applies to GEC-4VDPC and GEC-16VDPC only. North American UL 60065 standards P/N 1069680 • REV 1.0 • ISS 14APR10 11 of 12...
FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
