Wolf GAS COOK TOPS Installation Instructions Manual
Wolf appliance company inc gas cook tops installation instructions
Hide thumbs
Also See for GAS COOK TOPS:
- Installation manual (16 pages) ,
- Use & care information manual (19 pages)
Related Manuals for Wolf GAS COOK TOPS
Summary of Contents for Wolf GAS COOK TOPS
- Page 1 O O K T O P S NSTALLATION NSTRUCTIONS...
- Page 2 ® WOLF is a registered trademark of Wolf Appliance Company, Inc. As you follow these instructions, you will notice WARNING and CAUTION symbols. This blocked information is important for the safe and efficient installation of Wolf equip- ment. There are two types of potential hazards that may occur during installation.
-
Page 3: Important Note
W O L F G A S C O O K TO P S I N S TA L L AT I O N R E Q U I R E M E N T S IMPORTANT NOTE: This installation must be completed by a qualified installer, service agency or gas supplier. - Page 4 W O L F G A S C O O K TO P S B E F O R E Y O U S T A R T Proper installation is your responsibility. Have a qualified technician install this cooktop. You must also assure that electri- cal installation is adequate and in compli- ance with all local codes and ordinances.
- Page 5 I N S TA L L AT I O N I N S T R U C T I O N S S I T E P R E P A R A T I O N C O U N T E R T O P C U T- O U T D I M E N S I O N S IMPORTANT NOTE: Countertop opening dimensions shown on the following pages must be used.
- Page 6 W O L F G A S C O O K TO P S I N S TA L L AT I O N The illustrations below provide the overall dimensions, countertop cut-out and installation specifications for Model CT15G. For Model CT15G, the gas service may be supplied through the floor if the cooktop is not installed above an oven.
- Page 7 I N S TA L L AT I O N I N S T R U C T I O N S I N S TA L L AT I O N S P E C I F I C A T I O N S The illustrations below provide the overall dimensions, countertop cut-out and installation specifications for Model CT30G.
- Page 8 W O L F G A S C O O K TO P S I N S TA L L AT I O N The illustrations below provide the overall dimensions, countertop cut-out and installation specifications for Model CT36G. IMPORTANT NOTE: 39" (991) wide cabinets are recommended for installation of Model CT36G.
- Page 9 I N S TA L L AT I O N I N S T R U C T I O N S V E N T I L AT I O N O P T I O N S IMPORTANT NOTE: It is recommended that you operate the Wolf gas cooktop with either a Wolf cooktop ventilation hood, downdraft system or Pro ventilation hood.
-
Page 10: Explosion Hazard
W O L F G A S C O O K TO P S G A S S U P P LY EXPLOSION HAZARD — Use a new CSA approved gas supply line and install a gas shut-off valve. I M P O R TA N T Securely tighten all gas connections. -
Page 11: Electrical Shock Hazard
I N S TA L L AT I O N I N S T R U C T I O N S G A S S U P P LY R E Q U I R E M E N T S L I N E P R E S S U R E T E S T I N G Testing above psi (3.5 kPa) 14"... - Page 12 W O L F G A S C O O K TO P S C O O K T O P I N S TA L L AT I O N Remove the cooktop, pressure regulator, burner grates and burner caps from the shipping package.
- Page 13 I N S TA L L AT I O N I N S T R U C T I O N S C O O K T O P I N S TA L L AT I O N G A S S U P P LY L I N E C O N N E C T I O N Assemble the flexible metal connector from the gas supply pipe to the pressure regulator.
- Page 14 Neither this book nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Wolf Appliance Company, Inc., an affiliate of Sub-Zero Freezer Company, Inc. ©Wolf Appliance Company, Inc. all rights reserved.
- Page 15 I N S TA L L AT I O N I N S T R U C T I O N S W I R I N G D I A G R A M S Model CT15G LR SPARK RR SPARK MODULE MODULE...
- Page 16 W O L F A P P L I A N C E C O M PA N Y, I N C. P. O. B OX 4 4 8 4 8 M A D I S O N , W I 5 3 7 4 4 8 0 0 - 3 3 2 - 9 5 1 3 W O L FA P P L I A N C E .
