Land Pride SF2566 Operator's Manual
Hide thumbs
Also See for SF2566:
- Parts manual (12 pages) ,
- Specifications (1 page) ,
- Operator's manual (25 pages)
Table of Contents
Advertisement
Quick Links
Scarifiers
SF2566 & SF2577
10401
Table of Contents
Read the Operator's Manual entirely. When you
!
see this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Cover photo may show optional equipment
not supplied with standard unit.
© Copyright 2014
302-188M
Operator's Manual
Printed
11/10/15
Advertisement
Table of Contents
Related Manuals for Land Pride SF2566
Summary of Contents for Land Pride SF2566
- Page 1 Table of Contents Scarifiers SF2566 & SF2577 10401 302-188M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
-
Page 2: Machine Identification
Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you, or the dealer, have added Options not originally ordered with the machine, or removed Options that were originally ordered, the weights and measurements are no longer accurate for your machine. - Page 3 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
-
Page 5: Safety At All Times
Download the appropriate App on your Refer to Parts Manual QR smart phone, open the App, point your Locator on this page for phone on the QR code and take a picture. detailed instructions. 11/10/15 SF2566 & SF2577 Scarifiers 302-188M... - Page 6 ▲ Replace parts on this machine with ▲ Work in a clean dry area. rating equal to or greater than the genuine Land Pride parts only. Do gross weight of the towed ▲ Lower attached implement to the not alter this machine in a way machinery.
- Page 7 ▲ Never allow children to operate ▲ Be sure to ask how close you can as a hard hat, safety shoes, safety equipment. glasses, and ear plugs. work to the marks they positioned. 11/10/15 SF2566 & SF2577 Scarifiers 302-188M...
-
Page 8: Using This Manual
Table of Contents Introduction Introduction Owner Assistance Land Pride welcomes you to the growing family of new product owners. The Online Warranty Registration or Warranty Registration card should be completed by the dealer at This Scarifier has been designed with care and built by the time of purchase. -
Page 9: Accessory Attachments
SF25 Assembly Accessory Attachments Refer to Refer to Figure 1-1: The Scarifier is designed and built by Land Pride for piggyback attachment and simultaneous use of Land Attach 3-Point upper link (#10) to Scarifier frame with Pride 15 and 25 Series Landscape Rakes or 15 and 25 hardware as indicated, making certain upper link is Series Rear Blades. -
Page 10: Tractor Hook-Up
6. Ensure that lower hitch arms are blocked to prevent laying on the ground or use auxiliary supports such excessive side movement. as post planted in the ground to prevent the possibility of the unit tipping over. 24711 Tractor Hook-Up Figure 1-2 SF2566 & SF2577 Scarifiers 302-188M 11/10/15... -
Page 11: Section 2: Operating
“Section 6: Features & Benefits” on page 11 for Land Pride for piggyback attachment and simultaneous additional information and performance enhancing use of the Land Pride 15 and 25 Series Landscape Rakes options. or 15 and 25 Series Rear Blades. This dual capability... - Page 12 4 1/2" Below Top Hole 4" Below 2nd Hole 2 1/2" Below 2nd Hole 2" Below 3rd Hole 1/2" Below 3rd Hole Even with cutting edge Bottom Hole 1 1/2" Above Bottom Hole 2" Above SF2566 & SF2577 Scarifiers 302-188M 11/10/15...
-
Page 13: Maintenance
CAUTION! Scarifier from tractor. Refer to “Unhook Scarifier” on the left-hand side of this page. Do not alter Land Pride equipment or replace parts with other brands. Doing so can cause equipment to perform improperly • Store Scarifier in a clean, dry place. Inside storage and may lead to breakage that can cause bodily injury. -
Page 14: Section 5: Specifications & Capacities
4 adjustments in 2” increments Horsepower Rating/Engine 25 to 50 HP Hitch Type Limited Cat.1 with Floating Top Link for Second Implement 3/4” x 2 1/2” Heat Treated Spring Steel Shanks Shank Type with Dimpled-On Tips 27517 SF2566 & SF2577 Scarifiers 302-188M 11/10/15... -
Page 15: Section 6: Features & Benefits
Allows for second implement to work in conjunction with the Scarifier such as a Landscape floating top link Rake. Compatible with Land Pride 15 & 25 Series Rakes and Blades. 5/16” Wall thickness High tensile strength to take the pressure from the shanks. -
Page 16: Section 7: Torque Values Chart
= nominal thread diameter in millimeters x thread pitch 1-1/2" - 12 1330 2970 2190 4820 3560 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. SF2566 & SF2577 Scarifiers 302-188M 11/10/15... -
Page 17: Warranty
This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship. - Page 18 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
