Summary of Contents for HP Broadband Series

  • Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
  • Page 2 Broadband Series Test System SERIAL NUMBERS This manual applies directly to instruments with serial numbers prefixed 3114U. For additional important information about serial numbers, see Chapter 1. HP E1663A SONET/SDH Electrical Interface User’s Guide Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3 Application Version Edition 1 January 1995 A.01.00 Edition 1A Rev. 1 July 1997 A.01.00 Call your local HP representative, or: Product support Tel: 1-800-661-3868 (In North America) Tel: 403-430-2770 (Outside North America) Fax: 403-430-2601 Email: support@idacom.hp.com Hewlett-Packard Company We want to hear from you. If you have any...

  • Page 4: Table Of Contents

    Overview Connecting to an Optical Line Interface Connecting to the System Under Test Starting a Test Session Log in to the HP Broadband Series Test System 2-6 3 C Function Reference Electrical Interface Library Library Initialization 3-3 Amplifier Gain Setup 3-3...
  • Page 5 Contents Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 6 Figures Figure 1.1 Typical Configuration Figure 2.1 Module address settings Figure 2.2 Interconnecting the modules Figure 2.3 Connecting to the system under test Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 7 Figures Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 8: Introduction

    Introduction Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 9 Introduction This chapter provides an overview of the HP E1663A SONET/SDH Electrical Interface. It covers: • a general description of the Electrical Interface, including identification and accessories • the Control panel • the front panel indicators and connectors • the functional features •...

  • Page 10: Overview

    Under Test, transmitting and receiving 155.52 Mb/s or 52 Mb/s SONET/SDH trans- mission signals. The HP E1663A is used in conjunction with the HP E1697A 155 Mb/s Optical Line Interface or the HP E1617A 52 Mb/s Optical Line Interface, and communication between the modules is by SMA to SMB Radio Frequency (RF) adaptor cables.

  • Page 11: Control Panel At A Glance

    Control Panel at a Glance Manage Configuration files with these menus. See “Getting Started” in your HP E1697A 155 Mb/s Optical Line View the application and Interface User’s Guide. firmware versions, and module identification details. Set signal amplification. See below.

  • Page 12: Front Panel At A Glance

    5 V. INTERMODULE CONNECTORS TRANSMIT CLOCK IN This SMA connector accepts the clock input from the HP E1697A. It is an ECL input, and is terminated in 50 Ω to −2 V dc (nominal). TRANSMIT DATA IN This SMA connector accepts data, in the binary NRZ format, from the HP E1697A. It is an ECL input, and is terminated in 50 Ω...

  • Page 13: Functional Features

    HP E1499A V/382 HP E1697A Controller. See the HP E1697A 155 Mb/s Optical Line Interface User’s Guide (HP p/n E1697- Note 90002) for guidance when configuring the 155 Mb/s Optical Line Interface. Transmitter The HP E1697A supplies binary NRZ (nonreturn to zero) formatted data signals and associated clock signals to the input of the Electrical Interface.

  • Page 14: Receiver

    The receiver clock is recovered from the data stream for the subsequent decoding circuitry. Decoding produces data signals in binary NRZ format, and both the clock and regenerated data signals are passed to the HP E1697A for processing. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 15: Esd Precautions

    ESD Precautions The Electrical Interface contains components sensitive to electrostatic discharge. CAUTION To prevent component damage, carefully follow the handling precautions pre- sented below. The smallest static voltage most people can feel is about 3500 volts. It takes less than one tenth of that (about 300 volts) to destroy or severely damage static sen- sitive circuits.

  • Page 16: Service

    Service The performance of the Electrical Interface should be verified annually to ensure that it is operating within the specifications. To do this, see the HP 75000 Series 90 HP E1663A SONET/SDH Electrical Interface User’s Manual (HP p/n E1663-90001). If it is necessary to return the Electrical Interface to Hewlett-Packard for service, ensure the following information is sent with the module: •...

  • Page 17: Storage And Shipment

    Storage and Shipment The Electrical Interface may be stored or shipped in environments within the fol- lowing limits: : −40°C to +75°C. Temperature Humidity : 50% to 95% RH from 25°C to 40°C. Altitude : Up to 4600 m (15,000 ft). The module should also be protected from temperature extremes which may cause condensation within the clamshell enclosure.
  • Page 18 Introduction Storage and Shipment 4 Seal the carton with strong, nylon, adhesive tape. 5 Mark the carton “FRAGILE, HANDLE WITH CARE”. 6 Retain copies of all shipping papers. 7 In any correspondence, refer to the module by model number and full serial number.
  • Page 19 Introduction Storage and Shipment 1-12 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 20: Getting Started

    Getting Started Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 21: Overview

    Overview The following diagrams show you how to set up, and operate the line interface. For details, read the relevant manuals. Ensure that the module is correctly installed in the mainframe before installing software. Refer to the E1663A Module Installation Guide (E1663-91200) for instructions Once you have correctly installed the module, software, and online help: Connect to an optical...
  • Page 22 Getting Started Overview 155 Mb/s Optical Line Configure the Optical Interface or 52 Mb/s Line Interface and the Optical Line Interface Electrical Interface for User’s Guide the test session. SONET/SDH Electrical Interface User’s Guide. 155 Mb/s Optical Line Test convergence, cell, Interface or 52 Mb/s and physical layers.

  • Page 23: Connecting To An Optical Line Interface

    RF cables with an SMA connector on one end and an SMB connector on the other. Connections are shown in Figure 2.1. Figure 2.1 Interconnecting the modules HP E1697A Optical Line HP E1663A Interface or HP E1617A SONET/SDH...

  • Page 24: Connecting To The System Under Test

    Connecting to the System Under Test Connect the Electrical Interface to the System Under Test as shown. Figure 2.2 Connecting to the system under test HP E1663A SONET/SDH Electrical Interface System Under Test. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 25: Starting A Test Session

    Log in to the HP Broadband Series Test System Refer to “Setting Up a Test Session” and “Starting a Test Session” in the 155 Mb/s Optical Line Interface User’s Guide before logging into the HP Broadband Series Test System. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 26: Function Reference

    C Function Reference Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 27 C Function Reference The HP E1663A SONET/SDH Electrical Interface cannot be used stand-alone. It must be used in conjunction with an HP E1697A 155 Mb/s Optical Line Interface module. This chapter describes the Electrical Interface library. See your 155 Mb/s Optical Line Interface User’s Guide for information on how to write test programs using the HP Broadband Series libraries.

  • Page 28: Electrical Interface Library

    Electrical Interface Library The SONET/SDH Electrical Interface library, , provides functions to libeif155.a control the module. Its header file is . All Electrical Interface <hpt/eif155.h> library functions have the prefix HptEif155. All of these functions returns -1 if an error occurs, 0 otherwise. Library Initialization int HptEif155InitLib ();...
  • Page 29 C Function Reference Electrical Interface Library Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 30: Specifications

    Specifications Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 31 Specifications Except where otherwise stated, the following parameters are warranted perfor- mance specifications. Parameters described as “typical” or “nominal” are supple- mental characteristics which provide a useful indication of typical, but non- warranted, performance. All specifications are for 0°C to 55°C after a 30 minute warm-up.

  • Page 32: Electrical Specifications

    Specifications Electrical Specifications Electrical Specifications Power Requirements (maximum) dc Volts dc Current Dynamic Current Power Dissipation 1.1 A 110 mA 27 Watts −5.2 V 2.1 A 210 mA −2 V 1.3 A 130 mA 12 V 0.35 A 35 mA −12 V 0.32 A 32 mA...
  • Page 33 Specifications Electrical Specifications Coded Electrical Transmitter 155.52 MHz with 50% ± 10%duty cycle (typical) Clock Data Serial stream: 155.52 Mb/s (nominal) The exact transmit bit rate is derived from the binary clock and data input signals Format Output STS-3 and STM-1 Signals ±...
  • Page 34 Specifications Electrical Specifications Coded Electrical Receiver 155.52 MHz with 50% ± 10% duty cycle (typical) Clock Serial stream: 155.52 Mb/s ± 100 ppm Data Format Input Signals STS-3 and STM-1 Equalization Automatic equalization Monitor Mode 20 dB of fixed gain to cater for nominal monitor point loss Return Loss >...

  • Page 35: Mechanical Specifications

    Specifications Mechanical Specifications Mechanical Specifications Physical Size One C-size slot Weight 1.6 kg (nominal) Environmental Operating Conditions 0 to 55 °C. Operating Temperature −40 to 75 °C. Storage Temperature 50% to 95% relative humidity from 25 to 40 °C. Humidity Artisan Technology Group - Quality Instrumentation ...

  • Page 36: Standards

    Specifications Standards Standards EMC Regulatory Compliance FTZ 1046/1984 (CISPR11, EN55011) Electrical Safety Standards IEC 348 (1978) CSA - C22.2 No. 231 Series - M89 Communications Standards ANSI T1.105-1991, TR-TSY-000253 ITU (CCITT) Recommendations G.703 Bellcore TA-NWT-000253 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 37 Specifications Standards Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 38: Index

    Index module identification, 1-4 amplifier, monitor, 1-7 monitor amplifier, 1-7 anti-static precautions, 1-8 packaging, 1-10 C library commands HptEif155InitLib, 3-3 HptEif155SetInputGain, 3-3 receiver clock, 1-7 cabling, intermodule, 2-4 receiver function, 1-7 clock recovery, 1-7 connections, intermodule, 2-4 service procedures, 1-9 connectors shipping details, 1-9, 1-10 intermodule, 1-5...
  • Page 39 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
