Yamaha RBX374 Service Manual

RBX374/RBX375
WARNING : CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition,
other electrical/electronic and/or plastic (Where applicable) components may
also contain traces of chemicals found by the California Health and Welfare
Agency (and possibly other entities) to cause cancer and/or birth defects or
other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COM-
PONENTS IN YOUR MOUTH FOR ANY REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When
soldering, do not inhale solder fumes or expose eyes to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure
of this product, wash your hands before handling food.
EG 011746
ELECTRIC BASSES
SERVICE MANUAL
<Other color>
BL
FSL
CONTENTS
OVERALL ASSEMBLY ............................................................. 2
ELECTRICAL PARTS ................................................................ 6
CIRCUIT BOARDS .................................................................... 6
CIRCUIT DIAGRAM .................................................................. 7
WIRING ..................................................................................... 8
SPECIFICATIONS ..................................................................... 8
Copyright (c) Yamaha Corporation. All rights reserved. PDF-K351
<Other color>
RM
RM
BL
RBX374
HAMAMATSU, JAPAN
FSL
RBX375
'04.10
