Denon AVR-X5200W Service Manual page 30

3.5.6. Video system confirmation items
fig. XX: See the block diagram of the fig.XXth.
Paths confirmation item
Analog Video
V 0 1 : V I D E O
fig.16
1
Video Convert
V 0 2 : V . C O N V E R T
(Analog or HDMI ⇒ HDMI) fig.17
2
HDMI pass
V 0 3 : H D M I
（MAIN ZONE） fig.18
3
HDMI CEC
V 0 4 : H D M I
fig.19
4
HDMI Audio
V 0 5 : H . A U D I O - A V R
fig.20a
(Audio : AVR)
fig.20b
5
fig.20c
HDMI Audio
V 0 6 : H . A U D I O - T V
(Audio : TV)
fig.21a
6
fig.21b
GUI
V 0 7 : G U I
fig.22
7
HDMI
V 0 8 : Z O N E 2
(ZONE2) fig.23
8
Display
Input Source : CBL/SAT
P A S S
Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
P A S S
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
C E C
HDMI Control : ON
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR ( if checking the audio output from AVR )
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : TV ( if checking the audio output from TV )
Input Source : CBL/SAT
M E N U O N
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu : ON
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
H D M I
ZONE2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
Settings
・Component input ⇒ Component output
(bAs the input source, you can switch from CBL/SAT to other ones.
・CVBS input ⇒ IP Scaler ⇒ HDMI output.
・Component input ⇒ IP Scaler ⇒ HDMI output.
・HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
（bThe input source can be switched to any source except CBL/SAT.）
・HDMI input ⇒ HDMI output（MAIN ZONE）
（bThe input source can be switched to any source except CBL/SAT.）
・ When the power supply of a TV is put in the standby mode, make sure that the power supply of this unit is also put
in the standby mode.
・The ARC path can also be checked (check this using the TV input source).
（bThe input source can be switched to any source except CBL/SAT.）
・HDMI input(PCM , DolbyDigital , DTS) ⇒ Speaker output.
・HDMI input(HD audio) ⇒ Speaker output.
（bThe input source can be switched to any source except CBL/SAT.）
・HDMI input(PCM , DolbyDigital , DTS) ⇒ HDMI output (audio output from connected TV)
（bThe input source can be switched to any source except CBL/SAT.）
・GUI display ⇒ HDMI output.
（bThe input source can be switched to any source except CBL/SAT.）
・HDMI input ⇒ HDMI output (ZONE2)
(bAs the input source, you can switch from CBL/SAT to other ones.)
30
Contents of confirmation Remarks
