- Page 1 PAIRING YOUR NEW SIERRA SLEEP POWER BASE BY ASHLEY M9X432,M9X442/442A, M9X532, M9X542/542A, M9X632, M9X642A/642A A STEP BY STEP GUIDE...
-
Page 2: Power Supply
POWER SUPPLY (M9X432 & M9X442/442A 1. CONNECT THE POWER SUPPLY CORD INTO THE POWER 2. UNPLUG THE POWER SUPPLY CABLE FROM THE SUPPLY AND PLUG INTO AN OUTLET (MAKE SURE IT IS POWER SUPPLY (DO NOT UNPLUG FROM WALL CONNECTED TO THE POWER BASE) OUTLET) - Page 3 REMOTE SYNC M9X432 & M9X442/442A 3. HOLD DOWN THE “HOME” AND “DOWN” BUTTONS SIMULTANEOUSLY UNTIL THE BLUE BACKLIGHT DISSAPERS (WITHIN 5-7 SECONDS)
- Page 4 4. PLUG THE POWER SUPPLY CORD BACK INTO THE POWER SUPPLY. WITHIN SEVERAL SECONDS YOU WILL HEAR A LONG CHIRP FOLLOWED BY A SHORT CHIRP. YOUR BASE IS NOW SYNCED AND READY TO GO!
- Page 5 POWER SUPPLY (M9X532 & M9X542/542A 1. CONNECT THE POWER SUPPLY CORD INTO THE POWER 2. UNPLUG THE POWER SUPPLY CABLE FROM THE SUPPLY AND PLUG INTO AN OUTLET (MAKE SURE IT IS POWER SUPPLY (DO NOT UNPLUG FROM WALL CONNECTED TO THE POWER BASE) OUTLET)
- Page 6 REMOTE SYNC M9X532 & M9X542/542A 3. HOLD DOWN THE “HOME” AND “DOWN” BUTTONS SIMULTANEOUSLY UNTIL THE BLUE BACKLIGHT DISSAPERS (WITHIN 5-7 SECONDS)
- Page 7 4. PLUG THE POWER SUPPLY CORD BACK INTO THE POWER SUPPLY. WITHIN SEVERAL SECONDS YOU WILL HEAR A LONG CHIRP FOLLOWED BY A SHORT CHIRP. YOUR BASE IS NOW SYNCED AND READY TO GO!
- Page 8 POWER SUPPLY (M9X632 & M9X642/642A 1. CONNECT THE POWER SUPPLY CORD INTO THE POWER 2. UNPLUG THE POWER SUPPLY CABLE FROM THE SUPPLY AND PLUG INTO AN OUTLET (MAKE SURE IT IS POWER SUPPLY (DO NOT UNPLUG FROM WALL CONNECTED TO THE POWER BASE) OUTLET)
- Page 9 REMOTE SYNC M9X632 & M9X642 &642A 3. HOLD DOWN THE “SELECT” BUTTON UNTIL YOU SEE THE WORD “PAIR” ON THE SCREEN...
- Page 10 4. PLUG THE POWER SUPPLY CORD BACK INTO THE POWER 5. ONCE THE POWER SUPPLY IS PLUGGED BACK IN YOU SUPPLY. WITHIN SEVERAL SECONDS YOU WILL HEAR A LONG WILL SEE AN “ELCO” NOTIFICATION. YOUR POWER BASE CHIRP FOLLOWED BY A SHORT CHIRP. IS READY TO GO!
- Page 11 SELECTING YOUR MEMORY PRE SETS TO CUSTOMIZE YOUR MEMORY PRE SET, PRESS AND HOLD DOWN THE LIGHT BUTTON NEXT TO PRE SET NUMBER 2 (WAIT 5-7 SECONDS) YOU WILL SEE THE SCREEN FLASH “SAVE”. SELECT PRE SET 1 OR 2. THAT’S IT YOUR MEMORY SETTING IS COMPLETE!
- Page 12 HOW TO ASSEMBLE YOUR KING POWER BASE BY ASHLEY 1. THE M9X KING BASES ARRIVE IN 2. OPEN BOTH BOXES AND PLACE EACH TWO BOXES AS SHOWN. UNIT FACE UP ALLOWING THE PLEASE MAKE SURE YOUR MECHANICS TO SHOW. CUSTOMER KNOWS TO ALLOW ROOM FOR ASSEMBLY IN THEIR HOME.
- Page 13 KING HEAD UNIT WITH “HEAD MOTOR” 1. TAKE THE BOX LABELED “HEAD MOTOR” OUT OF THE BOX...
- Page 14 CUT THE ZIP TIES UNDERNEATH CONNECT THE “BOTTOM BASE” ON BOTH “HEAD MOTOR B” SIDES TO EXTEND THE ARM TO TO THE PIN UNDER ATTACH THE HEAD MOTOR. THE BOTTOM BASE LABELED “B” (NOTE THIS IS WHY YOU NEED TO CUT THE ZIP TIES IN ORDER TO MOVE THE ARM)
- Page 15 BOLTING THE TWO BASES AND HEAD MOTOR TO PIN “A” 1. BOLT THE HINGES FROM THE “HEAD BASE” TO THE “BOTTOM BASE” (THE 4 BOLTS ARE LOCATED IN THE BOX WITH THE CASTER LEGS) AFTER THE HINGES ARE BOLTED, ATTACH THE OTHER HALF OF THE HEAD MOTOR TO PIN “A”...
