INSTALLATION INSTRUCTION MANUAL
Bosch Electric Built-in Single & Double Oven
Models HBL 73../74../75../76.. and Models HBN 74../75../76..
BEFORE YOU BEGIN, READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY
IMPORTANT: Save these instructions for the local electrical inspector's use.
INSTALLER: Please leave this manual with owner for future reference.
OWNER: Please keep this manual for future reference.
VEUILLEZ LIRE ATTENTIVEMENT CE MANUEL AVANT DE COMMENCER L'INSTALLATION
IMPORTANT: Conservez ce manuel pour l'inspecteur électrique local.
INSTALLATEUR: Veuillez remettre ce manue! au proprietaire de l'appareil
PROPRIÉTAIRE: Veuillez garder ce manuel et vous en servir pour
pour référence.
référence.
for
© 2002 BSH Home Appliances Corp.
1
Advertisement
Table of Contents
Related Manuals for Bosch HBN 74..
Summary of Contents for Bosch HBN 74..
- Page 1 INSTALLATION INSTRUCTION MANUAL Bosch Electric Built-in Single & Double Oven Models HBL 73../74../75../76.. and Models HBN 74../75../76.. BEFORE YOU BEGIN, READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY IMPORTANT: Save these instructions for the local electrical inspector’s use. INSTALLER: Please leave this manual with owner for future reference.
-
Page 2: Table Of Contents
Choosing Oven Location ... 3 Steps For Installation ... 3 Technical Data ... 4 – 5 HBL Models: Single Oven, Double Oven ... 4 HBN Models: Single Oven, Double Oven ... 5 Undercounter Installation ... 6 Single Oven ... 6 Wall Installation ... -
Page 3: Introduction
> Undercounter Installation, Single Oven > Wall Installation, Single Oven > Wall Installation, Double Oven • Electrical Supply and Wiring Requirements, Pro- gramming required if connecting to 208 Volt Cir- cuit. Electrical Connections for 3-wire or 4-wire Branch Circuit. • Final Checklist... -
Page 4: Hbl Models: Single Oven, Double Oven
HBL 736A UC 240/208 HBL 742A UC 240/208 HBL 745A UC 240/208 HBL 746A UC 240/208 SINGLE OVEN DOUBLE OVEN For cutout dimensions see following section titled: Preparing Location Double Oven Models HBL 752A UC 240/208 HBL 755A UC 240/208... -
Page 5: Hbn Models: Single Oven, Double Oven
Models Volts HBN 742A UC 240/208 HBN 745A UC 240/208 HBN 746A UC 240/208 SINGLE OVEN DOUBLE OVEN For cutout dimensions see following section titled: Preparing Location and Maximum Connected Load Double Oven Models Volts HBN 752A UC 240/208 HBN 755A UC... -
Page 6: Undercounter Installation
UNDERCOUNTER INSTALLATION, SINGLE OVEN Oven electrical supply: Locate junction box in adjacent cabinet or below bottom support surface. HBL Models: 28" opening width HBN Models: 25-3/8" opening width Bottom support surface must be solid, level and able to support at least 150 lbs. HBL Models: 29-1/4"... -
Page 7: Wall Installation
WALL INSTALLATION, SINGLE OVEN Electrical supply junction Note: 1. Do not slide oven across floor. Damage to floor covering or floor could result. 2. The oven support surface must be a mini- mum 3/4" thick plywood platform, solid, level and flush with the bottom of the cabinet cutout. -
Page 8: Double Oven
WALL INSTALLATION, DOUBLE OVEN Note: 1. Do not slide oven across floor. Damage to floor covering or floor could result. 2. The oven support surface must be a mini- mum 3/4" thick plywood platform, solid, level and flush with the bottom of the cabinet cutout. -
Page 9: Electrical Supply
ELECTRICAL SUPPLY Before installing the oven have a qualified elec- trician verify that your home is provided with ad- equate electrical service and that the addition of the oven will not overload the branch circuit on which it is to be installed. A separate three-wire or four- wire single phase, 240 Volt, 60 Hz, or a 208 Volt, 60 Hz branch circuit is required. -
Page 10: Connecting To 208 Volt Circuit
In Canada: Wiring must conform to Canadian Electrical Code C22.1- latest edition. You can obtain a copy of the Canadian Electrical Code by writing: Canadian Standards Association 178 Rexdale Boulevard Rexdale (Toronto), Ontario, Canada M9W 1R3 4. Wire size (COPPER WIRE ONLY) and connec- tions must be suitable for the rating of the appli- ance per the National Electrical Code require- ments. -
Page 11: Electrical Connections
ELECTRICAL CONNECTIONS This appliance is manufactured with a green GROUND wire connected to the oven chassis. After making sure that the power has been turned off, connect the flexible conduit from the oven to the junction box using a U.L. listed conduit connector. Figures A and B and the instructions provided below present the most common way of connecting the ovens. -
Page 12: Final Checklist
FINAL CHECKLIST To prevent improper connections leading to dam- age of electrical components and so voiding the warranty, the following steps must be performed: 1. Check the electrical requirements and make sure you have the correct electrical supply and that the oven is properly grounded.
