ITEM PART NO. QTY.
1 0D8656 1
2 027482 2
3 070936 2
4 070936C 2
5 039253 8
6 022145 12
7 022129 16
8 045771 4
9 071956 4
10 051730 4
34 Generac ® Power Systems, Inc.
Section 7 - Exploded Views and Parts
Generac Liquid-cooled 20 kW Generator
Mounting Base — Drawing No. 0E0768-B
14
4
9
10
17
20
DESCRIPTION
BASE MOUNTING 1.5L STNRD &
ACSTC
WASHER SHAKEPROOF EXT 5/16
STL
DAMPENER VIBRATION
VIB. ISO. 70-75 DURO
SCREW HHC M8-1.25 X 20 G8.8
WASHER FLAT 5/16 ZINC
WASHER LOCK M8-5/16
NUT HEX M8-1.25 G8 YEL CHR
WASHER FLAT M8
SCREW HHC M8-1.25 X 60 G8.8
8
7
6
5
7
6
16
18
22
ITEM PART NO.
11 021991
13 0D9335
14 0D9336
15 0C2454
16 047411
17 022097
18 022473
19 055414
20 049813
21 026850
22 0A1694
6
11
3
9
10
22
1
20
QTY. DESCRIPTION
1 EARTH STRAP
2 PANEL SUPPORT
2 PANEL BRACKET
16 SCREW TH-FRM M6-1 X 16 N WA
Z/JS
1 SCREW HHC M6-1.0 X 16 G8.8
1 WASHER LOCK M6-1/4
1 WASHER FLAT 1/4-M6 ZINC
1 LUG SLDLSS #2-#8 X 17/64 CU
5 NUT HEX M6 X 1.0 G8 YEL CHR
1 WASHER SHAKEPROOF EXT 1/4 STL
2 1-1/2" BUTTON PLUG
5
7
6
2
15
