TP-Link AC2300 Quick Installation Manual

Quick Installation Guide
AC2300 Wireless MU-MIMO Gigabit Router
Images may differ from actual products.
Connect the Hardware
If your internet connection is through an Ethernet cable directly from the wall
instead of through a DSL/Cable/Satellite modem, connect the Ethernet cable
to the router's Internet port, and then follow Step 4 and 5 to complete the
hardware connection.
Internet
Power adapter
Modem
Power adapter
1
Turn off the modem,
and remove the backup
battery if it has one.
2
Connect the modem to the
router's Internet port with an
Ethernet cable.
3
Turn on the modem, and
then wait about 2 minutes
for it to restart.
Router
5
Verify that the following LEDs are on and solid to confirm the
hardware is connected correctly.
Power
On
Note: If the 2.4GHz LED and 5GHz LED are off, press and hold the Wi-Fi On/Off button
on the side panel for 2 seconds, then release the button. Both LEDs will turn solid on.
4
Connect the power adapter
to the router and turn on
the router.
2.4GHz 5GHz Internet
On On On
