TP-Link Archer VR2100v Quick Installation Manual

Quick Installation Guide
AC2100 Wireless MU-MIMO
VDSL/ADSL Telephony Modem Router
Archer VR2100v
Set up with videos:
Scan the QR code or visit
https://www.tp-link.com/support/setup-video/
to search for the setup video of your product.

1. Set up the Modem Router

Power Adapter
Phone Jack
2
Connect the DSL splitter to the phone jack.
Note: If you won't use the traditional landline phone service, you
can directly connect the modem router to the phone jack.
DSL Splitter
For traditional landline phone service
se t
Re
U S
B
W P
S
W LA
N
Po
w er
O n/
O ff
Modem Router
4
Push in to turn on the
modem router.

2. Connect the Phone

Analog Phone

Connect your analog phones to the Phone ports on the modem router's
back panel. You may connect up to two.
1
Attach the antennas.

DECT Cordless Phone

e2
Ph on
on e1
Ph
A Open the registration page on your cordless phone. Press and hold the DECT
L
DS
button on the modem router for about 3 seconds until the Phone LED
CT
DE
flashes.
3
Connect the modem router
to the DSL splitter.
B Enter the PIN (Default: 0000) on the cordless phone if required.
Phone1 or 2
e2
Phon
e1
Phon
DSL
DECT
Reset
DECT
Reset DECT
Within 1 minute Press for about 3 seconds
DECT
Flashing
