CONTENTS BEFORE USE BEFORE USE IMPORTANT • To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe Warnings BASICS and Cautions in this manual. GETTING STARTED • Please keep the manual in a safe and accessible place for future reference. 1 Cancel the demonstration WARNING 2 Set the clock and date...
BASICS Faceplate Remote control (RM-RK52) Symbolic button Display window Remote sensor (Do not expose to bright sunlight.) Pull out the insulation sheet when using for the first time. Detach button Attach Detach How to reset How to replace the battery Your preset adjustments will be erased except stored...
For details on how to update the firmware, visit To set the date <http://www.jvc.net/cs/car/>. Press VOL +/– to select [DATE SET], then press * ENTER. Press VOL +/– to make the settings, then press * ENTER. * Not displayed when the corresponding source is selected.
RADIO GETTING STARTED [CLOCK] [TIME SYNC] [ON]: The clock time is automatically set using the Clock Time (CT) data in FM Radio Data System signal. ; [OFF]: Cancels. [CLOCK [ON]: The clock time is shown on the DISPLAY] display even when the unit is turned off. ; [OFF]: Cancels.
Page 6
RADIO Select a stored station [SSM] [SSM 01–06]/[SSM 07–12]/[SSM 13–18]: Automatically presets up to 18 stations for FM. “SSM” stops flashing when the first 6 stations are stored. Select Press one of the number buttons (1 to 6). [SSM 07–12]/[SSM 13–18] to store the following 12 stations. (or) Press [LOCAL SEEK]...
RADIO PTY code Preparation: You can listen to music from a portable audio player via the auxiliary input [NEWS], [AFFAIRS], [INFO], [SPORT], [EDUCATE], [DRAMA], [CULTURE], [SCIENCE], [VARIED], jack. [POP M] (music), [ROCK M] (music), [EASY M] (music), [LIGHT M] (music), [CLASSICS], •...
USB/ANDROID Start playback The source changes automatically and playback starts. USB input terminal • To directly select USB source or ANDROID source, press USB. USB 2.0 cable*1 (commercially available) On the faceplate On the remote control Press and hold S / T. Press and hold H / I.
AUDIO SETTINGS USB/ANDROID Select music drive While in USB source, press 5 MODE repeatedly. Stored songs in the following drive will be played back. • Selected internal or external memory of a smartphone (Mass Storage Class). • Selected drive of a multiple drive device. Select a drive equalizer directly Select a file from a folder/list Drive equalizer boosts specific frequencies in the audio signal to reduce the...
Page 10
AUDIO SETTINGS Default: [XX] [TREBLE] Frequency : [10.0KHZ]/[12.5KHZ]/[15.0KHZ]/[17.5KHZ] Level [LVL–06] to [LVL+06] [EQ SETTING] [Q FIX] [PRESET EQ] Selects a preset equalizer suitable to the music genre. (Default [10.0KHZ]/[LVL 00]/[Q FIX]) • Select [USER] to use the settings made in [EASY EQ] or [PRO EQ]. [AUDIO CONTROL] [FLAT]/[DRVN 3]/[DRVN 2]/[DRVN 1]/[HARD ROCK]/[HIP HOP]/[JAZZ]/ [POP]/[R&B]/[TALK]/[USER]/[VOCAL BOOST]/[BASS BOOST]/[CLASSICAL]/ [BASS BOOST]...
Page 11
AUDIO SETTINGS Speaker output settings [VOLUME ADJUST] [LEVEL –15] to [LEVEL +06] ([LEVEL 00]): Presets the initial volume [SPK/PRE OUT] level of each source by comparing to the FM volume level. (Before Select the output setting for the speakers [SPK/PRE OUT], based on the speaker adjustment, select the source you want to adjust.
DISPLAY SETTINGS Zone identification for brightness settings Default: [XX] [DISPLAY] (Symbolic button) [DIMMER] Dims the illumination. [OFF]: Dimmer is turned off. Brightness changes to [DAY] setting. [ON]: Dimmer is turned on. Brightness changes to [NIGHT] setting. (See “[BRIGHTNESS]” below.) [DIMMER TIME]: Set the dimmer on and off time. 1 Press VOL +/–...
1 [RED]/[GREEN]/[BLUE]: Select a primary color. – Any other latest information 2 [00] to [31]: Select the level. Visit <www.jvc.net/cs/car/>. Repeat steps 1 and 2 for all the primary colors. [NIGHT COLOR] • Your setting is stored to [USER] in [PRESET].
TROUBLESHOOTING REFERENCES Change the display information Symptom Remedy Each time you press , the display information changes. Sound cannot be heard. • Adjust the volume to the optimum level. • If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other information •...
INSTALLATION/CONNECTION TROUBLESHOOTING Warning Symptom Remedy • The unit can only be used with a 12 V DC power supply, negative ground. “CANNOT PLAY” flashes and/ • Check whether the connected device is compatible with • Disconnect the battery’s negative terminal before wiring and mounting. or connected device cannot this unit and ensure the files are in supported formats.
Page 16
INSTALLATION/CONNECTION Part list for installation Installing the unit (in-dash mounting) (A) Faceplate (×1) (B) Trim plate (×1) Do the required wiring. (Page 17) (C) Mounting sleeve (×1) (D) Wiring harness (×1) Hook on the top side Orientate the trim Dashboard of plate as illustrated your car before fitting.
Page 17
We recommend installing the unit with a commercially available custom wiring harness specific Output for your car and leave this job to professionals for your safety. Consult your car audio dealer. JVC Amplifier*1 terminals *1 Firmly connect the ground wire of the amplifier to the car’s chassis to avoid damaging the unit.
SPECIFICATIONS Frequency Range 87.5 MHz — 108.0 MHz (50 kHz step) MP3 Decode Compliant with MPEG-1/2 Audio Layer-3 Usable Sensitivity (S/N = 26 dB) 8.2 dBf (0.71 μV/75 Ω) WMA Decode Compliant with Windows Media Audio Quieting Sensitivity (DIN S/N = 46 dB) 17.2 dBf (2.0 μV/75 Ω) WAV Decode Linear-PCM...
Page 19
SPECIFICATIONS libFLAC Copyright (C) 2000-2009 Josh Coalson Copyright (C) 2011-2013 Xiph.Org Foundation Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: - Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
