SPECIFICATIONS
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source
when determining product load.
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power
Inrush Charge: The total inrush charge at power on.
eDRX Mode Used: Average current will be lower if a longer eDRX Period time is used. An eDRX
Period time of 81.9 seconds was used , with a 20 second paging time
(AT#CEDRXS=2,4,"0101","0111"). Issue AT#CEDRXS? command to view network supplied parameters.
®
