Wharfedale Pro PROGRAMME 35 User Manual

P R O G R A M M E 3 5 & 3 5 T L O U D S P E A K E R
WHARFEDALE SYSTEMS
W A R N I N G & S A F E T Y I N S T R U C T I O N S
1. READ INSTRUCTIONS carefully before operating this product.
2. RETAIN these instructions.
3. COMPLY WITH WARNINGS - All warnings and instructions for
this product should be adhered to.
4. USE WITH AMPLIFIERS - In order to avoid damage, it is
advisable to establish and follow a pattern for turning on and off
any sound system. With all system parts connected, turn on
source equipment, tape decks, instruments, mixers, signal
processors etc., BEFORE turning on your power amplifier. Many
products output turn on and turn off transients that can damage
speakers. By turning on your power amplifier LAST and making
sure the amplifier's input controls are at minimum any transients
"upstream" of the amplifier are not amplified and passed to the
speaker. Wait until all system parts have stabilised, then bring up
amplifier controls to operating level. This should take no more
than a few seconds. Similarly when shutting systems down,
always turn down amplifier input controls and then turn off your
amplifier BEFORE shutting down other components. Professional
amplifiers often feature delayed turn on/off circuits to perform
these functions for you automatically.
Wharfedale Pro Programme 35 & 35T Professional Sound Reinforcement Loudspeakers
Proprietary designed, high efficiency, high power
Wharfedale Professional drive units.
Sophisticated crossover design enables smooth
power and frequency response control through
crossover region.
Integral High Frequency Driver Overload protection
"PRO-TECH"™
Unpacking
All Wharfedale Pro products are fully checked before leaving the
factory. After unpacking please inspect cabinets for any physical
damage. Please retain the shipping carton if possible and internal
packing material in case the unit needs to be
returned. Please check as soon as possible
the unit is functioning. In the event of any
damage please contact your dealer
immediately so that a written claim for
damages can be made.
Operating/Use
1. The Programme 35 & 35T accept stripped bare end cables. The
Programme 35 & 35T have a push and clip connector at the rear of
each cabinet.
2. Attach the speaker cable securely to your Programme Series unit
and power amplifier (the amplifier should be off, power down mode).
Try to use the correct type of speaker cable according to the handling
ability of your Programme Series Cabinet. Use 2 core equal stranded
insulated cable for speaker runs. It is always advisable to use heavier
conductor cables on longer runs.
3. Power up amplifier with levels on zero. Confirm units are operating.
PROGRAMME SERIES LOUDSPEAKERS

USER MANUAL

PROGRAMME 35, 35T
5. CABLES - Never use shielded or microphone cable for any
speaker connection as this will not be heavy enough to handle the
amplifier load and could cause damage to the complete system.
6.
The rigging, suspension or mounting of this speaker system can
expose members of the public to serious health risks and even
death. UNDER NO CIRCUMSTANCES ATTEMPT TO RIG,
SUSPEND OR OTHERWISE MOUNT THIS SYSTEM UNLESS
YOU ARE FULLY QUALIFIED AND CERTIFIED TO DO SO BY
RELEVANT LOCAL, STATE AND NATIONAL AUTHORITIES.
ALL RELEVANT SAFETY REGULATIONS MUST BE
FOLLOWED. IF YOU ARE NOT PROPERLY QUALIFIED OR DO
NOT KNOW OF PERTINENT REGULATIONS, CONSULT
QUALIFIED PERSONNEL FOR ADVICE AND ASSISTANCE.
7.
capable of generating very high sound pressure levels. Use care
with placement and operation to avoid exposure to excessive
levels that can cause permanent hearing damage.
8. SERVICING - The user should not attempt to service this
product except that mentioned in this manual.
High power output, low distortion sound quality
100 volt ine system with switchable power tapping
on 35T
Vinyl black ash or rosewood finish. (Finish can be
painted to match surroundings)
Developed from award winning Diamond Series
Small compact size
Wharfedale Pro Limited Warranty*
Wharfedale Programme
warranted to be clear of manufacturing or materials defects for a period of
one year from the original date of purchase. In the event of malfunction,
contact your authorised Wharfedale Professional dealer or distributor for
information.
*Be aware that warranty details may differ from country to country. Contact your dealer or
distributor for information.
RIGGING • SUSPENDING • MOUNTING
CAUTION: These professional loudspeaker systems are
35& 35T
Series loudspeaker systems are
These terms do not infringe your statutory rights.
Programme
35 Rear
