Summary of Contents for Wharfedale Pro DIAMOND 10 SERIES 10.3
-
Page 2: Cautions
Warning: To reduce the risk of fire or electrical shock,do not expose this product to rain or moisture. The product must not be exposed to dripping and splashing and no object filled with liquids-such as a vase of flowers- should be placed on the product. -
Page 3: Table Of Contents
Some Front and all Centre loudspeakers are magnetically screened.You should site front loudspeakers at least 0.5 m away from TV sets and magnetic storage media. All Wharfedale centre loudspeakers may be sited close to a TV screen with no adverse effects.The specifications on Pages 20 and 21 have AV shielding details for your loudspeakers. -
Page 4: Unpacking The Equipment
We hope you will derive many years of good service from our products. Servicing In the unlikely even that your unit develops a fault you should return it to your Wharfedale dealer using the original packing to ensure safe shipping. -
Page 5: C A L B S E N A D C O N N Crossovers
When connecting terminals make sure you leave no strands of bare wire that can short across to adjacent terminals. As an alternative to bare wire you can use specialist spade connectors. Your Wharfedale dealer will be pleased to advise you. Crossover Networks Bi-Wireable Networks Most speakers in the Diamond 10 series use a special bi-wireable crossover panel with four terminal binding posts. -
Page 6: Positioning The Front Loudspeakers
Positioning the Front Loudspeakers The 10.3, 10.4,10.5, 10.6 and 10.7 models are designed to be floor standing. We suggest that they are positioned at least 200 mm from the rear walls and 700 mm from the side walls, facing slightly inwards. The 10.1, and 10.2 models should be stand or wall mounted though they may be placed on a rigid shelf. -
Page 7: Positioning And Attaching Surround Loudspeakers
Fine Tuning Procedures Set up the subwoofer with all tone controls and filters on your amplifier or processor set ‘flat’. Listening rooms are not ideal. Because of room geometry and construction there will be areas with severe peaks at some frequencies and severe troughs at others. If you site loudspeakers in such areas the response will be highly non-flat. -
Page 8: Connecting The Front Loudspeakers
Connecting the Front Loudspeakers STANDARD CONNECTION D10 SERIES EXCEPT D10.0 R.SPKR Standard Connection Choose a suitable length of twin core speaker cable for each channel, and prepare the ends. Unscrew each terminal a few turns. Connect the red, positive (+) terminal of the Left loudspeaker to the corresponding red, positive (+) amplifier terminal. -
Page 9: Connecting The Centre And Surround Loudspeakers
Connecting Your Subwoofer - 2 Connecting to a Digital AV Processor A-V AMPLIFIER If your AV processor has a line level or LFE subwoofer output you should use this connection. You will need to purchase a single screened RCA phono lead from your dealer. Connect this lead to the RIGHT LEFT Left line input of the Subwoofer as shown. -
Page 10: Diamond 10 Subwoofers
Diamond 10 Subwoofers Introduction Wharfedale subwoofers are intended for use with high quality domestic sound systems. They are equally effective in Stereo and Home Cinema applications. Your subwoofer will probably be used in conjunction with Wharfedale loudspeakers though they will partner any audiophile or top-quality home cinema amplification and loudspeakers.
