- Page 1 USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO PT-16H610S LCD TV...
- Page 2 .com Westinghouse Digital Electronics Santa Fe Springs, CA SE-UM-1603-0701...
-
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY AND PRECAUTIONS...1 Important Information...1 Safety Precautions...2 Important Safety Instructions ...4 GENERAL INFORMATION ...6 Feature ...6 Controls and Ports of the Panel ...7 Accessories ...9 Remote Control...10 INSTALLATION AND FUNCTION ADJUSTMENT...12 Installation ...12 Function adjustment ...15 TROUBLESHOOTING ...29 PRODUCT SPECIFICATION ...332... -
Page 5: Important Safety And Precautions
IMPORTANT SAFETY AND PRECAUTIONS This wide active matrix TFT (thin film transistor) liquid crystal monitor is designed for use as a stand alone TV as well as a display device for video electronics appliances and personal computers. Important Information Warning : To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. -
Page 6: Safety Precautions
Safety Precautions 1. Cleaning : Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. 2. Water and moisture : Do not use the product near water or areas of high moisture content such as swimming pools, bathtubs or wet basements. - Page 7 7. Stand : Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product.
-
Page 8: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 9 13. Unplug the apparatus during lightening storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in an way, such as power-supply cord is damaged, liquid has been spilled or objects have fallen into apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has dropped.
-
Page 10: General Information
GENERAL INFORMATION Feature Your TV is designed with the latest technology and is a high-performance unit that includes the following special feature : Multi-sources input included RF IN, D-SUB, HDMIx2, Compositex2, and Componentx1. Built-in combo tuner is able to receive ATSC, NTSC and Clear QAM Cable signals. Built-in 10W dual channel speakers. -
Page 11: Controls And Ports Of The Panel
Controls and Ports of the Panel Power indicator & Remote sensor window FUNCTION KEYS MENU ( ) : Display the main menu. When OSD is appeared, press the button to select or access the sub-menu. 2. VOLUME ( ) : Decrease/Increase the volume or be the left/right arrow button for menu. 3. - Page 12 1. Service USB Factory service port 2. HDMI input Connect to an external video device such as HD digital cable/satellite receiver, HD STB, Media center PC, or DVD player 3. HDMI Audio input(R/L) Connect the audio input if you using a DVI-to-HDMI converter. 4.
-
Page 13: Accessories
Accessories LCD - TV User’s Manual Remote Control & Batteries Quick connect Power Cord Quick Connect Guide Warranty Card Warranty Card... -
Page 14: Remote Control
Remote Control Power Switch TV power on/off. Mute Turn the sound on/off. Swap No support No support Backlight Adjust the LCD Backlight level Sleep Press to select a preset time interval for automatic power down. Press to enable or disabled closed caption. Favorite Select, remove or add your favorite channel. - Page 15 Guide Broadcast program information. Info. Display the source and channel information. YPbPr1 Not available Select TV(NTSC/ATSC) source input. Not available HDMI Select HDMI input. YPbPr2 Not available. Not available. Video Select Video input. S-Video Not available. Dot button(NOTES) Quicker access to all the available virtual channels...
-
Page 16: Installation And Function Adjustment
NOTES Dot : The Dot Drop List is menu list of all the virtual channels available on the current physical channel for the user to select. The user can utilize this function for quicker access to all the available virtual channels instead of channeling through each channel. - Page 17 2. Connections...
- Page 18 3. Connect power cables Connect the power cord to the LCD TV then to a proper AC outlet. IMPORTANT: The power input voltage for TV is 120Vac, before beginning; make sure all devices are turned off. 4. Turn Power On Press the power button on the right side of the LCD TV, or press the power (Red) button on the remote control.
-
Page 19: Function Adjustment
Function adjustment There are four main Setup Menus; these are Settings, Channels, Locks and Guide. All the functions can be adjusted either by the remote control or by using the control keys on the LCD TV’s right side. Viewing OSD Menu To display the main menu, press the Menu button on the right side of front control keys of the LCD TV or the MENU key on the remote control. - Page 20 Press arrow keys to select or adjust your favorite picture settings. Preset Choose among different preset adjustments for TV picture. Movie / Sports / Game / Enhanced / User Contrast Press arrow keys to adjust the contrast. Brightness Press arrow keys to adjust the brightness. Sharpness Press arrow keys to adjust the Sharpness.
- Page 21 Backlight Press Enter to adjust backlight. Reset Press Enter to reset picture settings to factory defaults. Audio Bass / Treble / Balance Use arrow keys to adjust the treble, bass, and balance. Digital Preference Select language preference for digital channels. English / Francais / Espanol Analog Preference Select an analog audio preference if TV signal is analog.
- Page 22 Reset Press Enter key to recover the default audio setting. Time Sleep Timer(Off, 15Min, 30Min, 60Min) Set the sleep time to turn off TV. OFF / 15 Min / 30Min / 60Min Time Zone Press arrow keys to select time zone. Pacific, Alaska, Hawaii, Eastern, Atlantic, Central, Mountain DST(Daylight Saving Time) Press arrow keys to select ON or OFF.
- Page 23 Settings Need to change picture Menu Setting Menu Language Use arrow keys to adjust Menu Language English / Francais / Espanol...
- Page 24 OSD Time Out Use arrow keys to select 15,30,45,60 sec. OSD Transparency Press arrow keys to select your preferred setting. Off / Low / Middle / High Closed Caption Activation Press arrow keys to select your preferred setting. CC off / CC on / CC On when muted Basic Selection Choose the type of closed caption settings to use for programs broadcast with basic caption.
- Page 25 Advanced Selection Advanced CS1/Advance CS2/ Advance CS3/ Advance CS4/ Advance CS5/ Advance CS6 Advanced Appearance Use arrow keys to adjust closed caption appearance such as font and size, each change can be previewed on bottom of menu. Input Labels Press arrow keys to select your preferred default or custom of input labels. Need to change picture...
- Page 26 Autosource (ON, OFF) Autosource will detect a new incoming signal and automatically switch the input source to the connection of the new source’s device. Power Management Set TV power saving modes ( Normal/quick boot-up time, but large power consumption; Energy saving/longer boot-up time, but small power consumption.) DPMS Mode Press arrow keys to select your preferred setting.
- Page 27 System Info Display important system info, you may need the information when calling customer service or troubleshooting such as firmware version. Source ID/Resolution/Firmware Version/Model Number Advance ( For Software Upgrade) Rotate Video Press arrow keys to enable image flip. Reset Press Enter key to select recover the default setting or not.
- Page 28 Restore Default Pin Entry (Reset your TV to factory settings.) LOCK Lock feature prevents viewers from watching programs that are not age-appropriate, such as programs containing violence or adult language. Change Password The pin number is required when you want to enter Locks menu, just use the remote control to key in your pin number.
- Page 29 Input Block Block TV/AV/HDMI sources USA-TV TV Y All children TV Y7 For older children TV G General audience TV PG Parental guidance suggested TV 14 Parental strongly cautioned TV MA Mature audience only USA-Movie General audience Parental guidance suggested PG-13 Parental strongly cautioned Restricted...
- Page 30 NC 17 No on 17 and under admitted Adult audience only Canada Canada-English General programming, suitable for all audience 8 ans+ Children eight years and older 13 ans+ Viewers 13 year and older 16 ans+ Viewers 16 year and older 18 ans+ Adult programming Canada-French Children...
- Page 31 Front Panel Lock Press Enter to enable or disables the Front Panel buttons as below. Channel Antenna Press arrow keys to select Air or Cable for your TV signal. Auto Scan Press arrow keys to select scan available channels Scan All / Digital Only / Analog only...
- Page 32 Favorite List To display which channels have been set for Favorites. Channel List( Show / Hide ) To show and hide specific channel for Digital Only / Analog Only / Custom / All / None. Channel NO. To display channel. Channel Label Press arrow keys to channel and press arrow keys to edit the channel name.
-
Page 33: Troubleshooting
TROUBLESHOOTING... - Page 34 There is no picture or sound. ▪ Make sure the AC adapter is connected. ▪ Verify that there is a valid source signal. ▪ Make sure the correct input mode is selected. There is no picture from AV. ▪ Make sure the BRIGHTNESS is properly adjusted. ▪...
- Page 35 Picture is light or improperly tinted. ▪ Check the Hue, Saturation and Color adjustments. ▪ Reset the TV to the factory default settings. The picture is too dark. ▪ Select a different Video Preset mode. ▪ Check the Brightness of Picture Settings. ▪...
- Page 36 The picture is not sharp. ▪ The signal source may be weak. ▪ The provider may be experiencing difficulties. ▪ Check input connections. ▪ Check the Sharpness of Picture Settings. The picture moves. ▪ The source signal may be weak. ▪...
-
Page 37: Product Specification
PRODUCT SPECIFICATION ITEMS Screen Size Aspect Ratio Panel Resolution Display colors Viewing Angle (CR>10) Broadcasting System Receiving Channel TV Function Sound System Resolution Data Broadcasting Composite Signal Video Input HDMI Connection Audio 1 Audio Input Audio 2 Speaker ( build-in) Audio Output RCA Out Function Keys...
