Model No. WLTL22190
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WLTL22190
Summary of Contents for Weslo WLTL22190
- Page 1 ¨ Model No. WLTL22190 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satisfac- tion through direct assistance from our factory.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . - Page 3 14. Never start the treadmill while you are stand- ing on the walking belt. 15. Always hold the handrails while running on the treadmill. When walking, hold the handrails or use the included hand weights. 16. The treadmill is capable of high speeds. Adjust the speed in small increments to avoid sudden jumps in speed.
-
Page 4: Before You Begin
The model number of the treadmill is WLTL22190. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location). -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 6 3. With the help of a second person, hold the Console Base (6) and the Right Handrail (57) near the right Upright (14) as shown. Insert all excess Wire Harness (26) into the Handrail and down into the right Upright. Bend the Wire Harness as shown, if necessary.
-
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. They will deteriorate the walking belt and cause excessive wear. - Page 8 DIAGRAM OF THE CONSOLE Speed Control CAUTION: Before operating the console, read the following precautions. ¥ Do not stand on the walking belt when turn- ing on the power. ¥ Always wear the clip (see the drawing above) while operating the treadmill. When the key is removed from the console, the walking belt will stop.
- Page 9 Follow the steps below to operate the console. Insert the key fully into the power switch. Inserting the key will not turn on the dis- play. The display will turn on when the DIS- PLAY button is pressed or when the walking belt is started.
-
Page 10: How To Fold And Move The Treadmill
HOW TO USE THE HAND WEIGHTS To exercise your upper body as you walk on the treadmill, hold the 1-pound weights at your sides or press the weights above your head. To increase the intensity of your exercise, use the 2-pound or 3-pound weights. The hand weights can be stored on the weight rack. - Page 11 HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described above. Make sure that the stor- age latch is closed fully over the catch. 1. Hold the handrails and place one foot on the base as shown.
-
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be permanently damaged.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for in- dividuals over the age of 35 or individuals with pre-existing health problems. The following guidelines will help you to plan your exer- cise program. - Page 15 Training Zone Exercise After warming up, increase the intensity of your exer- cise until your pulse is in your training zone for 20 to 60 minutes. (During the first few weeks of your exer- cise program, do not keep your pulse in your training zone for longer than 20 minutes.) Breathe regularly and deeply as you exerciseÑnever hold your breath.
- Page 16 PART LISTÑModel No. WLTL22190 Key No. Qty. Description Key/Clip Left Handrail Cage Nut Wire Clip Rear Isolator Screw Console Base Speed Control Knob Speed Potentiometer Console Plug 3 lbs. Weight Console Assembly Storage Latch Screw Upright/Base Handrail Bolt Handrail Washer/Roller Washer...
- Page 17 EXPLODED DRAWINGÑModel No. WLTL22190 R0899A...
-
Page 18: Ordering Replacement Parts
If possible, place the treadmill near your telephone for easy reference when calling. WESLO is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
